Key Specifications
Fuel Capacity
18.35 litres / 4.85 gallons
Advertisement
Full 2005 Yamaha YZF-R1 Specifications
Colours
Team Yamaha Blue/White; Liquid Silver/Cerulean Silver; Shift Red
Seat Height
833 mm / 32.8 in.
Wheelbase
1,394 mm / 54.9 in.
Length
2,065 mm / 81.3 in.
Fuel Capacity
18.35 litres / 4.85 gallons
Bore x Stroke (in,)
3.0 x 2.1 inches
Bore x Stroke (mm)
77.0 x 53.6 mm
Displacement (cc)
998.00 cc
Displacement (ci)
60.90 cubic inches
Engine Type
In-line four
Fuel Control
DOHC
Stroke
4
Fuel System
Injection
Compression Ratio
12.4:1
Valve System
5
Final Drive
Chain
Gearbox
6-speed
Suspension - Front
43mm inverted telescopic fork w/adjustable preload, compression and rebound damping; 4.7´ travel
Suspension - Rear
Single shock w/piggyback reservoir and adjustable preload, compression and rebound damping; 5.1´ travel
Rake
24.0°
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Rear Diameter (mm)
220 mm
Brakes - Front
Double disc
Brakes - Rear
Single disc
Tyres - Front
120/70-ZR17
Tyres - Rear
180/55-ZR17
