Key Specifications
Engine
In-line four, four-stroke
Power
118 hp / 88.1 kW @ 13500 rpm
Torque
66 Nm / 48.6 lb-ft @ 11250 rpm
Fuel Capacity
18.17 litres
Advertisement
Full 2014 Honda CBR 600RR Specifications
Comments
Model ID: CBR600RR
Year
2014
Colours
Red, White/Blue/Red, Black
Make Model
Honda CBR 600RR
Warranty
One year. Unlimited milage. Transferable.
Width (mm)
740 mm
Width (in.)
29.1 inches
Wheelbase (mm)
1,369 mm
Wheelbase (in.)
53.9 inches
Seat Height (mm)
820 mm
Seat Height (in.)
32.3 inches
Length (mm)
2,075 mm
Length (in.)
81.7 inches
Height (mm)
1,165 mm
Height (in.)
45.9 inches
Ground Clearance (mm)
140 mm
Ground Clearance (in.)
5.5 inches
Seat Height
820 mm / 32.3 in
Wheelbase
1369 mm / 53.9 in
Ground Clearance
135 mm / 5.3 in
Wet Weight (lbs.)
410.0 pounds
Wet Weight (kg)
186.0 kg
Fuel Capacity (l)
18.17 litres
Fuel Capacity (gal.)
4.80 gallons
Dry Weight (lbs.)
683.4 pounds
Dry Weight (kg)
310
Dry Weight
156.5 kg / 345 lbs
Fuel Capacity
18.2 liters / 4.8 gal
Wet Weight
186 kg / 410 lbs
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
36.55 cubic inches
Displacement (cc)
599.00 cc
CO2
58.5 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
67.0 x 42.5 mm
Bore x Stroke (in,)
2.6 x 1.7 inches
Displacement
599 cc / 36.5 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder
Fuel System
Injection. Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors
Bore x Stroke
67 x 42.5 mm
Compression Ratio
12.2:1
Cooling System
Liquid cooled
Emissions
Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.
Engine Lubrication
Forced pressure and wet sump
Engine Oil Specification
Synthetic, 10W/40
Fuel Consumption
2.52 litres/100 km (39.7 km/l or 93.34 mpg)
Fuel Induction
Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors
Ignition
Computer-controlled digital transistorized with electronic advance and independent four-cylinder 3D-mapped computer control.
Lubrication
Wet sump
Spark Plug
NGK, IMR9C-9H
Starter
Electric
Valve System
4
Clutch
Cable-operated multiplate wet clutch
Final Drive
#525 O-ring chain
Gearbox
6-speed
Primary Drive
#525 O-ring chain
Transmission / Drive
Close-ratio 6 Speed
Wheel Travel - Rear (mm)
103 mm
Wheel Travel - Rear (in.)
4.1 inches
Wheel Travel - Front (mm)
118 mm
Wheel Travel - Front (in.)
4.7 inches
Trail (mm)
98 mm
Trail (in.)
3.8 inches
Frame Type
Aluminium, twin spar
Suspension - Front
41mm inverted Big Piston Fork with spring preload, rebound and compression damping adjustability
Suspension - Rear
Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Rake
23.5°
Trail
97.7mm / 3.9 in
Wheel Travel - Front
120 mm / 4.3 in
Wheel Travel - Rear
129.5 mm / 5.1 in
Instrumentation
LCD Instrumentation.
Brakes - Rear Diameter (mm)
220 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Front Diameter (mm)
310 mm
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front
2x 310mm discs 4 piston calipers
Brakes - Rear
Single 220mm disc 1 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
180/55 ZR17
