Key Specifications
Engine
In-line four, four-stroke
Power
118 hp / 88.1 kW @ 13500 rpm
Torque
66 Nm / 48.6 lb-ft @ 11250 rpm
Top Speed
255.3 km/h / 158.6 mph
Fuel Capacity
18.16 litres
Advertisement
Full 2010 Honda CBR 600RR Specifications
Year
2010
Colours
Pearl Orange/Black, Leyla
Make Model
Honda CBR 600RR
Wheelbase (mm)
1,369 mm
Wheelbase (in.)
53.9 inches
Seat Height (mm)
820 mm
Seat Height (in.)
32.3 inches
Seat Height
820 mm / 32.3 in
Wheelbase
1369 mm / 53.9 in
Ground Clearance
135 mm / 5.3 in
Height
1105 mm / 43.5 in
Length
2015 mm / 79.3 in
Width
685 mm / 26.9 in
Wet Weight (lbs.)
410.0 pounds
Wet Weight (kg)
186.0 kg
Fuel Capacity (l)
18.16 litres
Fuel Capacity (gal.)
4.80 gallons
Dry Weight (lbs.)
683.4 pounds
Dry Weight (kg)
310
Dry Weight
156.5 kg / 345 lbs
Fuel Capacity
18.2 liters / 4.8 gal
Wet Weight
186 kg / 410 lbs
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
36.55 cubic inches
Displacement (cc)
599.00 cc
CO2
132.9 CO
Bore x Stroke (mm)
67.0 x 42.5 mm
Bore x Stroke (in,)
2.6 x 1.7 inches
Displacement
599 cc / 36.5 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Fuel System
Injection. Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors
Bore x Stroke
67 x 42.5 mm
Compression Ratio
12.2:1
Cooling System
Liquid cooled
Engine Oil Specification
Synthetic, 10W/40
Fuel Consumption
5.73 litres/100 km (17.5 km/l or 41.05 mpg)
Fuel Induction
Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors
Ignition
Computer-controlled digital transistorized with electronic advance and independent four-cylinder 3D-mapped computer control.
Lubrication
Wet sump
Spark Plug
NGK, IMR9C-9H
Starter
Electric
Valve System
4
Clutch
Cable-operated multiplate wet clutch.
Final Drive
#525 O-ring chain
Gearbox
6-speed
Transmission / Drive
Close-ratio 6 Speed
Trail (in.)
3.8 inches
Trail (mm)
98 mm
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (mm)
119 mm
Wheel Travel - Rear (in.)
5.1 inches
Wheel Travel - Rear (mm)
130 mm
Frame Type
Aluminium, twin spar
Suspension - Front
41mm inverted Big Piston Fork with spring preload, rebound and compression damping adjustability
Suspension - Rear
Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability;
Rake
23.5°
Trail
97.7mm / 3.9 in
Wheel Travel - Front
120 mm / 4.3 in
Wheel Travel - Rear
129.5 mm / 5.1 in
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front Diameter (mm)
310 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Rear Diameter (mm)
220 mm
Brakes - Front
2x 310mm discs 4 piston calipers
Brakes - Rear
Single 220mm disc 1 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
180/55 ZR17
