Maximum RPM
|
- | - | - | - | 9000 | - | - | - | - | - | - | 14600 | 14600 | 14600 | 14600 | - |
|
Fuel Control
|
SOHC | DOHC | DOHC | DOHC | DOHC | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | - |
|
Engine Type
|
In-line four | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke | - |
|
Comments
|
- | - | Power Steering | Blata is from the Czech Republic. | - | 4 mode, disengageable Race ABS and DTC (Dynamic Traction Control). | 4 mode, disengageable Race ABS and DTC (Dynamic Traction Control). | 4 mode, disengageable Race ABS and DTC (Dynamic Traction Control). | 4 mode, disengageable Race ABS and DTC (Dynamic Traction Control). | 4 mode, disengageable Race ABS and DTC (Dynamic Traction Control). | - | 4 Ride Modes (Rain/Sport/Dynamic/Race) | 4 Ride Modes (Rain/Sport/Dynamic/Race). Dynamic Traction Control. Electronic Immobilizer. | 4 Ride Modes (Rain/Sport/Dynamic/Race). Dynamic Traction Control. Electronic Immobilizer. | 4 Ride Modes (Rain/Sport/Dynamic/Race). Dynamic Traction Control. Hill Start Control. Electronic Immobilizer. | - |
|
Displacement (cc)
|
999.00 cc | - | - | - | - | - | - | - | - | - | - | 999.0 cc | 999.0 cc | 999.0 cc | - | - |
|
Bore x Stroke (mm)
|
80.0 x 0.0 mm | - | - | - | - | - | - | - | - | - | - | 80.0 x 49.7 mm | 80.0 x 49.7 mm | 80.0 x 49.7 mm | - | - |
|
Bore x Stroke (in,)
|
3.1 x inches | - | - | - | - | - | - | - | - | - | - | 3.1 x 2.0 inches | 3.1 x 2.0 inches | 3.1 x 2.0 inches | - | - |
|
CO2
|
- | 132.2 CO | 132.2 CO | 132.2 CO | 951.2 CO ↑ | 125.3 CO2 g/km. (CO2 - Carbon dioxide emission) ↓ | 132.2 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ | 132.2 CO2 g/km. (CO2 - Carbon dioxide emission) | - | - | 155.4 CO2 g/km. (CO2 - Carbon dioxide emission) | 147.6 CO2 g/km. (CO2 - Carbon dioxide emission) ↓ | 147.6 CO2 g/km. (CO2 - Carbon dioxide emission) | - | - | - |
|
Seat Height
|
- | 820 mm / 33.3 in. | 820 mm / 33.3 in. | 820 mm / 33.3 in | 820 mm / 33.3 in | 820 mm / 33.3 in | 815 mm / 32.0 in ↓ | 815 mm / 32.0 in | 815 mm / 32.0 in. | 815 mm / 32.0 in. | 824 mm / 32.4 in ↑ | 823 mm / 32.4 in. ↓ | 823 mm / 32.4 in. | 823 mm / 32.4 in. | 824 mm / 32.4 in ↑ | 832 mm / 32.4 in ↑ |
|
Frame Type
|
Bridge-type aluminium frame, load-bearing engine | Bridge-type aluminium frame, load-bearing engine | Bridge-type aluminium frame, load-bearing engine | Bridge-type aluminium frame, load-bearing engine | Bridge-type aluminium frame, load-bearing engine | Bridge-type aluminium frame, load-bearing engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Aluminium composite bridge frame, partially self-supporting engine | Bridge-type aluminum laminate frame with load-bearing engine | Bridge-type aluminum laminate frame with load-bearing engine |
|
Dry Weight
|
183 kg / 403.4 lbs | 183 kg / 403.4 lbs | 183 kg / 403.4 lbs | 178 kg / 398 lbs ↓ | 178 kg / 398 lbs | 178 kg / 398 lbs | 175.5 kg / 386.9 lbs ↓ | 175.5 kg / 386.9 lbs | 175.5 kg / 386.9 lbs | 175.5 kg / 386.9 lbs | 179.5 kg / 395.7 lbs ↑ | - | - | 208 kg / 458.6 lbs | 175 kg / 385.8 lbs - M Package: 173.2 kg / 382 lbs (without battery) ↓ | 176 kg / 388 lbs ↑ |
|
Engine Detail
|
- | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder | Titanium valves | Titanium valves | Titanium valves | Four stroke, transverse four cylinder, DOHC, valve actuation via single cam followers, BMW ShiftCam variable intake cam control | Four stroke, transverse four cylinder, DOHC, valve actuation via single cam followers, BMW ShiftCam variable intake cam control |
|
Brakes - Front
|
Double disc. ABS, wight of entire system 2.5 kg. Optional DTC Dynamic Traction Control . | 2x 320mm discs 4 piston calipers ↓ | 2x 320mm discs 4 piston calipers | 2x 320mm discs 4 piston calipers | 2x 320mm discs 4 piston calipers | 2x 320mm discs 4 piston calipers | 2 x 320mm Discs, 4 piston calipers | 2 x 320mm Discs, 4 piston calipers | 2 x 320mm Discs, 4 piston calipers | 2 x 320mm Discs, 4 piston calipers | 2x 320mm floating disc, radial 4-piston fixed calipers | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. | 2x 320mm floating disc, radial 4-piston fixed calipers | 2x 320mm floating disc, radial 4-piston fixed calipers |
|
Wheelbase
|
- | 1422 mm / 56 in. | 1422 mm / 56 in. | 1422.7 mm / 56.0 in ↑ | 1422.7 mm / 56.0 in | 1422.7 mm / 56.0 in | 1425 mm / 56.1 in ↑ | 1425 mm / 56.1 in | 1425 mm / 56.1 in | 1425 mm / 56.1 in | 1441 mm / 56.7 in ↑ | 1441 mm / 56.7 in. | 1441 mm / 56.7 in. | 1441 mm / 56.7 in. | 1457 mm / 57.4 in ↑ | 1457 mm / 57.4 in |
|
Brakes - Rear
|
Single disc. ABS | Single 220mm disc 1 piston calipers | Single 220mm disc 1 piston calipers | Single 220mm disc 1 piston calipers | Single 220mm disc 1 piston calipers | Single 220mm disc 1 piston calipers | Single 220mm disc, 1 piston caliper | Single 220mm disc, 1 piston caliper | Single 220mm disc, 1 piston caliper | Single 220mm disc, 1 piston caliper | Single 220 mm disk, single-piston floating caliper | Single disc. ABS. Floating disc. Single-piston caliper. | Single disc. ABS. Floating disc. Single-piston caliper. | Single disc. ABS. Floating disc. Single-piston caliper. | Single 220 mm disk, single-piston floating caliper | Single 220 mm disk, single-piston floating caliper |
|
Fuel Capacity
|
- | 17.5 Litres / 4.6 US gal. | 17.5 Litres / 4.6 US gal. | 17.5 Litres / 4.6 US gal | 17.5 Litres / 4.6 US gal | 17.5 Litres / 4.6 US gal | 17.5 Litres / 4.6 US gal | 17.5 Litres / 4.6 US gal | 17.5 Litres / 4.6 US gal. | 17.5 Litres / 4.6 US gal. | 16.5 Litres / 4.4 US gal ↓ | 16.50 litres / 4.36 US gallons | 16.50 litres / 4.36 US gallons | 16.50 litres / 4.36 US gallons | 16.5 Litres / 4.35 US gal | 16.5 Litres / 4.35 US gal |
|
Suspension - Front
|
Upside down fork, 46 mm | 43mm Telescopic fork ↓ | 43mm Telescopic fork | 43mm Telescopic fork | 43mm Telescopic fork | 43mm Telescopic fork | Upside-down telescopic fork ø 46 mm, compression and rebound stage adjustable ↑ | Upside-down telescopic fork ø 46 mm, compression and rebound stage adjustable | Upside-down telescopic fork ø 46 mm, compression and rebound stage adjustable | Upside-down telescopic fork ø 46 mm, compression and rebound stage adjustable | Upside-down telescopic fork, slide tube diameter 45 mm, spring preload, compression and rebound stage adjustable, DDC option: damping electronically adjustable ↓ | Upside-down telescopic fork 46 mm, compression and rebound stage adjustable, ↑ | Upside-down telescopic fork 46 mm, compression and rebound stage adjustable, | Upside-down telescopic fork 46 mm, compression and rebound stage adjustable. | 45 mm Upside-down telescopic fork, compression and rebound stage adjustable, spring preload, optional DDC electronically adjustable damping ↓ | Upside-down telescopic fork, diameter 45 mm, spring preload, rebound and compression stages adjustable |
|
Suspension - Rear
|
Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable | Cast aluminium double-strut swingarm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable. | Cast aluminium double-strut swingarm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable. | Cast aluminium double-strut swingarm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable. | Cast aluminium double-strut swingarm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable. | Cast aluminium double-strut swingarm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable. | Aluminium double-strut swingarm, compression and rebound damping adjustable | Aluminium double-strut swingarm, compression and rebound damping adjustable | Aluminium double-strut swingarm, compression and rebound damping adjustable | Aluminium double-strut swingarm, compression and rebound damping adjustable | Aluminium underslung double-sided swinging arm with central spring strut, spring preload, adjustable compression and rebound stage, DDC option: damping electronically adjustable | WSBK Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload | WSBK Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload | WSBK Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload | Aluminum underslung double-sided swingarm, Central spring and shock absorber, Spring preload, rebound and compression adjustable, Optional DDC electronically adjustable damping | Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable spring preload |
|
Top Speed
|
200.0 km/h / 124.3 mph | 299 km/h / 185.7 mp/h ↑ | 299 km/h / 185.7 mp/h | - | 193.1 km/h / 120.0 mph | 201.2 km/h / 125.0 mph ↑ | - | 201.2 km/h / 125.0 mph | - | - | 200.0 km/h / 124.3 mph | 200.0 km/h / 124.3 mph | 201.2 km/h / 125.0 mph ↑ | 297.7 km/h / 185.0 mph ↑ | 302.6 km/h / 188.0 mph ↑ | - |
|
Fuel System
|
Injection | Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K-P) | Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K-P) | Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K-P) | Injection. Electronic injection, digital engine electronics with integrated knock control (BMS-KP) | Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K-P) | Injection. Electronic injection | Injection. Electronic injection | Injection. Electronic injection, variable intake pipe | Injection. Electronic injection, variable intake pipe | Injection. Electronic injection, variable intake pipe | Injection. Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor | Injection. Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor | Injection. Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor | Injection. Electronic injection, variable intake pibe | - |
|
ABS
|
- | Optional equipment BMW Motorrad Race ABS (partially integral, disengageable) | Optional equipment BMW Motorrad Race ABS (partially integral, disengageable) | BMW Motorrad Race ABS, disengageable, 4 modes to select: Rain, Sport, Race, Slick (optional equipment) | BMW Motorrad Race ABS, disengageable, 4 modes to select: Rain, Sport, Race, Slick (optional equipment) | BMW Motorrad Race ABS, disengageable, 4 modes to select: Rain, Sport, Race, Slick (optional equipment) | BMW Motorrad Race ABS (part-integral), disengageable, modes to select | BMW Motorrad Race ABS (part-integral), disengageable, modes to select | BMW Motorrad Race ABS (part-integral), disengageable, modes to select | BMW Motorrad Race ABS (part-integral), disengageable, modes to select | BMW Motorrad ABS Pro (part integral, disengageable) | - | - | - | BMW Motorrad Race ABS (partial integral), Brake-Slide-Assist / BMW Motorrad ABS Pro (settings for RAIN, ROAD, DYNAMIC, RACE mode) | BMW Motorrad Race ABS (partial integral), Brake-Slide-Assist / BMW Motorrad ABS Pro (settings for RAIN, ROAD, DYNAMIC, RACE mode) |
|
Colours
|
Mineral Silver metallic, Acid Green metallic, Thunder Grey metallic, Alpine White/Lupine Blue/Magma Red. | Green, gray, silver, white/blue/red | Yellow, thunder grey, white/blue/red, light grey | Blue, black, blue/white, red | Red/white, grey, black, white/blue/red | Granite Grey Metallic Matte/Alpine White, Racing Red/Alpine White/Sapphire Black Metallic, Sapphire Black Metallic, | Red/white, black, white/blue/red | Racing Red/Light White, Black Storm Metallic, Black Storm Metallic/racing Red, Light White/Lupin Blue Metallic/Racing Red | Grey/black, red/white/blue, red/white | Racing Red/Light White, Granite Grey Metallic/Black Storm Metallic | Light White/Lupin Blue Metallic/Racing Red | Light White/Lupin Blue Metallic/Racing Red, Racing Red | Light White/Lupin Blue Metallic/Racing Red, Racing Red, Hockenheim Silver Metallic | Light White/Lupin Blue Metallic/Racing Red, Black Storm Metallic, Mineral Gray Metallic | Light White/M Motorsport, Passion Red, Black Storm Metallic | - |
|
Alternator
|
- | - | - | - | - | - | 350 W | 350 W | 350 W | 350 W | 450 W ↑ | - | - | - | - | - |
|
Battery Capacity
|
- | 14 V / 10 Ah, maintenance-free | 14 V / 10 Ah, maintenance-free | 14 V / 10 Ah, maintenance-free | 14 V / 10 Ah, maintenance-free | 14 V / 10 Ah, maintenance-free | 12 V / 7 Ah, maintenance-free ↓ | 12 V / 7 Ah, maintenance-free | 12 V / 7 Ah, maintenance-free | 12 V / 7 Ah, maintenance-free | 12 V / 8 Ah, maintenance-free | - | - | - | - | - |
|
Clutch
|
Multiple-disc clutch in oil bath, mechanically operated | Multiple disc antihopping clutch in oil bath, mechanically operated | Multiple disc antihopping clutch in oil bath, mechanically operated | Multiple disc antihopping clutch in oil bath, mechanically operated | Multiple disc antihopping clutch in oil bath, mechanically operated | Multiple disc antihopping clutch in oil bath, mechanically operated | Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled | Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled | Multi-plate anti-hopping wet clutch, mechanically activated | Multi-plate anti-hopping wet clutch, mechanically activated | Self-reinforcing multi-plate anti-hopping wet clutch, mechanically activated | Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled | Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled | Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled | Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement | Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement |
|
Final Drive
|
Chain | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain 525 17/46 | Chain 525 17/46 |
|
Height
|
- | 1138 mm / 44.8 in. (excl. mirrors) | 1138 mm / 44.8 in. (excl. mirrors) | 1138 mm / 44.8 in. (excl. mirrors) | 1138 mm / 44.8 in. (excl. mirrors) | 1138 mm / 44.8 in. (excl. mirrors) | 1140 mm / 44.8 in. (excl. mirrors) ↑ | 1140 mm / 44.8 in. (excl. mirrors) | 1140 mm / 44.8 in. (excl. mirrors) | 1140 mm / 44.8 in. (excl. mirrors) | 1140 mm / 44.9 in. | 1151 mm / 45.3 in. ↑ | 1151 mm / 45.3 in. | 1151 mm / 45.3 in. | 1203.9 mm / 47.4 in ↑ | 1205 mm / 47.4 in ↑ |
|
Rims
|
- | - | Cast aluminium | Cast aluminium | Aluminum cast wheels | Cast Aluminium | Aluminium cast wheels | Cast aluminum wheels | - | Die-cast aluminium wheels | Die-cast aluminium wheels | Aluminum cast wheels | Cast aluminium | - | - | - |
|
Length
|
2,145 mm / 84.4 in. | 2056 mm / 80.9 in. ↑ | 2056 mm / 80.9 in. | 2056 mm / 80.9 in. | 2056 mm / 80.9 in. | 2056 mm / 80.9 in. | 2050 mm / 80.7 in. ↓ | 2050 mm / 80.7 in. | 2050 mm / 80.7 in. | 2050 mm / 80.7 in. | 846 mm / 33.3 in (with mirrors) ↓ | 2073 mm / 81.6 in. ↑ | 2073 mm / 81.6 in. | 2073 mm / 81.6 in. | 2073 mm / 81.6 in | 2073 mm / 81.6 in |
|
Wet Weight
|
206.5 kg / 455.3 lbs | 204 kg / 449.7 lbs ↓ | 204 kg / 449.7 lbs | 202.0 kg / 445.3 lbs ↓ | 204.6 kg / 451.0 lbs ↑ | 202.0 kg / 445.3 lbs ↓ | 204 kg / 449.7 lbs ↑ | 204 kg / 449.7 lbs | 204 kg / 449.7 lbs | 204 kg / 449.7 lbs | Standard: 197 kg / 434.3 lbs with Race Package option 195.4 / 430.7 lbs with M Package option 193.5 kg / 426.6 ↓ | 197.0 kg / 434.3 lbs | 197.0 kg / 434.3 lbs | 196.9 kg / 434.0 lbs ↓ | 197 kg / 434.3 lbs - M Package: 193.2 kg / 426.6 lbs ↑ | 198 kg / 436.5 lbs ↑ |
|
Compression Ratio
|
- | 13:1 | 13:1 | 13.0:1 | 13.0:1 | 13.0:1 | 13.0:1 | 13.0:1 | 13.0:1 | 13.0:1 | 13.3:1 ↑ | 13.3:1 | 13.3:1 | 13.3:1 | 13.3:1 | 13.3:1 |
|
Gear Ratios
|
- | 1st 2.6471 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261:1 | 1st 2.6471 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261:1 | 1st 2.6471 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261:1 | 1st 2.6471 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261:1 | 1st 2.6471 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261:1 | - | - | 1st 2.647 2nd 2.091 3rd 1.727 4th 1.5 5th 1.36 6th 1.261 | 1st 2.647 2nd 2.091 3rd 1.727 4th 1.5 5th 1.36 6th 1.261 | 1st 2.647 2nd 2.091 3rd 1.727 4th 1.500 5th 1.360 6th 1.261 | - | - | - | - | 1st: 2.647 / 2nd: 2.091 / 3rd: 1.727 / 4th: 1.500 / 5th: 1.360 / 6th: 1.261 |
|
Cooling System
|
- | Liquid cooled. | Liquid cooled. | Liquid cooled. | Liquid cooled. | Liquid cooled. | Liquid cooled | Liquid cooled | Liquid cooled | Liquid cooled | Liquid cooled | - | - | - | Liquid/oil cooled | Liquid/oil cooled |
|
Emissions
|
- | Two regulated three-way catalytic converters, EU-3 | Two regulated three-way catalytic converters, EU-3 | Two regulated three-way catalytic converters, EU-3 | Two regulated three-way catalytic converters, EU-3 | Two regulated three-way catalytic converters, EU-3 | - | - | Closed-loop 3-way catalytic converters, EU-4 norm with electronically controlled interference pipe | Closed-loop 3-way catalytic converters, EU-4 norm with electronically controlled interference pipe | Closed-loop three-way catalytic converter | Closed-loop 3-way catalytic converter, emission standard EU-4 | Closed-loop 3-way catalytic converter, emission standard EU-4 | Euro 4. Closed-loop 3-way catalytic converter. ↑ | Closed-loop 3-way catalytic converter, emission standard EU-5 ↓ | Closed-loop 3-way catalytic converter, emission standard EU-5 |
|
Tyres - Front
|
120/70-ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70-ZR17 | 120/70-ZR17 | 120/70-ZR17 | 120/70 ZR17 | 120/70 ZR17 |
|
Engine Lubrication
|
Dry sump | - | Dry sump | Dry sump | - | - | - | Wet sump | Wet sump | Wet sump | Wet sump | Wet sump | Wet sump | Wet sump | Wet sump | - |
|
Width
|
- | 826 mm / 32.5 in. (incl. mirrors) | 826 mm / 32.5 in. (incl. mirrors) | 826 mm / 32.5 in (incl. mirrors) | 826 mm / 32.5 in (incl. mirrors) | 826 mm / 32.5 in (incl. mirrors) | 826 mm / 32.5 in. (incl. mirrors) | 826 mm / 32.5 in. (incl. mirrors) | 826 mm / 32.5 in. (incl. mirrors) | 826 mm / 32.5 in. (incl. mirrors) | 846 mm / 33.3 in (with mirrors) ↑ | 848 mm / 33.4 in. ↑ | 848 mm / 33.4 in. | 848 mm / 33.4 in. | 848 mm / 33.4 in | 848 mm / 33.4 in |
|
Engine Management
|
- | - | - | - | - | - | Emission control Closed-loop 3-way catalytic converters, EU-3 norm with electronically controlled interference pipe | Emission control Closed-loop 3-way catalytic converters, EU-3 norm with electronically controlled interference pipe | Emission control Closed-loop 3-way catalytic converters, EU-3 norm with electronically controlled interference pipe | Emission control Closed-loop 3-way catalytic converters, EU-3 norm with electronically controlled interference pipe | BMS-O | - | - | - | BMS-0 | Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor, 48mm throttle body | BMS-0 | Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor, 48mm throttle body |
|
Tyres - Rear
|
180/55-ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 180/55 ZR17 | 190/55 ZR17 ↑ | - | - | - | 190/55 ZR17 (with M wheels: 200/55 ZR17) | 190/55 ZR17 (with M wheels: 200/55 ZR17) |
|
Primary Drive
|
- | - | Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD + Diff Lock | - | - | Chain Driveline | Chain 17/45 | Chain 17/45 | Chain 17/45 | Chain 17/45 | 1.652 ↓ | Chain 17/45 ↑ | Chain 17/45 | - | - | - |
|
Wheels
|
- | Cast alumiium | Cast alumiium | Cast alumiium | Cast alumiium | Cast alumiium | Aluminium cast wheels | Aluminium cast wheels | Aluminium cast wheels | Aluminium cast wheels | Standard: Die-cast aluminium wheels Forged aluminium wheels as part of Race Package option Carbon fibre wheels as part of M Package option | - | - | - | Standard die-cast aluminum wheels Optional M forged aluminum or M Carbon wheels | Standard die-cast aluminum wheels Optional M forged aluminum or M Carbon wheels |
|
Rake
|
25.8° | 23.9° ↓ | 23.9° | 23.9° | 24.0° ↑ | 24.6° ↑ | 23.5° ↓ | 23.5° | 23.5° | 23.5° | 23.5° | 23.5° | 23.5° | 23.5° | 23.6° ↑ | - |
|
Instrumentation
|
- | - | - | - | - | - | - | - | - | - | - | - | Three-phase 450 W Generator. 12 V / 8 Ah, maintenance-free. | Three-phase 450 W Generator. 12 V / 8 Ah, maintenance-free battery. | 6.5´ TFT-Display ↓ | - |
|
Lighting system
|
- | - | - | 12V 55W headlight | - | - | - | - | - | - | - | LED Headlight | LED Headlight | LED Headlight | LED Headlight | - |
|
Fuel Consumption
|
- | 5.70 litres/100 km (17.5 km/l or 41.27 mpg) | 5.70 litres/100 km (17.5 km/l or 41.27 mpg) | 5.70 litres/100 km (17.5 km/l or 41.27 mpg) | 41.00 litres/100 km (2.4 km/l or 5.74 mpg) ↑ | 5.40 litres/100 km (18.5 km/l or 43.56 mpg) ↓ | 5.70 litres/100 km (17.5 km/l or 41.27 mpg) ↑ | 5.70 litres/100 km (17.5 km/l or 41.27 mpg) | - | - | 6.70 litres/100 km (14.9 km/l or 35.11 mpg) | 6.36 litres/100 km (15.7 km/l or 36.98 mpg) ↓ | 6.36 litres/100 km (15.7 km/l or 36.98 mpg) | - | - | - |
|
Transmission / Drive
|
- | 6 Speed | 6 Speed | 6 Speed | 6 Speed | 6 Speed | Constant-mesh 6-speed gearbox, straight-toothed | Constant-mesh 6-speed gearbox, straight-toothed | Constant-mesh 6-speed gearbox, straight-toothed | Constant-mesh 6-speed gearbox, straight-toothed | Constant-mesh 6-speed gearbox | - | - | - | Claw-shifted 6-speed gearbox with straight cut gears | Claw-shifted 6-speed gearbox with straight cut gears |
|
Steering Head Angle
|
- | 66.1° | 66.1° | 66.1° | 66.1° | 66.1° | 66,5° ↑ | 66,5° | 66,5° | 66,5° | 66.9° ↑ | - | - | - | 66.4° | 66.4° |
|
Fuel Reserve
|
- | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 gallons | 3.79 litres / 1.00 gallons ↓ | 4.00 litres / 1.06 gallons ↑ | 4.1 Litres / 1.08 US gal ↑ | 4.1 Litres / 1.08 US gal | 4.1 Litres / 1.08 US gal | 4.1 Litres / 1.08 US gal | 4.00 litres / 1.06 US gallons ↓ | 4.00 litres / 1.06 US gallons | 4.00 litres / 1.06 US gallons | 4.00 litres / 1.06 US gallons | 4.00 litres / 1.06 US gallons | - |
|
Trail
|
95 mm / 3.7 in. | 95.9 mm ↑ | 95.9 mm | 98.5 mm ↑ | 98.5 mm | 98.5 mm | 96.5 mm / 3.8" ↓ | 96.5 mm / 3.8 in | 96.5 mm / 3.8 in | 96.5 mm / 3.8 in | 93.9 mm / 3.7 in ↓ | 97 mm / 3.8 in. ↑ | 94 mm / 3.7 in. ↓ | 94 mm / 3.7 in. | 99.8 mm / 3.9 in ↑ | 99.8 mm / 3.9 in |
|
Max Power
|
- | 143.9 kW / 193 hp @ 13000 rpm | 143.9 kW / 193 hp @ 13000 rpm | 143.9 kW / 193 hp @ 13000 rpm | 143.9 kW / 193 hp @ 13000 rpm | 143.9 kW / 193 hp @ 13000 rpm | 146 kW / 199 hp @ 13500 rpm ↑ | 146 kW / 199 hp @ 13500 rpm | 146 kW / 199 hp @ 13500 rpm | 146 kW / 199 hp @ 13500 rpm | 152 kW / 207 hp @ 13500 rpm ↑ | - | - | - | 151 kW / 205 hp @ 13000 rpm | 154 kW / 206 hp @ 13700 rpm ↑ |
|
Wheel Travel - Front
|
125 mm / 4.9 in. | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 120 mm / 4.7 in ↓ | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in | 120 mm / 4.7 in |
|
Wheel Travel - Rear
|
125 mm / 4.9 in. | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 125 mm / 4.9 in | 120 mm / 4.7 in ↓ | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 117 mm / 4.6 in ↓ | 117 mm / 4.6 in. | 117 mm / 4.6 in. | 117 mm / 4.6 in. | 117 mm / 4.6 in | 118 mm / 4.6 in ↑ |
|
Max Torque
|
112.00 | 112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm | 112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm | 112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm | 112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm | 112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm | 113 Nm / 11.5 kgf-m / 83.3 lb-ft @ 10500 rpm ↑ | 113 Nm / 11.5 kgf-m / 83.3 lb-ft @ 10500 rpm | 113 Nm / 11.5 kgf-m / 83.3 lb-ft @ 10500 rpm | 113 Nm / 11.5 kgf-m / 83.3 lb-ft @ 10500 rpm | 113 Nm / 83.3 lb-ft @ 10500 rpm | 112.6 Nm (11.5 kgf-m or 83.0 ft.lbs) @ 11000 Revolutions" ↓ | 112.6 Nm (11.5 kgf-m or 83.0 ft.lbs) @ 11000 Revolutions" | 112.6 Nm (11.5 kgf-m or 83.0 ft.lbs) @ 11000 Revolutions" | 113 Nm / 83.3 lb-ft @ 11000 rpm ↑ | 113 Nm / 83.3 lb-ft @ 11000 rpm |
|
Power-to-Weight Ratio
|
1.0405 HP/kg | 1.0405 HP/kg | 1.0406 HP/kg | 1.0698 HP/kg ↑ | 1.0691 HP/kg | 1.0843 HP/kg ↑ | 1.1156 HP/kg ↑ | 1.1339 HP/kg ↑ | - | 1.1086 HP/kg | 1.1086 HP/kg | - | - | 0.9856 HP/kg | 1.1714 HP/kg ↑ | - |
|
Intake / Outlet Valve Diameter
|
- | 33.5 mm / 27.2 mm | 33.5 mm / 27.2 mm | 33.5 mm / 27.2 mm | 33.5 mm / 27.2 mm | 33.5 mm / 27.2 mm | - | - | - | - | 33.5/27.2 | - | - | - | - | - |
|
Starter
|
Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric, 0.8 kW | Electric | Electric | Electric | Electric | Electric |
|
Throttle valve diameter
|
- | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | - | - | - | - | 48 mm / 1.9 in | - | - | - | - | - |
