Key Specifications
Power
131 kW / 178 hp @ 11000rpm
Torque
118 Nm / 12 kgf-m / 87 ft -lb @ 8500rpm
Top Speed
292.9 km/h / 181.9 mph
Fuel Capacity
18.00 litres
Full 2006 Suzuki GSX-R 1000 Specifications
Year
2006
Colours
Blue/White, Black/Grey, Black/Yellow
Make Model
Suzuki GSX-R 1000
Width (mm)
710 mm
Width (in.)
28.0 inches
Wheelbase (mm)
1,405 mm
Wheelbase (in.)
55.3 inches
Seat Height (mm)
810 mm
Seat Height (in.)
31.9 inches
Length (mm)
2,030 mm
Length (in.)
79.9 inches
Height (mm)
1,130 mm
Height (in.)
44.5 inches
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
810 mm / 31.9 in.
Wheelbase
1405 mm / 55.3 in.
Ground Clearance
125 mm / 4.9 in.
Height
1130 mm / 44.5 in
Length
2030 mm / 79.9 in
Width
710 mm / 28 in
Fuel Capacity (l)
18.00 litres
Fuel Capacity (gal.)
4.76 gallons
Dry Weight (lbs.)
366.0 pounds
Dry Weight (kg)
166
Dry Weight
166 kg / 366 lbs
Fuel Capacity
18 Litres / 4.8 US gal / 4.0 Imp gal
Stroke
4
Fuel Control
DOHC
Engine Type
In-line four
Displacement (ci)
60.93 cubic inches
Displacement (cc)
998.60 cc
Bore x Stroke (mm)
73.4 x 59.0 mm
Bore x Stroke (in,)
2.9 x 2.3 inches
Displacement
998.6 cc / 60.9 cub. in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Fuel System
Injection. Fuel Injection
Bore x Stroke
74.3 x 59 mm
Compression Ratio
12.5:1
Cooling System
Liquid cooled
Engine Lubrication
Wet Sump
Engine Oil Specification
Synthetic, 10W/40
Exhaust
4 into 1 into 2, Stainless steel
Fuel Consumption
6.9 l/100 km / 14.5 km/l / 34 US mpg / 41 Impmpg
Fuel Induction
Electronic Fuel Injection with four 44mm throttle bodies
Fuel Range
195 km / 121 miles
Ignition
Electronic ignition, Transistorized
Lubrication
Wet sump
Spark Plug
NGK, CR9EIA-9
Starter
Electric
Clutch
Cable-operated multiplate wet clutch with back torque limiter
Final Drive
#530 chain
Gear Ratios
1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1
Gearbox
6-speed
Transmission / Drive
6 Speed, constant mesh
Frame Type
Aluminium, twin spar
Suspension - Front
43mm Kayaba inverted cartridge forks with diamond-like coating adjustable for preload, compression and rebound damping
Suspension - Rear
Kayaba monoshock adjustable for ride height, preload, compression and rebound damping
Rake
23.75°
Trail
96 mm / 3.8 in.
Wheel Travel - Front
125mm / 4.9 in.
Wheel Travel - Rear
130 mm / 5.1 in.
Brakes - Front
2 x 310 mm discs, 4 piston caliper
Brakes - Rear
Single 220 mm disc, 2 caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
190/50 ZR17
Wheels
Cast aluminium, 3 spoke
