2016 Honda CBR 1000RR Fireblade Specifications

Name: 2016 Honda CBR 1000RR Fireblade
Brand: Honda

Sport • Specs last verified 13 July 2026

No images available

Tap to enlarge

2016 Honda CBR 1000RR Fireblade Overview

The 2016 Honda CBR 1000RR Fireblade is a sport motorcycle built around 999.8 cc of displacement. Under the tank sits a Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder engine, a compression ratio of 12.3:1. 2016 Honda CBR 1000RR Fireblade delivers 133 kW @ 12250rpm of peak power and 114 Nm @ 10500rpm of torque. From a practical standpoint, the 2016 CBR 1000RR Fireblade tips the scales at 201 kg, carries a 19.3-litre fuel tank, offers a seat height of 817.8 mm and spans a 1409.7 mm wheelbase. Scroll down for the complete 2016 Honda CBR 1000RR Fireblade spec sheet covering every technical detail from suspension travel to tyre sizes.

2016 CBR 1000RR Fireblade - Pros & Cons

Strengths

Strong power output: 2016 Honda CBR 1000RR Fireblade makes 133 kW @ 12250rpm with 114 Nm @ 10500rpm of torque - competitive figures for its class.
Fuel injection: The Programmed Dual Stage Fuel Injection (PGM-DSFI) with 46mm throttle bodies system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
Large fuel range: The 19.3-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.

Considerations

Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.

Wear Points & Servicing Notes

Cooling system servicing

The Liquid cooled system on the CBR 1000RR Fireblade needs a coolant change roughly every two years (or per the service schedule) - skipping it lets the coolant turn acidic and corrode the aluminium water passages over time.

Fuelling & injector care

Fuelling comes from Programmed Dual Stage Fuel Injection (PGM-DSFI) with 46mm throttle bodies. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.

Brake disc and pad wear

The 2x Floating 320mm discs Brembo four-piston calipers front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Suspension condition on used examples

Up front, the CBR 1000RR Fireblade runs 43mm Öhlins inverted fork with spring preload, rebound and compression damping adjustability and Pro-Link Öhlins shock with spring preload, rebound and compression damping adjustability at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.

Final drive maintenance

Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.

Frame & chassis check

The frame is Diamond; aluminium composite twin-spar - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.

CBR 1000RR Fireblade - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2016 Honda CBR 1000RR Fireblade, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained CBR 1000RR Fireblade should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any CBR 1000RR Fireblade. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

Fuel system care

The CBR 1000RR Fireblade's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.

2016 Honda CBR 1000RR Fireblade - Frequently Asked Questions

What engine does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade uses a Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder engine with 999.8 cc of displacement. It is liquid cooled.

How much does the 2016 Honda CBR 1000RR Fireblade weigh?

The 2016 Honda CBR 1000RR Fireblade weighs 201 kg. This is the manufacturer's wet figure.

How much power does the 2016 Honda CBR 1000RR Fireblade make?

The 2016 Honda CBR 1000RR Fireblade produces 133 kW @ 12250rpm of power and 114 Nm @ 10500rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2016 Honda CBR 1000RR Fireblade?

The 2016 Honda CBR 1000RR Fireblade has a 19.3-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 321-386 km between stops.

Is the 2016 Honda CBR 1000RR Fireblade suitable for shorter riders?

The 2016 Honda CBR 1000RR Fireblade has a seat height of 817.8 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade uses 2x Floating 320mm discs Brembo four-piston calipers at the front and Single 220mm disc, 1 piston caliper at the rear.

What tyre sizes does the 2016 Honda CBR 1000RR Fireblade use?

The 2016 Honda CBR 1000RR Fireblade runs 120/70-17 Pirelli Diablo Supercorsa SC front and 190/50-17 Pirelli Diablo Supercorsa SC rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2016 Honda CBR 1000RR Fireblade have?

The 2016 Honda CBR 1000RR Fireblade is fitted with a Close-ratio 6 Speed transmission.

Honda CBR 1000RR Fireblade Spec Evolution

The Honda CBR 1000RR Fireblade was produced across 7 model years (2005-2019). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2005	2006	2013	2016	2017	2018	2019
Max Power	126,4 kW / 172 hp @ 11250 rpm	126,4 kW /172 hp @ 11250 rpm	175.6 hp / 131.0 kW @ 12000 rpm	133 kW / 178 hp @ 12250rpm	141 kW / 189 hp @ 13000rpm	141 kW / 189 hp @ 13000rpm	141 kW / 189 hp @ 13000rpm
Wet Weight	205 kg / 450 lbs	202 kg / 445 lbs	195 kg / 430 lbs (209 kg / 461.7 lbs C-ABS)	201 kg / 444 lbs	196 kg / 432 lbs	196 kg / 432 lbs	195 kg / 430 lbs
Dry Weight	179 kg / 394.6 lbs	176 kg / 388 lbs	173 kg / 381.3 lbs	-	-	-	-
Engine Detail	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, Chain-driven DOHC, 4 valve per cylinder.
Top Speed	284.3 km/h / 176.6 mph	277.7 km/h	287.1 km/h / 178.3 mph	-	-	-	-
Seat Height	828 mm / 32.3 in	828 mm / 32.3 in	820 mm / 32.3 in	817.8 mm / 32.2 in	8352 mm / 32.7 in	8352 mm / 32.7 in	8352 mm / 32.7 in
Fuel Capacity	18 Litres / 4.8 gal	18 Litres / 4.8 gal	17.7 Liters / 4.7 gal	19.3 Liters / 4.4 gal	16 Litres / 4.2 US gal	16 Litres / 4.2 US gal	16 Litres / 4.2 US gal
Frame Type	Aluminium, twin spar	Aluminium, twin spar	Diamond; aluminium composite twin-spar	Diamond; aluminium composite twin-spar	Diamond; aluminium composite twin spar	Diamond; aluminium composite twin spar	Diamond; aluminium composite twin spar

Key Specifications

Engine

Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder

Power

133 kW / 178 hp @ 12250rpm

Torque

114 Nm / 84.07 ft.lb @ 10500rpm

Top Speed

Not published by manufacturer

Weight

201 kg / 444 lbs

Fuel Capacity

19.3 Liters / 4.4 gal

Full 2016 Honda CBR 1000RR Fireblade Specifications

Year 2016

Make Model Honda CBR1000RR Fireblade

Seat Height 817.8 mm / 32.2 in

Wheelbase 1409.7 mm / 55.5 in

Height 1141mm / 44.9 in

Length 2080 mm / 81.8 in

Width 720 mm / 28.3 in

Fuel Capacity 19.3 Liters / 4.4 gal

Oil Capacity 3.7 Litres

Wet Weight 201 kg / 444 lbs

Max Power 133 kW / 178 hp @ 12250rpm

Max Torque 114 Nm / 84.07 ft.lb @ 10500rpm

Displacement 999.8 cc / 60.9 cu-in

Engine Detail Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder

Bore x Stroke 76 x 55.1 mm

Compression Ratio 12.3:1

Cooling System Liquid cooled

Fuel Induction Programmed Dual Stage Fuel Injection (PGM-DSFI) with 46mm throttle bodies, Denso 12-hole injectors

Ignition Computer-controlled digital transistorized with 3-D mapping

Starter Electric

Clutch Wet, multiplate with diaphragm spring

Final Drive #530 O-ring-sealed chain

Transmission / Drive Close-ratio 6 Speed

Frame Type Diamond; aluminium composite twin-spar

Suspension - Front 43mm Öhlins inverted fork with spring preload, rebound and compression damping adjustability

Suspension - Rear Pro-Link Öhlins shock with spring preload, rebound and compression damping adjustability

Rake 23.3°

Trail 96.2mm / 3.8 in

Brakes - Front 2x Floating 320mm discs Brembo four-piston calipers

Brakes - Rear Single 220mm disc, 1 piston caliper

ABS Electronic Combined ABS

Rims 12-spoke cast aluminium

Tyres - Front 120/70-17 Pirelli Diablo Supercorsa SC

Tyres - Rear 190/50-17 Pirelli Diablo Supercorsa SC

Wheels - Front 17M/C x MT3.5

Wheels - Rear 17M/C x MT6

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
