Key Specifications
Engine
In-line four, four-stroke
Power
152 kW / 207 hp @ 13500 rpm
Torque
113 Nm / 83.3 lb-ft @ 10500 rpm
Weight
Standard: 197 kg / 434.3 lbs with Race Package option 195.4 / 430.7 lbs with M Package option 193.5 kg / 426.6
Fuel Capacity
17.50 litres
Full 2019 BMW S 1000RR Specifications
Year
2019
Colours
Light White/Lupin Blue Metallic/Racing Red
Make Model
BMW S 1000RR
Width (mm)
826 mm
Width (in.)
32.5 inches
Wheelbase (mm)
1438 mm
Wheelbase (in.)
56.6 inches
Height (in.)
44.9 inches
Height (mm)
1140 mm
Length (in.)
80.7 inches
Length (mm)
2050 mm
Seat Height (in.)
32.1 inches
Seat Height (mm)
815 mm
Seat Height
824 mm / 32.4 in
Wheelbase
1441 mm / 56.7 in
Length
846 mm / 33.3 in (with mirrors)
Width
846 mm / 33.3 in (with mirrors)
Wet Weight (kg)
208.0 kg
Wet Weight (lbs.)
458.6 pounds
Fuel Capacity (l)
17.50 litres
Fuel Capacity (gal.)
4.62 US gallons
Dry Weight (lbs.)
395.7 pounds
Dry Weight (kg)
179.5
Fuel Capacity
16.5 Litres / 4.4 US gal
Wet Weight
Standard: 197 kg / 434.3 lbs with Race Package option 195.4 / 430.7 lbs with M Package option 193.5 kg / 426.6
Fuel Reserve (l)
4.00 litres
Fuel Reserve (gal.)
1.06 US gallons
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
Displacement (ci)
60.96 cubic inches
Displacement (cc)
999.0 cc
CO2
155.4 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
80.0 x 49.7 mm
Bore x Stroke (in,)
3.1 x 2.0 inches
Displacement
999 cc / 60.9 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Fuel System
Injection. Electronic injection, variable intake pipe
Bore x Stroke
80 x 49.7 mm
Compression Ratio
13.3:1
Cooling System
Liquid cooled
Emissions
Closed-loop three-way catalytic converter
Engine Lubrication
Wet sump
Engine Management
BMS-O
Fuel Consumption
6.70 litres/100 km (14.9 km/l or 35.11 mpg)
Fuel Type
Premium (super plus) unleaded petrol, octane number 95-98 (RON) (knock control; rated output with 98 RON)
Intake / Outlet Valve Diameter
33.5/27.2
Lubrication
Wet sump
Mixture Control
Electronic injection
Starter
Electric, 0.8 kW
Throttle valve diameter
48 mm / 1.9 in
Valve Actuation / Drive
Valve activation via individual rocker arms and variable intake camshaft control system BMW ShiftCam
Battery Capacity
12 V / 8 Ah, maintenance-free
Clutch
Self-reinforcing multi-plate anti-hopping wet clutch, mechanically activated
Final Drive
Chain
Gear Ratios
1st 2.647 2nd 2.091 3rd 1.727 4th 1.500 5th 1.360 6th 1.261
Gearbox
6-speed
Primary Drive
1.652
Secondary Drive Ratio
2.647
Transmission / Drive
Constant-mesh 6-speed gearbox
Wheel Travel - Rear (mm)
120 mm
Wheel Travel - Rear (in.)
4.7 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (in.)
4.7 inches
Trail (mm)
97 mm
Trail (in.)
3.8 inches
Frame Type
Aluminium composite bridge frame, self-supporting engine
Suspension - Front
Upside-down telescopic fork, slide tube diameter 45 mm, spring preload, compression and rebound stage adjustable, DDC option: damping electronically adjustable
Suspension - Rear
Aluminium underslung double-sided swinging arm with central spring strut, spring preload, adjustable compression and rebound stage, DDC option: damping electronically adjustable
Rake
23.5°
Steering Head Angle
66.9°
Trail
93.9 mm / 3.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
117 mm / 4.6 in
Traction control
BMW Motorrad DTC
Brakes - Front
2x 320mm floating disc, radial 4-piston fixed calipers
Brakes - Rear
Single 220 mm disk, single-piston floating caliper
ABS
BMW Motorrad ABS Pro (part integral, disengageable)
Rims
Die-cast aluminium wheels
Tyres - Front
120/70 ZR17
Tyres - Rear
190/55 ZR17
Wheels
Standard: Die-cast aluminium wheels Forged aluminium wheels as part of Race Package option Carbon fibre wheels as part of M Package option
Wheels - Front
3.50 x 17
Wheels - Rear
6.00 x 17
