Yamaha FZ1 Specs

2005–2011 • 5 variants

First introduced in 2005, the Yamaha FZ1 is a sport motorcycle that has seen 5 variants through 2011. The engine is a high silicon-content ceramic-composite cylinder lining. at 998.00 cc.

About the Yamaha FZ1

Documented here are the full technical specifications for the Yamaha FZ1, a Naked bike motorcycle with a production run from 2005 to 2017. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

Yamaha FZ1 by Year

2011 Yamaha FZ1 View specs →

2009 Yamaha FZ1 View specs →

2008 Yamaha FZ1 View specs →

2007 Yamaha FZ1 View specs →

2005 Yamaha FZ1 View specs →

Spec Evolution

How key specs changed across production years.

Specification	2005	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017
Bore x Stroke (in,)	2.9 x 2.3 inches	3.0 x 2.1 inches ↑	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches
Bore x Stroke (mm)	74.0 x 58.0 mm	77.0 x 53.6 mm ↑	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm
Brakes - Front Diameter (in.)	11.7 inches	12.6 inches ↑	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches	12.6 inches
Ground Clearance (mm)	-	135 mm	-	-	-	140 mm	135 mm ↓	135 mm	135 mm	135 mm	135 mm	135 mm	135 mm
Ground Clearance (in.)	-	5.3 inches	-	-	-	5.5 inches	5.3 inches ↓	5.3 inches	5.3 inches	5.3 inches	5.3 inches	5.3 inches	5.3 inches
Fuel Control	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Engine Type	In-line four	In-line four	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke
Brakes - Front Diameter (mm)	298 mm	320 mm ↑	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm	320 mm
Brakes - Rear Diameter (in.)	10.5 inches	9.6 inches ↓	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches	9.6 inches
Brakes - Rear Diameter (mm)	267 mm	245 mm ↓	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm	245 mm
Comments	-	-	-	-	-	-	-	-	-	4500 Ah Lithium Polymer battery. Range 75km. XOR is an abbreviation of Xtraordinary Object on Road. Foldable bike. French brand.	-	Windscreen	Windscreen
CO2	-	-	-	-	155.9 CO	155.9 CO	155.9 CO	155.9 CO	155.9 CO	155.9 CO	155.9 CO2 g/km. (CO2 - Carbon dioxide emission)	155.9 CO2 g/km. (CO2 - Carbon dioxide emission)	155.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Frame Type	-	-	-	-	-	-	Aluminium die-cast, Diamond Shaped	-	-	-	-	Aluminum	Aluminum
Seat Height	820 mm / 32.3 in.	815 mm / 32.1 in. ↓	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.
Dry Weight	208.2 kg / 459.0 lbs	198 kg / 436.5 lbs ↓	198.7 kg / 438.0 lbs ↑	199.1 kg / 439.0 lbs ↑	-	-	230 kg / 507.0 lbs	-	210.5 kg / 464.1 lbs	59 kg / 130.1 lbs ↓	-	-	-
Brakes - Front	Double disc	Double disc	Double disc	Double disc	Double disc	Double disc	Double disc. Floating discs w/4-piston calipers	Double disc. Floating discs w/4-piston calipers	Double disc. Floating disc. Four-piston calipers.	Double disc. Floating disc. Four-piston calipers.	Double disc. Floating discs. Four-piston calipers.	Double disc. Floating discs. Four-piston calipers.	Double disc. Floating discs. Four-piston calipers.
Wheelbase	1,450 mm / 57.1 in.	1,460 mm / 57.5 in. ↑	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.	1,461 mm / 57.5 in.
Engine Detail	-	-	-	-	-	-	-	Titanium intake valves	-	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.
Brakes - Rear	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc. Single-piston caliper.	Single disc. Single-piston caliper.	Single disc. Single-piston caliper.	Single disc. Single-piston caliper.	Single disc. Single-piston caliper.
Fuel Capacity	5.60 litres / 1.48 gallons	18.00 litres / 4.76 gallons ↑	17.97 litres / 4.75 gallons ↓	17.97 litres / 4.75 gallons	17.97 litres / 4.75 gallons	18.01 litres / 4.76 gallons ↑	18.02 litres / 4.76 gallons	18.17 litres / 4.80 gallons ↑	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons
Suspension - Front	43mm telescopic fork w/adjustable preload, compression and rebound damping	Telescopic upside down forks	43mm telescopic fork w/adjustable preload, compression and rebound damping	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork	43mm fork
Suspension - Rear	Single shock w/piggyback reservoir and adjustable preload, compression and rebound damping	Swingarm (link suspension)	Single shock w/ piggyback reservoir	Single shock	Single shock	Single shock	Single shock	Single shock	Single shock	Single shock	Single shock, adjustable preload and rebound damping, 5.1-in travel	Single shock, adjustable preload and rebound damping, 5.1-in travel	Single shock, adjustable preload and rebound damping, 5.1-in travel
Fuel System	Carburettor. (4) 37mm Mikuni CV w/throttle position sensor (TPS)	Injection. Grouped injected fuel injection	Injection	Injection	Injection	Injection	Injection	Injection	Injection	Injection	Injection	Injection	Injection
Colours	Team Yamaha Blue, Liquid Silver	-	Raven, Cobalt blue	Grey, Red	Cobalt Blue, Granite Gray/Raven	Raven, Candy red	Liquid Silver	Pearl White/Matte Black	Cobalt Blue	Pearl White	Granite Gray	Granite Gray	Granite Gray
Clutch	Multiplate	Wet, multiple-disc	-	-	-	-	Wet, multiple-disc coil spring	-	-	No clutch	-	-	-
Height	1,191 mm / 46.9 in.	1,205 mm / 47.4 in. ↑	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.	1,204 mm / 47.4 in.
Length	2,126 mm / 83.7 in.	2,140 mm / 84.3 in. ↑	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.	2,141 mm / 84.3 in.
Compression Ratio	11.4:1	11.5:1 ↑	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1	11.5:1
Warranty	-	-	-	-	-	-	1 Year (Limited Factory Warranty)	1 Year (Limited Factory Warranty)	1 Year (Limited Factory Warranty)	1 Year (Limited Factory Warranty)	1 Year Limited Factory Warranty	1 Year Limited Factory Warranty	1 Year Limited Factory Warranty
Wet Weight	-	-	-	-	220.0 kg / 485.0 lbs	220.9 kg / 487.0 lbs ↑	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs
Emissions	-	-	-	-	-	-	Three-way catalyst technology	-	-	No direct emission	-	-	-
Tyres - Front	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17
Gearbox	6-speed	5-speed ↓	6-speed ↑	6-speed	6-speed	6-speed	6-speed	6-speed	6-speed	6-speed	6-speed	6-speed	6-speed
Width	765 mm / 30.1 in.	770 mm / 30.3 in. ↑	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.	770 mm / 30.3 in.
Tyres - Rear	180/55-ZR17	190/50-ZR17 ↑	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17	190/50-ZR17
Rake	26.0°	-	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°	25.0°
Exhaust	-	-	-	-	-	-	-	-	-	Four-into two-into one short-style exhaust system	-	Four-into two-into one short-style exhaust	Four-into two-into one short-style exhaust
Instrumentation	-	-	-	-	-	-	-	Speedometer, odometer and fuel gauge	-	Analog tachometer, digital speedometer, dual trip meter with miles on reserve function, odometer, water temperature and lights for neutral, high beam, low fuel and turn signals	Analog tachometer, digital speedometer, dual trip meter with miles on reserve function, odometer, water temperature and lights for neutral, high beam, low fuel and turn signals	Analog tachometer, digital speedometer, dual trip meter with miles on reserve function, odometer, water temperature and lights for neutral, high beam, low fuel and turn signals	Analog tachometer, digital speedometer, dual trip meter with miles on reserve function, odometer, water temperature and lights for neutral, high beam, low fuel and turn signals
Seat	-	-	-	-	-	-	-	-	2-person seat	Two-piece seat	Two-piece seat	Two-piece seat	Two-piece seat
Lighting system	-	-	-	-	-	-	Dual 30W Krypton Multi-reflector Headlights and 21/5W Brake light	Dual 30W Krypton multireflector headlights and 21/5W brakelight	-	LED lights	-	-	-
Trail	104 mm / 4.1 in.	-	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.	109 mm / 4.3 in.
Wheel Travel - Front	142 mm / 5.6 in.	130 mm / 5.1 in. ↓	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	147 mm / 5.8 in. ↑	130 mm / 5.1 in. ↓	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.
Wheel Travel - Rear	135 mm / 5.3 in.	125 mm / 4.9 in. ↓	130 mm / 5.1 in. ↑	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	193 mm / 7.6 in. ↑	130 mm / 5.1 in. ↓	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.
Ignition	Digital TCI	TCI (digital)	Digital TCI	Digital TCI	TCI: Transistor Controlled Ignition	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU	Digital TCI: Transistor Controlled Ignition with 32-bit ECU
Max Torque	-	106.00	-	-	-	-	115.00 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 10000	-	-	-	-	-	-
Power-to-Weight Ratio	-	0.7470 HP/kg	-	-	-	-	-	-	0.1143 HP/kg	0.1819 HP/kg ↑	-	-	-
Valve System	-	-	-	5	4 ↓	5 ↑	5	-	5	5	4 ↓	4	5 ↑
