2011 Yamaha FZ1 Specifications

Name: 2011 Yamaha FZ1
Brand: Yamaha

Naked bike • Specs last verified 13 July 2026

No images available

Tap to enlarge

2011 Yamaha FZ1 Overview

Yamaha FZ1 is a naked bike motorcycle, displacing 998 cc. Power comes from an In-line four, four-stroke engine running DOHC valve actuation, a compression ratio of 11.5:1. Bore and stroke come in at 77 x 53.6 mm. On the performance side, it delivers 115 Nm @ 10000 of torque. On the road, the 2011 FZ1 tips the scales at 220.9 kg, carries a 18.02-litre fuel tank, offers a seat height of 815 mm and spans a 1,461 mm wheelbase. That's roughly 15 kg heavier than the average naked bike motorcycle in our database. The full 2011 Yamaha FZ1 spec sheet below covers every technical detail, from suspension travel to tyre sizes.

2011 FZ1 - Pros & Cons

Strengths

Fuel injection: Fuel injection means consistent cold starts and clean throttle response without the fussiness of a carbureted setup.
Large fuel range: A 18.02-litre tank means fewer stops on longer rides - a genuine plus for touring or a lengthy daily commute.

Considerations

Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.

Wear Points & Servicing Notes

Fuelling & injector care

The fuel injection on the FZ1 needs little beyond good fuel and periodic use of an injector-cleaner additive - no jetting or float-bowl maintenance to worry about.

Valve clearance checks

With DOHC valve gear, the FZ1 needs periodic clearance checks; caught early they're a cheap adjustment, left unchecked they accelerate valve seat wear.

Brake disc and pad wear

Braking up front comes from Double disc. Floating discs w/4-piston calipers - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.

Suspension condition on used examples

The FZ1's suspension runs 43mm fork at the front. The rear uses Single shock. Fork-seal condition and rear linkage play are the two things worth checking before buying used.

Final drive maintenance

The FZ1 uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.

Frame & chassis check

Built around a Aluminium die-cast, Diamond Shaped, the FZ1's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.

Handling the weight at a standstill

220.9 kg puts the FZ1 toward the heavier end of its class. It's most noticeable at walking pace; once underway the mass settles into the handling rather than fighting it.

FZ1 - Buying & Maintenance Guide

What to check before buying

Before handing over money for a used 2011 Yamaha FZ1, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy FZ1 should catch quickly and settle into a smooth idle.

Oil and filter changes

Nothing protects a FZ1's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). The sump holds 3.70 litres, so budget for that volume of quality motorcycle-specific engine oil. Match the viscosity grade to what the owner's manual specifies, not what's cheapest.

Fuel system care

Fuel injection on the FZ1 needs little attention beyond decent fuel and an occasional system-cleaner additive. Anything left standing for three months or more should have its fuel drained and replaced before it varnishes the injectors.

Valve clearance service

Valve clearances are easy to overlook on a used FZ1 since a bike out of spec doesn't always feel obviously wrong - but the wear it causes is real. Ask the seller for documentation before assuming it's been done.

2011 Yamaha FZ1 - Frequently Asked Questions

What engine does the 2011 Yamaha FZ1 have?

The 2011 Yamaha FZ1 uses an In-line four, four-stroke engine with 998 cc of displacement.

How much does the 2011 Yamaha FZ1 weigh?

The 2011 Yamaha FZ1 weighs 220.9 kg. This is the manufacturer's wet figure.

How much power does the 2011 Yamaha FZ1 make?

The 2011 Yamaha FZ1 produces 115 Nm @ 10000 of torque.

What is the fuel tank capacity of the 2011 Yamaha FZ1?

The 2011 Yamaha FZ1 has a 18.02-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 300-360 km between stops.

Is the 2011 Yamaha FZ1 suitable for shorter riders?

The 2011 Yamaha FZ1 has a seat height of 815 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2011 Yamaha FZ1 have?

The 2011 Yamaha FZ1 uses Double disc. Floating discs w/4-piston calipers at the front and Single disc at the rear.

What tyre sizes does the 2011 Yamaha FZ1 use?

The 2011 Yamaha FZ1 runs 120/70-ZR17 front and 190/50-ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

How much oil does the 2011 Yamaha FZ1 take?

The 2011 Yamaha FZ1 takes 3.70 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.

Yamaha FZ1 Spec Evolution

The Yamaha FZ1 was produced across 13 model years (2005-2017). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2005	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017
Wet Weight	-	-	-	-	220.0 kg / 485.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs	220.9 kg / 487.0 lbs
Dry Weight	208.2 kg / 459.0 lbs	198 kg / 436.5 lbs	198.7 kg / 438.0 lbs	199.1 kg / 439.0 lbs	-	-	230 kg / 507.0 lbs	-	210.5 kg / 464.1 lbs	59 kg / 130.1 lbs	-	-	-
Engine Detail	-	-	-	-	-	-	-	Titanium intake valves	-	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.	High silicon-content ceramic-composite cylinder lining.
Engine Type	In-line four	In-line four	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke
Seat Height	820 mm / 32.3 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.	815 mm / 32.1 in.
Fuel Capacity	5.60 litres / 1.48 gallons	18.00 litres / 4.76 gallons	17.97 litres / 4.75 gallons	17.97 litres / 4.75 gallons	17.97 litres / 4.75 gallons	18.01 litres / 4.76 gallons	18.02 litres / 4.76 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons	18.17 litres / 4.80 gallons
Bore x Stroke (in,)	2.9 x 2.3 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches	3.0 x 2.1 inches
Bore x Stroke (mm)	74.0 x 58.0 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm	77.0 x 53.6 mm

Key Specifications

Engine

In-line four, four-stroke

Power

Not published by manufacturer

Torque

115.00 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 10000

Top Speed

Not published by manufacturer

Weight

220.9 kg / 487.0 lbs

Fuel Capacity

18.02 litres / 4.76 gallons

Full 2011 Yamaha FZ1 Specifications

Colours Liquid Silver

Warranty 1 Year (Limited Factory Warranty)

Ground Clearance (mm) 135 mm

Ground Clearance (in.) 5.3 inches

Seat Height 815 mm / 32.1 in.

Wheelbase 1,461 mm / 57.5 in.

Height 1,204 mm / 47.4 in.

Length 2,141 mm / 84.3 in.

Width 770 mm / 30.3 in.

Oil Capacity (Quarts) 0.24 quarts

Oil Capacity (l) 3.70 litres

Dry Weight 230 kg / 507.0 lbs

Fuel Capacity 18.02 litres / 4.76 gallons

Wet Weight 220.9 kg / 487.0 lbs

Max Torque 115.00 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 10000

Fuel Control DOHC

Engine Type In-line four, four-stroke

Displacement (ci) 60.90 cubic inches

Displacement (cc) 998.00 cc

CO2 155.9 CO

Bore x Stroke (mm) 77.0 x 53.6 mm

Bore x Stroke (in,) 3.0 x 2.1 inches

Fuel System Injection

Compression Ratio 11.5:1

Emissions Three-way catalyst technology

Engine Lubrication Wet sump

Fuel Consumption 6.72 litres/100 km (14.9 km/l or 35.00 mpg)

Ignition Digital TCI: Transistor Controlled Ignition with 32-bit ECU

Starter Electric

Valve System 5

Clutch Wet, multiple-disc coil spring

Final Drive Chain

Gearbox 6-speed

Primary Drive O-ring chain

Frame Type Aluminium die-cast, Diamond Shaped

Suspension - Front 43mm fork

Suspension - Rear Single shock

Rake 25.0°

Trail 109 mm / 4.3 in.

Wheel Travel - Front 130 mm / 5.1 in.

Wheel Travel - Rear 130 mm / 5.1 in.

Lighting system Dual 30W Krypton Multi-reflector Headlights and 21/5W Brake light

Brakes - Front Diameter (in.) 12.6 inches

Brakes - Front Diameter (mm) 320 mm

Brakes - Rear Diameter (in.) 9.6 inches

Brakes - Rear Diameter (mm) 245 mm

Brakes - Front Double disc. Floating discs w/4-piston calipers

Brakes - Rear Single disc

Tyres - Front 120/70-ZR17

Tyres - Rear 190/50-ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
