Storage
|
- | - | - | - | - | - | Front Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg | - | - | - | - | Saddle bags | Saddle bags | Saddle bags |
|
Fuel Control
|
- | SOHC | - | SOHC | SOHC | SOHC | DOHC | DOHC | DOHC | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) |
|
Engine Type
|
- | Twin, four-stroke | Two cylinder boxer | Two cylinder boxer | Two cylinder boxer | Two cylinder boxer, two-stroke | Two cylinder boxer, four-stroke | Two cylinder boxer, four-stroke | Two cylinder boxer, two-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Twin, four-stroke | Twin, four-stroke |
|
CO2
|
- | 83.5 CO | - | - | - | 83.5 CO | 95.1 CO ↑ | 95.1 CO | 95.8 CO ↑ | 90.5 CO2 g/km. (CO2 - Carbon dioxide emission) ↓ | 90.5 CO2 g/km. (CO2 - Carbon dioxide emission) | 90.5 CO2 g/km. (CO2 - Carbon dioxide emission) | 115.1 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ | 115.1 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Comments
|
- | - | - | - | - | - | Power Steering | Blata is from the Czech Republic. | - | - | - | Windscreen. | Windscreen. Heated grips. Riding modes rain and road. | Windscreen. Heated grips. Riding modes rain and road. |
|
Displacement (cc)
|
- | - | - | - | 1170.00 cc | - | - | - | - | - | 1170.00 cc | - | 1170.00 cc | 1170.0 cc |
|
Brakes - Rear Diameter (mm)
|
- | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 276 mm ↑ | 276 mm | 276 mm | 276 mm | - |
|
Brakes - Rear Diameter (in.)
|
- | 10.4 inches | 10.4 inches | 10.4 inches | 10.4 inches | 10.4 inches | 10.4 inches | 10.4 inches | 10.4 inches | 10.9 inches ↑ | 10.9 inches | 10.9 inches | 10.9 inches | - |
|
Stroke
|
- | - | 4 | 2 ↓ | 4 ↑ | - | - | - | - | - | - | - | - | - |
|
Seat Height
|
820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 780 mm / 30.7 in. ↓ | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) ↑ | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 805 mm / 31.7 in. ↓ | 805 mm / 31.7 in. | 805 mm / 31.7 in. | 805 mm / 31.7 in. | 805 mm / 31.7 in. |
|
Frame Type
|
Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Two-section frame consisting of front and rear sections, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Two-part tubular frame, engine partially load-bearing | Two-part tubular frame, engine partially load-bearing | Two-part tubular frame, engine partially load-bearing | Two-section frame consisting of front and rear sections, load-bearing engine-gearbox unit | Two-section frame consisting of front and rear sections, load-bearing engine-gearbox unit |
|
Dry Weight
|
229 kg / 485.0 lbs | 229 kg / 485.0 lbs | 229 kg / 485.0 lbs | 229 kg / 504.9 lbs | 182 kg / 401.2 lbs ↓ | 229 kg / 485.0 lbs ↑ | 229 kg / 485.0 lbs | 229 kg / 485.0 lbs | 229 kg / 485.0 lbs | 233.2 kg / 514.0 lbs ↑ | 233.2 kg / 514.0 lbs | 233.2 kg / 514.0 lbs | - | - |
|
Brakes - Front
|
2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | Double disc. ABS | 2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | 2 x 320mm Discs, 4 piston callipers | Double disc. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS | Double disc. ABS |
|
Wheelbase
|
1485 mm / 58.4 in | 1485 mm / 58.4 in | 1485 mm / 58.4 in | 1485 mm / 58.4 in | 1,485 mm / 58.5 in. ↓ | 1485 mm / 58.4 in ↑ | 1485 mm / 58.4 in | 1485 mm / 58.4 in | 1485 mm / 58.4 in | 1,485 mm / 58.5 in. ↓ | 1,485 mm / 58.5 in. | 1,485 mm / 58.5 in. | 1,485 mm / 58.5 in. | 1485 mm / 58.5 in. ↑ |
|
Brakes - Rear
|
Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single disc. ABS | Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single 265mm disc, 2 piston caliper | Single disc. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. ABS | Single disc. ABS |
|
Fuel Capacity
|
27 Liters / 7.1 US gal | 27 Liters / 7.1 US gal | 27 Liters / 7.1 US gal | 27 Liters / 7.1 US gal | 16.00 litres / 4.23 gallons ↓ | 27 Liters / 7.1 US gal ↑ | 27 Liters / 7.1 US gal | 27 Liters / 7.1 US gal | 27 Liters / 7.1 US gal | 25.00 litres / 6.61 gallons ↓ | 25.00 litres / 6.61 gallons | 25.00 litres / 6.61 gallons | 25.00 litres / 6.61 gallons | 25.00 litres / 6.61 US gallons |
|
Suspension - Front
|
BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever; stanchion diameter 35 mm, central spring strut | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | Telelever | Telelever | BMW Telelever, ? 37 mm, central spring strut | BMW Motorrad Telelever | BMW Motorrad Telelever |
|
Top Speed
|
210 km/h / 130.5 mph | 210 km/h / 130.5 mph | 210 km/h / 130.5 mph | 210 km/h / 130.5 mph | 200.0 km/h / 124.3 mph ↓ | 210 km/h / 130.5 mph ↑ | 210 km/h / 130.5 mph | 210 km/h / 130.5 mph | 210 km/h / 130.5 mph | 201.2 km/h / 125.0 mph ↓ | 201.2 km/h / 125.0 mph | 201.2 km/h / 125.0 mph | 200.0 km/h / 124.3 mph ↓ | 200.0 km/h / 124.3 mph |
|
Suspension - Rear
|
Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Cast aluminium single-sided swing arm with BMW Motorrad Paralever | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Cast aluminium single swing arm with Paralever | Cast aluminium single swing arm with Paralever | Cast aluminium single swing arm with Paralever | BMW Motorrad EVO Paralever | BMW Motorrad EVO Paralever |
|
Fuel System
|
- | Injection. Electronic intake pipe injection/digital engine management: BMW engine management, BMS-K with overrun fuel cut-off, dual ignition | Injection. Electronic fuel injection | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition | Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition | Injection. Electronic intake pipe injection / BMS-K+ digital engine management with overrun fuel cut-off, twin spark ignition | - | Injection. Electronic intake pipe injection / BMS-K+ digital engine management with overrun fuel cut-off, twin spark ignition | Injection. Electronic intake pipe injection / BMS-K+ digital engine management with overrun fuel cut-off, twin spark ignition | Injection. Digital engine management, electronic intake pipe fuel injection | Injection. Digital engine management, electronic intake pipe fuel injection |
|
Colours
|
- | - | - | - | Biaritz blue, Sapphire black metallic, Titan silver | Light gray, gray, silver, polar | Thunder grey, polar, grey/silver/granite, ostra grey | Blue, gray, magnesium/beige | Silver/beige, blue, grey | Ebony, blue, grey | Ebony, blue/grey, grey | Ebony Metallic, San Marino Blue/Granite Grey Metallic Matte, Platinum Bronze Metallic | Alpine White, Mars Red Metallic/Dark Slate Metallic Matt | Alpine White, Mars Red Metallic/Dark Slate Metallic Matt, Carbon Black Metallic, Blue Planet Metallic, Sparkling Storm Metallic |
|
Clutch
|
Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically operated | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Single dry plate clutch, hydraulically | Hydraulic slipper clutch | Hydraulic slipper clutch | Multi-plate wet clutch, hydraulically operated | Wet eight-disc clutch with anti-hopping function, hydraulically operated | Wet eight-disc clutch with anti-hopping function, hydraulically operated |
|
Final Drive
|
System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | Shaft drive (cardan) | System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | System Enclosed driveshaft with two universal joints | Shaft drive (cardan) | Shaft drive (cardan) | Shaft drive (cardan) | Shaft drive (cardan) | Shaft drive (cardan) (final drive) |
|
Rims
|
- | - | - | - | - | - | Cast aluminium | Cast aluminium | Cast aluminum wheels | Cast aluminium | Cast aluminium | Cast aluminium | Cast aluminium | Cast aluminium |
|
Height
|
- | 1,430 mm / 56.3 in. | - | - | 1,430 mm / 56.3 in. | 1,430 mm / 56.3 in. | 1,430 mm / 56.3 in. | 1,430 mm / 56.3 in. | 1,430 mm / 56.3 in. | 1,415 mm / 55.7 in. ↓ | 1,415 mm / 55.7 in. | 1,415 mm / 55.7 in. | 1,415 mm / 55.7 in. | 1415 mm / 55.7 in. ↑ |
|
Length
|
2230 mm / 79.9 in | 2230 mm / 79.9 in | 2230 mm / 79.9 in | 2230 mm / 79.9 in | 2,230 mm / 87.8 in. ↓ | 2230 mm / 79.9 in ↑ | 2230 mm / 79.9 in | 2230 mm / 79.9 in | 2230 mm / 79.9 in | 2,222 mm / 87.5 in. ↓ | 2,222 mm / 87.5 in. | 2,222 mm / 87.5 in. | 2,222 mm / 87.5 in. | 2222 mm / 87.5 in. ↑ |
|
Wet Weight
|
259 kg / 570.9 lbs | 259 kg / 570.9 lbs | 259 kg / 570.9 lbs | 259 kg / 570.9 lbs | 204.0 kg / 449.7 lbs ↓ | 259 kg / 570.9 lbs ↑ | 259 kg / 570.9 lbs | 259 kg / 570.9 lbs | 259 kg / 570.9 lbs | 274.0 kg / 604.1 lbs ↑ | 274.0 kg / 604.1 lbs | 274.0 kg / 604.1 lbs | 276.0 kg / 608.5 lbs ↑ | 276.0 kg / 608.5 lbs |
|
Compression Ratio
|
12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.0:1 | 12.5:1 ↑ | 12.5:1 | 12.5:1 | 12.5:1 | 12.5:1 |
|
Emissions
|
- | - | - | - | - | - | Closed-loop 3-way catalytic converter, emission standard EU-3 | Closed-loop 3-way catalytic converter | Closed-loop 3-way catalytic converter, emission standard EU-3 | Emission standard EU-3 ↓ | Emission standard EU-3 | Emission standard EU-3 | Performance / fuel consumption | Performance / fuel consumption |
|
Engine Lubrication
|
- | - | - | - | - | - | Dry sump | Dry sump | Dry sump | Dry sump | Dry sump | Wet sump | Wet sump | Wet sump |
|
Tyres - Front
|
120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70-ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70 ZR17 | 120/70-ZR17 | 120/70-ZR17 | 120/70-ZR17 | 120/70-ZR17 | 120/70-ZR17 |
|
Width
|
905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in. | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 985 mm / 38.8 in. ↑ | 985 mm / 38.8 in. | 985 mm / 38.8 in. | 983 mm / 38.7 in. ↓ | 983 mm / 38.7 in. |
|
Tyres - Rear
|
180/60 ZR17 | 180/60 ZR17 | 180/60 ZR17 | 180/60 ZR17 | 180/55-ZR17 | 180/60 ZR17 | 180/60 ZR17 | 180/60 ZR17 | 180/60 ZR17 | 180/55-ZR17 | 180/55-ZR17 | 180/55-ZR17 | 180/55-ZR17 | - |
|
Primary Drive
|
- | - | - | - | - | - | Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD + Diff Lock | - | Constant mesh | - | - | - | - | - |
|
Rake
|
- | 26.6° | - | 26.2° | 26.2° | 26.2° | 26.2° | 26.2° | 26.2° | 26.5° ↑ | 26.5° | 26.5° | 26.4° ↓ | 26.4° |
|
Fuel Consumption
|
5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | - | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 3.90 litres/100 km (25.6 km/l or 60.31 mpg) ↓ | 3.90 litres/100 km (25.6 km/l or 60.31 mpg) | 3.90 litres/100 km (25.6 km/l or 60.31 mpg) | 4.96 litres/100 km (20.2 km/l or 47.42 mpg) ↑ | 4.96 litres/100 km (20.2 km/l or 47.42 mpg) |
|
Fuel Reserve
|
4 Litres / 1.0 US gal | 4 Litres / 1.0 US gal | 4 Litres / 1.0 US gal | 4 Litres / 1.0 US gal | 2.00 litres / 0.53 gallons ↓ | 4 Litres / 1.0 US gal ↑ | 4 Litres / 1.0 US gal | 4 Litres / 1.0 US gal | 4 Litres / 1.0 US gal | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 gallons | 4.00 litres / 1.06 US gallons |
|
Trail
|
116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.6 in. | 116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.5 in | 116 mm / 4.6 in. | 116 mm / 4.6 in. | 116 mm / 4.6 in. | 116 mm / 4.6 in. | 116 mm / 4.6 in. |
|
Wheel Travel - Front
|
120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in. | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in | 120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in. |
|
Wheel Travel - Rear
|
135 mm / 5.3 in | 135 mm / 5.3 in | 135 mm / 5.3 in | 135 mm / 5.3 in | 135 mm / 5.3 in. | 135 mm / 5.3 in | 135 mm / 5.3 in | 135 mm / 5.3 in | 135 mm / 5.3 in | 136 mm / 5.4 in. ↑ | 136 mm / 5.4 in. | 136 mm / 5.4 in. | 136 mm / 5.4 in. | 136 mm / 5.4 in. |
|
Max Torque
|
115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115.00 | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions ↑ | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions |
|
Power-to-Weight Ratio
|
- | 0.4743 HP/kg | 0.4803 HP/kg | 0.5968 HP/kg ↑ | 0.5968 HP/kg | 0.4743 HP/kg ↓ | 0.4743 HP/kg | 0.4743 HP/kg | 0.4718 HP/kg | 0.5361 HP/kg ↑ | 0.5361 HP/kg | 0.5361 HP/kg | - | - |
|
Valve System
|
- | 4 | - | 4 | 4 | 4 | 4 | - | 2 | - | 4 | 4 | 4 | 4 |
