Key Specifications
Engine
In-line four, four-stroke
Power
136.1 kW / 182.5 hp @ 12000rpm
Torque
117 Nm / 11.9 kg fm / 86.3 lb.ft @ 10000rpm
Top Speed
299 km/h / 185.8 mph
Fuel Capacity
19.00 litres
Full 2013 Suzuki GSX-R 1000 Specifications
Comments
Sold in the Philippines.
Year
2013
Colours
Metallic Triton Blue, Glass Splash White, Metallic Mat Black, Glass Sparkle Black
Make Model
Suzuki GSX-R 1000
Warranty
12 month unlimited mileage limited warranty.
Width (mm)
705 mm
Width (in.)
27.8 inches
Wheelbase (mm)
1,485 mm
Wheelbase (in.)
58.5 inches
Seat Height (mm)
810 mm
Seat Height (in.)
31.9 inches
Length (mm)
2,045 mm
Length (in.)
80.5 inches
Height (mm)
1,050 mm
Height (in.)
41.3 inches
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
810 mm / 31.9 in.
Wheelbase
1405mm / 55.3in
Ground Clearance
130 mm / 5.1 in.
Height
1130 mm / 44.5in
Length
1130 mm / 44.5in
Width
705 mm / 27.8in
Fuel Capacity (l)
19.00 litres
Fuel Capacity (gal.)
5.02 gallons
Oil Capacity (l)
0.90 litres
Oil Capacity (Quarts)
0.06 quarts
Wet Weight (kg)
203.0 kg
Wet Weight (lbs.)
447.5 pounds
Fuel Capacity
17.5 Litres / 4.6 US gal / 3.8 Imp gal
Wet Weight
203 kg / 448 lbs
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
60.96 cubic inches
Displacement (cc)
999.00 cc
Bore x Stroke (mm)
74.5 x 57.3 mm
Bore x Stroke (in,)
2.9 x 2.3 inches
Displacement
998.6 cc / 60.9 cub. in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Fuel System
Injection. Suzuki Fuel Injection
Bore x Stroke
74.5 x 57.3 mm
Compression Ratio
12.9:1
Cooling System
Liquid cooled
Engine Lubrication
Wet sump
Engine Oil Specification
Synthetic, 10W/40
Exhaust
4 into 2 into 1, stainless steel
Fuel Induction
Fuel Injection
Ignition
Electronic ignition Transistorized
Lubrication
Wet sump
Spark Plug
NGK, CR9EIA-9
Starter
Electric
Valve System
4
Clutch
Hydraulically-actuated multiplate wet clutch.
Final Drive
Chain, DID50VAZ, 114 links
Gear Ratios
1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1
Gearbox
6-speed
Primary Drive
Chain, DID50VAZ, 114 links
Transmission / Drive
6 Speed, constant mesh
Frame Type
Aluminium, twin spar
Suspension - Front
Inverted telescopic, coil spring, oil damped
Suspension - Rear
Link type, coil spring, oil damped
Rake
24°
Wheel Travel - Front
125mm / 4.9 in.
Wheel Travel - Rear
130mm / 5.1 in.
Instrumentation
Silver-ringed analog tachometer with LCD speedometer. LCD readouts include odometer, dual trip meters, reserve trip meter, clock, coolant temperature/oil pressure warning indicator, gear position indicator, lap timer/stopwatch, S-DMS setting indic
Brakes - Front
2 x 310 mm Discs radial mount Brembo monobloc 4 piston caliper
Brakes - Rear
Single 220 mm disc
Tyres - Front
120/70 ZR17 M/C (58W), tubeless
Tyres - Rear
190/50 ZR17 M/C (73W), tubeless
