2020 BMW S 1000XR Specifications

Name: 2020 BMW S 1000XR
Brand: BMW

Sport • Specs last verified 13 July 2026

No images available

Tap to enlarge

2020 BMW S 1000XR Overview

The 2020 BMW S 1000XR is a sport motorcycle built around 999 cc of displacement. Under the tank sits an In-line four, four-stroke engine running Double Overhead Cams/Twin Cam (DOHC) valve actuation, a compression ratio of 12.5:1. 2020 BMW S 1000XR delivers 121 kW @ 11000 rpm of peak power and 114 Nm @ 9250 rpm of torque. The factory-quoted top speed stands at 200 km/h, making it a capable performer in its class. From a practical standpoint, the 2020 S 1000XR tips the scales at 226 kg, carries a 20-litre fuel tank, offers a seat height of 840 mm and spans a 1552 mm wheelbase. That's roughly 23.3 kg heavier than the average sport motorcycle in our database. Scroll down for the complete 2020 BMW S 1000XR spec sheet covering every technical detail from suspension travel to tyre sizes.

2020 S 1000XR - Pros & Cons

Strengths

Strong power output: 2020 BMW S 1000XR makes 121 kW @ 11000 rpm with 114 Nm @ 9250 rpm of torque - competitive figures for its class.
Fuel injection: The fuel injection system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
Large fuel range: The 20-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.

Considerations

Tall seat height: The 840 mm seat height will challenge shorter riders - tiptoeing at low speeds is something to factor into your decision.
Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.

Wear Points & Servicing Notes

Cooling system servicing

The Liquid cooled system on the S 1000XR needs a coolant change roughly every two years (or per the service schedule) - skipping it lets the coolant turn acidic and corrode the aluminium water passages over time.

Fuelling & injector care

Fuelling comes from fuel injection. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.

Valve clearance checks

Double Overhead Cams/Twin Cam (DOHC) valve actuation on the S 1000XR means clearances should be checked at the manufacturer's specified interval - they can tighten as mileage accumulates, and a light top-end tick is usually the first sign.

Brake disc and pad wear

The 2X 320mm discs floating, radial 4-piston fixed calipers front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Suspension condition on used examples

Up front, the S 1000XR runs 43mm Upside-down telescopic fork, slide tube, Dynamic ESA, damping electronically adjustable and Aluminium underslung double-sided swinging arm with central spring strut, Dynamic ESA, damping electronically adjustable at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.

Final drive maintenance

Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.

Frame & chassis check

The frame is Construction type aluminium perimeter frame, engine self-supporting - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.

Handling the weight at a standstill

At 226 kg, the S 1000XR is a substantial machine - low-speed manoeuvring in car parks takes more physical effort than on a lighter bike, though the weight disappears once rolling.

S 1000XR - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2020 BMW S 1000XR, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained S 1000XR should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any S 1000XR. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

Fuel system care

The S 1000XR's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.

Valve clearance service

Check that valve clearances have been adjusted at the correct intervals on any used S 1000XR. A bike with clearances out of spec doesn't always feel obviously wrong - but tight clearances accelerate valve seat wear. Ask for service documentation proving it's been done.

2020 BMW S 1000XR - Frequently Asked Questions

What engine does the 2020 BMW S 1000XR have?

The 2020 BMW S 1000XR uses an In-line four, four-stroke engine with 999 cc of displacement. It is liquid cooled.

What is the top speed of the 2020 BMW S 1000XR?

The 2020 BMW S 1000XR has a factory-quoted top speed of 200 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.

How much does the 2020 BMW S 1000XR weigh?

The 2020 BMW S 1000XR weighs 226 kg. This is the manufacturer's wet figure.

How much power does the 2020 BMW S 1000XR make?

The 2020 BMW S 1000XR produces 121 kW @ 11000 rpm of power and 114 Nm @ 9250 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2020 BMW S 1000XR?

The 2020 BMW S 1000XR has a 20-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 333-400 km between stops.

Is the 2020 BMW S 1000XR suitable for shorter riders?

The 2020 BMW S 1000XR has a seat height of 840 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2020 BMW S 1000XR have?

The 2020 BMW S 1000XR uses 2X 320mm discs floating, radial 4-piston fixed calipers at the front and Single 220 mm disc, 1 piston floating caliper at the rear.

What tyre sizes does the 2020 BMW S 1000XR use?

The 2020 BMW S 1000XR runs 120/70 ZR17 front and 190/55 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2020 BMW S 1000XR have?

The 2020 BMW S 1000XR is fitted with a Constant -mesh 6-speed gearbox, straight-toothed transmission.

BMW S 1000XR Spec Evolution

The BMW S 1000XR was produced across 10 model years (2015-2024). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2015	2016	2017	2018	2019	2020	2021	2022	2023	2024
Max Power	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	121 kW / 165 hp @ 11000 rpm	-	126.8 kW / 170 hp @ 11000 rpm
Wet Weight	228 kg / 502.6 lbs	228 kg / 502.6 lbs	228 kg / 502.6 lbs	228 kg / 502.6 lbs	228 kg / 502.6 lbs	226 kg / 498 lbs	226 kg / 498 lbs	226 kg / 498 lbs	223.6 kg / 493.0 lbs	227 kg / 498 lbs
Dry Weight	178 kg / 392.4 lbs	178 kg / 392.4 lbs	178 kg / 392.4 lbs	178 kg / 392.4 lbs	178 kg / 392.4 lbs	205 kg / 451.9 lbs	-	-	-	-
Engine Detail	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms, 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, Intake/outlet mm 33.5/27.2	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, Intake/outlet mm 33.5/27.2	-	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Seat Height	840 mm / 33.1 in	840 mm / 33.1 in	840 mm / 33.1 in	840 mm / 33.1 in	840 mm / 33.1 in	840 mm / 33.0 in	840 mm / 33.0 in - 790 mm / 31.1 with optional lowered suspension	840 mm / 33.0 in - 790 mm / 31.1 with optional lowered suspension	790 mm / 31.1 in.	850 mm / 33.5 in - 790 mm / 31.1 with optional lowered suspension
Fuel Capacity	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20 Litres / 5.2 US gal	20.00 litres / 5.28 US gallons	20 Litres / 5.2 US gal
Comments	-	Small windscreen. Switchable ABS.	Small windscreen. Switchable ABS.	Small windscreen. Automatic Stability Control.	-	-	Riding Modes Pro (incl. HSC Pro, MSR, ABS Pro and DTC). Integrated Pannier Holders.	Riding Modes Pro (incl. HSC Pro, MSR, ABS Pro and DTC). Integrated Pannier Holders.	Riding Modes Pro (incl. HSC Pro, MSR, ABS Pro and DTC). Integrated Pannier Holders.	-
CO2	125.3 CO2 g/km. (CO2 - Carbon dioxide emission)	125.3 CO2 g/km. (CO2 - Carbon dioxide emission)	-	155.4 CO2 g/km. (CO2 - Carbon dioxide emission)	155.4 CO2 g/km. (CO2 - Carbon dioxide emission)	143.8 CO2 g/km. (CO2 - Carbon dioxide emission)	147.6 CO2 g/km. (CO2 - Carbon dioxide emission)	147.6 CO2 g/km. (CO2 - Carbon dioxide emission)	147.6 CO2 g/km. (CO2 - Carbon dioxide emission)	-

Key Specifications

Engine

In-line four, four-stroke

Power

121 kW / 165 hp @ 11000 rpm

Torque

114 Nm / 84 lb-ft @ 9250 rpm

Top Speed

200.0 km/h / 124.3 mph

Weight

226 kg / 498 lbs

Fuel Capacity

20 Litres / 5.2 US gal

Full 2020 BMW S 1000XR Specifications

Year 2020

Colours Racing Red uni/White Aluminium metallic matt, Ice Grey uni

Make Model BMW S 1000XR

Storage Storage compartment underneath seat

Seat Height 840 mm / 33.0 in

Wheelbase 1552 mm / 61.1 in

Height 1411 mm / 55.6 in.

Length 2333 mm / 91.8 in

Width 850 mm / 33.4 in with mirrors

Dry Weight 205 kg / 451.9 lbs

Fuel Capacity 20 Litres / 5.2 US gal

Wet Weight 226 kg / 498 lbs

Top Speed 200.0 km/h / 124.3 mph

Max Power 121 kW / 165 hp @ 11000 rpm

Max Torque 114 Nm / 84 lb-ft @ 9250 rpm

Power-to-Weight Ratio 0.7915 HP/kg

Fuel Control Double Overhead Cams/Twin Cam (DOHC)

Engine Type In-line four, four-stroke

CO2 143.8 CO2 g/km. (CO2 - Carbon dioxide emission)

Displacement 999 cc / 60.9 cu-in

Engine Detail Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2

Fuel System Injection. Electronic Injection

Bore x Stroke 80 x 49.7 mm

Compression Ratio 12.5:1

Cooling System Liquid cooled

Emissions Closed-loop three-way catalytic converter

Engine Management BMS-X

Fuel Consumption 6.20 litres/100 km (16.1 km/l or 37.94 mpg)

Fuel Reserve 4.00 litres / 1.06 US gallons

Lubrication Wet sump

Mixture Control Electronic injection, throttle valve 48 mm

Starter Electric

Valve System 4

Clutch Self-reinforcing multi-plate anti-hopping wet clutch, mechanically activated

Final Drive Chain

Gear Ratios 1st 2.647 2nd 2.091 3rd 1.727 4th. 1.476 5th 1.304 lth. 1.167

Gearbox 6-speed

Primary Drive Chain 17/45

Primary Drive Ratios 1.652

Transmission / Drive Constant -mesh 6-speed gearbox, straight-toothed

Frame Type Construction type aluminium perimeter frame, engine self-supporting

Suspension - Front 43mm Upside-down telescopic fork, slide tube, Dynamic ESA, damping electronically adjustable

Suspension - Rear Aluminium underslung double-sided swinging arm with central spring strut, Dynamic ESA, damping electronically adjustable

Rake 25.5°

Steering Head Angle 64.5°

Trail 116 mm / 4.6 in

Wheel Travel - Front 150 mm / 5.9 in

Wheel Travel - Rear 150 mm / 5.9 in

Traction control BMW Motorrad DTC

Electrical System Alternator W 493 Battery V/Ah 12 / 9, maintenance-free Headlamp W LED low beam twin headlamp with projection module LED high beam with projection module Starter kW 0.8

Lighting system LED lights

Brakes - Front 2X 320mm discs floating, radial 4-piston fixed calipers

Brakes - Rear Single 220 mm disc, 1 piston floating caliper

ABS BMW Motorrad ABS Pro

Rims Cast Aluminium

Tyres - Front 120/70 ZR17

Tyres - Rear 190/55 ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
