2016 Honda CBR 1000RR Fireblade Specifications

Name: 2016 Honda CBR 1000RR Fireblade
Brand: Honda

No images available

Tap to enlarge

2016 Honda CBR 1000RR Fireblade Overview

The 2016 Honda CBR 1000RR Fireblade is a sport motorcycle built around 999.8 cc of displacement. Under the tank sits a Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder engine, a compression ratio of 12.3:1. 2016 Honda CBR 1000RR Fireblade delivers 133 kW @ 12250rpm of peak power and 114 Nm @ 10500rpm of torque. From a practical standpoint, the 2016 CBR 1000RR Fireblade tips the scales at 201 kg, carries a 19.3-litre fuel tank, offers a seat height of 817.8 mm and spans a 1409.7 mm wheelbase. Scroll down for the complete 2016 Honda CBR 1000RR Fireblade spec sheet covering every technical detail from suspension travel to tyre sizes.

2016 CBR 1000RR Fireblade - Pros & Cons

Strengths

Strong power output: 2016 Honda CBR 1000RR Fireblade makes 133 kW @ 12250rpm with 114 Nm @ 10500rpm of torque - competitive figures for its class.

Considerations

Age-related wear: As with any used CBR 1000RR Fireblade, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.

Owner Experiences & Common Issues

General ownership notes

The 2016 Honda CBR 1000RR Fireblade has built a reputation for solid everyday reliability when serviced to schedule. As with any motorcycle of this era, documented service history is the single biggest indicator of long-term reliability when buying used.

CBR 1000RR Fireblade - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2016 Honda CBR 1000RR Fireblade, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained CBR 1000RR Fireblade should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any CBR 1000RR Fireblade. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

2016 Honda CBR 1000RR Fireblade - Frequently Asked Questions

What engine does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade uses a Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder engine with 999.8 cc of displacement. It is liquid cooled.

How much does the 2016 Honda CBR 1000RR Fireblade weigh?

The 2016 Honda CBR 1000RR Fireblade weighs 201 kg. This is the manufacturer's wet figure.

How much power does the 2016 Honda CBR 1000RR Fireblade make?

The 2016 Honda CBR 1000RR Fireblade produces 133 kW @ 12250rpm of power and 114 Nm @ 10500rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2016 Honda CBR 1000RR Fireblade?

The 2016 Honda CBR 1000RR Fireblade has a 19.3-litre fuel tank.

Is the 2016 Honda CBR 1000RR Fireblade suitable for shorter riders?

The 2016 Honda CBR 1000RR Fireblade has a seat height of 817.8 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade uses 2x Floating 320mm discs Brembo four-piston calipers at the front and Single 220mm disc, 1 piston caliper at the rear.

What tyre sizes does the 2016 Honda CBR 1000RR Fireblade use?

The 2016 Honda CBR 1000RR Fireblade runs 120/70-17 Pirelli Diablo Supercorsa SC front and 190/50-17 Pirelli Diablo Supercorsa SC rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade is fitted with a Close-ratio 6 Speed transmission.

Honda CBR 1000RR Fireblade Spec Evolution

The Honda CBR 1000RR Fireblade was produced across 7 model years (2005-2019). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2005	2006	2013	2016	2017	2018	2019
Max Power	126,4 kW / 172 hp @ 11250 rpm	126,4 kW /172 hp @ 11250 rpm	175.6 hp / 131.0 kW @ 12000 rpm	133 kW / 178 hp @ 12250rpm	141 kW / 189 hp @ 13000rpm	141 kW / 189 hp @ 13000rpm	141 kW / 189 hp @ 13000rpm
Wet Weight	205 kg / 450 lbs	202 kg / 445 lbs	195 kg / 430 lbs (209 kg / 461.7 lbs C-ABS)	201 kg / 444 lbs	196 kg / 432 lbs	196 kg / 432 lbs	195 kg / 430 lbs
Dry Weight	179 kg / 394.6 lbs	176 kg / 388 lbs	173 kg / 381.3 lbs	-	-	-	-
Engine Detail	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.
Top Speed	284.3 km/h / 176.6 mph	277.7 km/h	287.1 km/h / 178.3 mph	-	-	-	-
Seat Height	828 mm / 32.3 in	828 mm / 32.3 in	820 mm / 32.3 in	817.8 mm / 32.2 in	8352 mm / 32.7 in	8352 mm / 32.7 in	8352 mm / 32.7 in
Fuel Capacity	18 Litres / 4.8 gal	18 Litres / 4.8 gal	17.7 Liters / 4.7 gal	19.3 Liters / 4.4 gal	16 Litres / 4.2 US gal	16 Litres / 4.2 US gal	16 Litres / 4.2 US gal
Frame Type	Aluminium, twin spar	Aluminium, twin spar	Diamond; aluminium composite twin-spar	Diamond; aluminium composite twin-spar	Diamond; aluminium composite twin spar	Diamond; aluminium composite twin spar	Diamond; aluminium composite twin spar

Key Specifications

Engine

Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder

Power

133 kW / 178 hp @ 12250rpm

Torque

114 Nm / 84.07 ft.lb @ 10500rpm

Top Speed

N/A

Weight

201 kg / 444 lbs

Fuel Capacity

19.3 Liters / 4.4 gal

Full 2016 Honda CBR 1000RR Fireblade Specifications

Year 2016

Make Model Honda CBR1000RR Fireblade

Max Power 133 kW / 178 hp @ 12250rpm

Max Torque 114 Nm / 84.07 ft.lb @ 10500rpm

Displacement 999.8 cc / 60.9 cu-in

Engine Detail Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder

Bore x Stroke 76 x 55.1 mm

Compression Ratio 12.3:1

Cooling System Liquid cooled

Fuel Induction Programmed Dual Stage Fuel Injection (PGM-DSFI) with 46mm throttle bodies, Denso 12-hole injectors

Ignition Computer-controlled digital transistorized with 3-D mapping

Starter Electric
