Key Specifications
Power
138 kW / 185.1 hp @ 12000rpm
Torque
117 Nm / 11.9 kgf-m / 86.3 lb.ft @ 10000rpm
Top Speed
290 km/h / 180.2 mph
Fuel Capacity
17.50 litres
Full 2008 Suzuki GSX-R 1000 Specifications
Year
2008
Colours
Blue/White, Black/Gold, White/Silver
Make Model
Suzuki GSX-R 1000
Width (mm)
720 mm
Width (in.)
28.3 inches
Wheelbase (mm)
1,415 mm
Wheelbase (in.)
55.7 inches
Seat Height (mm)
810 mm
Seat Height (in.)
31.9 inches
Length (mm)
2,045 mm
Length (in.)
80.5 inches
Height (mm)
1,130 mm
Height (in.)
44.5 inches
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
810 mm / 31.9 in.
Wheelbase
1415 mm / 55.7 in.
Ground Clearance
130 mm / 5.1 in.
Height
1130 mm / 44.5 in
Length
2045 mm / 80.5 in
Width
720 mm / 28.3 in
Wet Weight (kg)
192
Fuel Capacity (l)
17.50 litres
Fuel Capacity (gal.)
4.62 gallons
Dry Weight (lbs.)
379.2 pounds
Dry Weight (kg)
172
Dry Weight
172 kg / 379 lbs.
Fuel Capacity
17.5 Litres / 4.6 US gal / 3.8 Imp gal
Wet Weight
192 kg / 423 lbs
Stroke
4
Fuel Control
DOHC
Engine Type
In-line four
Displacement (ci)
60.96 cubic inches
Displacement (cc)
999.00 cc
Bore x Stroke (mm)
73.4 x 59.0 mm
Bore x Stroke (in,)
2.9 x 2.3 inches
Displacement
998.6 cc / 60.9 cub. in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Fuel System
Injection
Bore x Stroke
73.4 x 59 mm
Compression Ratio
12.5:1
Cooling System
Liquid cooled
Engine Lubrication
Wet Sump
Engine Oil Specification
Synthetic, 10W/40
Exhaust
4 into 2, stainless steel
Fuel Consumption
5.5 L/100 km / 18.1 km/l / 42.8 US mpg / 51 Imp mpg
Fuel Induction
Electronic Fuel Injection with four 44mm throttle bodies
Ignition
Electronic ignition, Transistorized
Lubrication
Wet sump
Spark Plug
NGK, CR9EIA-9
Starter
Electric
Clutch
Hydraulically-actuated multiplate wet clutch.
Final Drive
#530 chain
Gear Ratios
1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1
Gearbox
6-speed
Transmission / Drive
6 Speed, constant mesh
Frame Type
Aluminium, twin spar
Suspension - Front
Inverted telescopic, coil spring, oil damped, adjustable spring preload
Suspension - Rear
Link type, coil spring, gas/oil damped, adjustable spring preload
Rake
24°
Trail
98 mm / 3.9 in.
Wheel Travel - Front
125mm / 4.9 in.
Wheel Travel - Rear
130 mm / 5.1 in.
Brakes - Front
2 x 310 mm discs 4 piston caliper
Brakes - Rear
Single 220 mm disc
Tyres - Front
120/70 ZR17
Tyres - Rear
190/50 ZR17
Wheels
Cast aluminium alloy, 3 spoke
