Key Specifications
Engine
In-line four, four-stroke
Fuel Capacity
17.78 litres
Advertisement
Full 2010 Honda CBR1000RR Specifications
Colours
Red/Black, Pearl Orange/Light Silver Metallic
Wheelbase (mm)
1,407 mm
Wheelbase (in.)
55.4 inches
Seat Height (mm)
820 mm
Seat Height (in.)
32.3 inches
Wet Weight (lbs.)
439.0 pounds
Wet Weight (kg)
199.1 kg
Fuel Capacity (l)
17.78 litres
Fuel Capacity (gal.)
4.70 gallons
Dry Weight (lbs.)
705.5 pounds
Dry Weight (kg)
320
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
60.96 cubic inches
Displacement (cc)
999.00 cc
CO2
147.3 CO
Bore x Stroke (mm)
76.0 x 55.1 mm
Bore x Stroke (in,)
3.0 x 2.2 inches
Fuel System
Injection. Dual Stage Fuel Injection (DSFI)
Compression Ratio
12.3:1
Fuel Consumption
6.35 litres/100 km (15.7 km/l or 37.04 mpg)
Ignition
Computer-controlled digital transistorized with three-dimensional mapping
Valve System
4
Final Drive
Chain
Gearbox
6-speed
Trail (in.)
3.8 inches
Trail (mm)
96 mm
Wheel Travel - Front (in.)
4.3 inches
Wheel Travel - Front (mm)
109 mm
Wheel Travel - Rear (in.)
5.4 inches
Wheel Travel - Rear (mm)
137 mm
Suspension - Front
43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Suspension - Rear
Unit Pro-Link HMAS single shock with spring preload rebound and compression-damping adjustability
Rake
23.3°
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Rear Diameter (mm)
220 mm
Brakes - Front
Double disc
Brakes - Rear
Single disc
Tyres - Front
120/70-ZR17
Tyres - Rear
190/50-ZR17
