Key Specifications
Power
55 kW / 75 hp @ 7300 rpm
Torque
77 Nm / 7.9 kg-m / 56.8 lbs/ft @ 5500 rpm
Fuel Capacity
15.90 litres
Full 2013 BMW F 700GS Specifications
Year
2013
Colours
Red, silver, gray
Make Model
BMW F 700GS
Width (mm)
889 mm
Width (in.)
35.0 inches
Wheelbase (mm)
1,562 mm
Wheelbase (in.)
61.5 inches
Seat Height (mm)
820 mm
Seat Height (in.)
32.3 inches
Length (mm)
2,281 mm
Length (in.)
89.8 inches
Height (mm)
1,240 mm
Height (in.)
48.8 inches
Seat Height
820 mm - 790 mm / 32.3 in. - 31.1 in.
Wheelbase
1562 mm / 61.5 in
Height
1240 mm / 48.8 in (excl. mirrors)
Length
2280 mm / 89.8 in
Width
890 mm / 35.0 in (incl. mirrors)
Wet Weight (lbs.)
461.0 pounds
Wet Weight (kg)
209.1 kg
Fuel Capacity (l)
15.90 litres
Fuel Capacity (gal.)
4.20 gallons
Dry Weight (lbs.)
410.0 pounds
Dry Weight (kg)
186
Dry Weight
186 kg / 410 lbs
Fuel Capacity
16 L / 3.6 US gal
Wet Weight
209 kg / 460 lbs
Bore x Stroke (in,)
3.2 x 3.0 inches
Bore x Stroke (mm)
82.0 x 75.6 mm
CO2
90.9 CO
Displacement (cc)
798.00 cc
Displacement (ci)
48.69 cubic inches
Engine Type
Twin, four-stroke
Fuel Control
DOHC
Displacement
798 cc / 47.7 cub. in.
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Fuel System
Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)
Bore x Stroke
82 x 75.8 mm
Compression Ratio
12.0:1
Cooling System
Liquid cooled
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-3
Engine Lubrication
Dry sump
Fuel Consumption
3.92 litres/100 km (25.5 km/l or 60.01 mpg)
Fuel Induction
Electronic intake injection, ∅45mm throttle bodies
Ignition
Knock control and oxygen sensors.
Starter
Electric
Valve System
4
Clutch
Multiplate-plate in oil bath
Final Drive
Chain
Gear Ratios
1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96:1
Gearbox
6-speed
Primary Drive
Endless O-ring chain with shock damping in rear wheel hub
Transmission / Drive
6 Speed
Trail (mm)
94 mm
Trail (in.)
3.7 inches
Wheel Travel - Front (in.)
7.1 inches
Wheel Travel - Front (in.)
7.1 inches
Wheel Travel - Front (mm)
180 mm
Wheel Travel - Front (mm)
180 mm
Wheel Travel - Rear (in.)
6.7 inches
Wheel Travel - Rear (mm)
170 mm
Frame Type
Tubular frame in steel partly carrying the engine
Suspension - Front
Conventional ∅41mm telescopic fork
Suspension - Rear
Gas pressure spring strut
Rake
26.0°
Steering Head Angle
64°
Trail
95 mm / 3.7 in.
Wheel Travel - Front
180mm / 7.1 in
Wheel Travel - Rear
170mm / 6.7 in.
Brakes - Rear Diameter (mm)
265 mm
Brakes - Rear Diameter (in.)
10.4 inches
Brakes - Front Diameter (mm)
300 mm
Brakes - Front Diameter (in.)
11.8 inches
Brakes - Front
2 x ∅300mm discs, 4 piston calipers, ABS
Brakes - Rear
Single ∅265mm disc, 2 piston caliper, ABS
Rims
Cast aluminium wheels
Tyres - Front
110/80-R19
Tyres - Rear
140/80-R17
