Key Specifications
Engine
Single cylinder, four-stroke
Power
25 kW / 34 hp @ at 9500
Torque
28 Nm / 2.86 kgf-m / 20.7 ft-lb @ 7500 rpm
Weight
175 kg / 385.8 lbs
Fuel Capacity
11.50 litres
Full 2022 BMW G 310GS Specifications
Comments
Ride by Wire throttle.
Year
2022
Colours
Grey/Red/White/Blue, Triple Black, Polar White/Titanium Gray Metallic
Make Model
BMW G 310GS
Wheelbase (mm)
1420 mm
Wheelbase (in.)
55.9 inches
Storage
Luggage carrier
Seat Height (mm)
833 mm
Seat Height (in.)
32.8 inches
Length (mm)
2075 mm
Length (in.)
81.7 inches
Height (mm)
1230 mm
Height (in.)
48.4 inches
Seat Height
835 mm / 32.9 in 820 mm / 32.2 in Low Seat 850 mm / 33.5 in Comfort Seat
Wheelbase
1420 mm / 55.9 in
Height
1230 mm / 48.2 in (excl. mirrors)
Length
2075 mm / 81.7 in
Width
878 mm / 34.6 in (incl. mirrors)
Wet Weight (kg)
175
Fuel Capacity (l)
11.50 litres
Fuel Capacity (gal.)
3.04 US gallons
Dry Weight (lbs.)
385.8 pounds
Dry Weight (kg)
175
Fuel Capacity
11 Litres / 2.9 US gal
Wet Weight
175 kg / 385.8 lbs
Fuel Reserve (l)
1.00 litres
Fuel Reserve (gal.)
0.26 US gallons
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
Single cylinder, four-stroke
Displacement (ci)
19.10 cubic inches
Displacement (cc)
313.0 cc
CO2
76.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
80.0 x 62.1 mm
Bore x Stroke (in,)
3.1 x 2.4 inches
Displacement
313 cc / 19.1 cu-in
Engine Detail
Four stroke, rRearward-canted single-cylinder, DOHC, 4 valves
Fuel System
Injection
Bore x Stroke
80 x 62.1 mm
Compression Ratio
10.9:1
Cooling System
Liquid cooled
Emissions
Euro 5
Engine Lubrication
Wet sump
Exhaust
Single, closed-loop 3-way catalytic converter
Fuel Consumption
3.30 litres/100 km (30.3 km/l or 71.28 mpg)
Fuel Induction
EFI with front-intake 42mm throttle body
Ignition
Electronic
Lubrication
Wet sump
Starter
Electric
Valve System
4
Battery Capacity
12 V / 8 Ah, Maintenance free
Clutch
Wet multi-disc with assist-and-slipper function
Final Drive
Z-ring chain
Gearbox
6-speed
Primary Drive
X-ring chain with shock absorption in the real wheel hub
Transmission / Drive
6-speed
Wheel Travel - Rear (mm)
180 mm
Wheel Travel - Rear (in.)
7.1 inches
Wheel Travel - Front (mm)
180 mm
Wheel Travel - Front (in.)
7.1 inches
Trail (mm)
98 mm
Trail (in.)
3.9 inches
Frame Type
Tubular steel frame with bolted rear frame
Suspension - Front
41mm Upside-down fork, non-adjustable
Suspension - Rear
Linkage-free spring-preload adjustable shock
Rake
26.7°
Steering Head Angle
63.3°
Trail
98 mm / 3.86 in
Wheel Travel - Front
180 mm / 7.1 in
Wheel Travel - Rear
180 mm / 7.1 in
Alternator
308 W
Lighting system
LED headlight, turn indicators and rear light
Brakes - Front
Single 300mm disc, 4-piston fixed caliper, radially bolted
Brakes - Rear
Single 240mm disc, single-piston floating caliper
ABS
BMW Motorrad ABS
Rims
Cast aluminium
Tyres - Front
110/80 - R19
Tyres - Rear
150/70 - R17
Wheels - Front
Cast aluminium, 5-spoke, 2.50 x 19
Wheels - Rear
Cast aluminium, 5-spoke, 4.0 x 17
