Key Specifications
Engine
Two cylinder boxer
Fuel Capacity
20.00 litres
Advertisement
Full 2009 BMW R 1200GS Specifications
Colours
Slate grey matallic matt, Namibia orange
Width (mm)
23,749 mm
Width (in.)
935.0 inches
Wheelbase (mm)
1,507 mm
Wheelbase (in.)
59.3 inches
Length (mm)
2,210 mm
Length (in.)
87.0 inches
Height (mm)
1,450 mm
Height (in.)
57.1 inches
Wet Weight (lbs.)
504.9 pounds
Wet Weight (kg)
229.0 kg
Fuel Capacity (l)
20.00 litres
Fuel Capacity (gal.)
5.28 gallons
Dry Weight (lbs.)
447.5 pounds
Dry Weight (kg)
203
Bore x Stroke (in,)
4.0 x 2.9 inches
Bore x Stroke (mm)
101.0 x 73.0 mm
Displacement (cc)
1170.00 cc
Displacement (ci)
71.39 cubic inches
Engine Type
Two cylinder boxer
Fuel Control
SOHC
Fuel Reserve (gal.)
1.06 gallons
Fuel Reserve (l)
4.00 litres
Stroke
4
Fuel System
Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition
Compression Ratio
12.0:1
Exhaust
Euro 3
Starter
Electric
Valve System
4
Clutch
Single dry plate clutch, hydraulically operated
Final Drive
Shaft drive (cardan)
Gearbox
6-speed
Trail (in.)
4.0 inches
Trail (mm)
101 mm
Wheel Travel - Front (in.)
7.5 inches
Wheel Travel - Front (in.)
7.5 inches
Wheel Travel - Front (mm)
190 mm
Wheel Travel - Front (mm)
190 mm
Wheel Travel - Rear (in.)
7.9 inches
Wheel Travel - Rear (mm)
200 mm
Frame Type
Two-section frame consisting of front and rear sections, load- bearing engine-gearbox unit
Suspension - Front
BMW Motorrad Telelever
Suspension - Rear
Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Rake
25.7°
Brakes - Front Diameter (in.)
12.0 inches
Brakes - Front Diameter (mm)
305 mm
Brakes - Rear Diameter (in.)
10.4 inches
Brakes - Rear Diameter (mm)
265 mm
Brakes - Front
Double disc. Optional ABS, can be switched off
Brakes - Rear
Single disc. Optional ABS, can be switched off
Tyres - Front
110/80-19
Tyres - Rear
150/70-17
