Engine Type
|
Twin | Two cylinder boxer | Two cylinder boxer, two-stroke | Two cylinder boxer, four-stroke |
|
Frame Type
|
Main and front frame made of steel tubes, rear frame made of square aluminium tubes, engine with load-bearing function | Main and front frame made of steel tubes, rear frame made of square aluminium tubes, engine with load-bearing function | Main and front frame made of steel tubes, rear frame made of square aluminium tubes, engine with load-bearing function | Three-section frame consisting of front, middle and rear sections, load bearing engine-gearbox unit |
|
Dry Weight
|
190 kg / 418.8 lbs | 190 kg / 418.8 lbs | 190 kg / 418.8 lbs | 190 kg / 418.9 lbs |
|
Seat Height
|
820 mm / 32.2 in | 820 mm / 32.2 in | 820 mm / 32.2 in | 830 mm / 32.7 in. ↑ |
|
Wheelbase
|
1487 mm / 58.5 in | 1487 mm / 58.5 in | 1487 mm / 58.5 in | 1,487 mm / 58.5 in. ↓ |
|
Brakes - Front
|
2 x 320mm Discs, 2 piston caliper | 2 x 320mm Discs, 2 piston caliper | 2 x 320mm Discs, 2 piston caliper | Double disc. Optional ABS |
|
Brakes - Rear
|
Single 265mm disc, 1 piston caliper | Single 265mm disc, 1 piston caliper | Single 265mm disc, 1 piston caliper | Single disc. Optional ABS |
|
Fuel Capacity
|
17 Litres / 4.2 US gal | 17 Litres / 4.2 US gal | 17 Litres / 4.2 US gal | 17.00 litres / 4.49 gallons |
|
Suspension - Front
|
BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut | BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut | BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut | BMW Motorrad Telelever |
|
Top Speed
|
241.3 km/h / 149.9 mph | 241.3 km/h / 149.9 mph | 241.3 km/h / 149.9 mph | 200.0 km/h / 124.3 mph ↓ |
|
Suspension - Rear
|
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; WAD spring strut (travel-dependent damping), adjustable spring preload continuously variable, rebound damping adjustable | Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; WAD spring strut (travel-dependent damping), adjustable spring preload continuously variable, rebound damping adjustable | Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; WAD spring strut (travel-dependent damping), adjustable spring preload continuously variable, rebound damping adjustable | Cast aluminium single-sided swing arm with BMW Motorrad Paralever |
|
Fuel System
|
Injection. Electronic intake pipe injection/digital engine management: BMW engine management, BMS-K with overrun fuel cut-off, dual ignition | Injection | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition |
|
Clutch
|
Hydraulic, dry, single-disc | Hydraulic, dry, single-disc | Hydraulic, dry, single-disc | Single dry plate clutch, hydraulically operated |
|
Final Drive
|
Shaft | Shaft | Shaft | Shaft drive (cardan) |
|
Height
|
1177 mm / 46.3 in (without mirrors) | 1177 mm / 46.3 in (without mirrors) | 1177 mm / 46.3 in (without mirrors) | 1,177 mm / 46.3 in. ↓ |
|
Length
|
2151 mm / 84.6 in | 2151 mm / 84.6 in | 2151 mm / 84.6 in | 2,151 mm / 84.7 in. ↓ |
|
Wet Weight
|
212 kg / 467.3 lbs | 212 kg / 467.3 lbs | 212 kg / 467.3 lbs | 213.0 kg / 469.6 lbs ↑ |
|
Tyres - Front
|
120/70 ZR 17 | 120/70 ZR 17 | 120/70 ZR 17 | 120/70-ZX17 |
|
Width
|
870 mm / 34.2 in (with mirrors) | 870 mm / 34.2 in (with mirrors) | 870 mm / 34.2 in (with mirrors) | 870 mm / 34.3 in. |
|
Tyres - Rear
|
180/55 ZR 17 | 180/55 ZR 17 | 180/55 ZR 17 | 180/55-ZX17 |
|
Rake
|
24.0° | - | 24.0° | 24.0° |
|
Fuel Consumption
|
7.4 L/100 km13.6 km/l / 32 US mpg | 7.4 L/100 km13.6 km/l / 32 US mpg | 7.4 L/100 km13.6 km/l / 32 US mpg | 4.30 litres/100 km (23.3 km/l or 54.70 mpg) ↓ |
|
Trail
|
87 mm / 3.4 in | 87 mm / 3.4 in | 87 mm / 3.4 in | 87 mm / 3.4 in. |
|
Wheel Travel - Front
|
110 mm / 4.3 in | 110 mm / 4.3 in | 110 mm / 4.3 in | 110 mm / 4.3 in. |
|
Wheel Travel - Rear
|
120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in. |
|
Max Torque
|
112 Nm / 11.4 kgf-m / 83 ft-lb @ 6500 rpm | 112 Nm / 11.4 kgf-m / 83 ft-lb @ 6500 rpm | 112 Nm / 11.4 kgf-m / 83 ft-lb @ 6500 rpm | 112.00 Nm (11.4 kgf-m or 82.6 ft.lbs) @ 6800 |
|
Power-to-Weight Ratio
|
0.6352 HP/kg | 0.6421 HP/kg | 0.6352 HP/kg | 0.6352 HP/kg |
