2017 Yamaha XSR900 Specifications

Name: 2017 Yamaha XSR900
Brand: Yamaha

Classic • Specs last verified 13 July 2026

No images available

Tap to enlarge

2017 Yamaha XSR900 Overview

Yamaha XSR900 is a classic motorcycle, displacing 847 cc. Power comes from an In-line three, four-stroke engine running Double Overhead Cams/Twin Cam (DOHC) valve actuation, a compression ratio of 11.5:1. Bore and stroke come in at 78 x 59.1 mm. On the performance side, it delivers 87.50 Nm @ 8500 Revolutions of torque. On the road, the 2017 XSR900 tips the scales at 195 kg, carries a 14-litre fuel tank and offers a seat height of 830 mm. The full 2017 Yamaha XSR900 spec sheet below covers every technical detail, from suspension travel to tyre sizes.

2017 Yamaha XSR900 compared with other bikes in the Classic category

We checked the recorded figures for the 2017 Yamaha XSR900 against up to 909 bikes in the Classic category in our database, counting each model once at the model year nearest to this one.

Only 24 of the other 436 bikes in the Classic category have a taller seat height than the 830 mm of the XSR900.
With 87.5 Nm, the XSR900 has the joint 57th highest torque of 364 bikes in the Classic category, 69% above the category average of 51.8 Nm.
Engine displacement of 847 cc is larger than that of 749 of the other 908 bikes in the Classic category.
Narrowing the field to the 153 models within five model years of it, the seat height of 830 mm is taller than that of 136 of the other 152.

Versus the 2016 model

The figures we track are unchanged from the 2016 model: peak torque, wet weight, displacement and seat height all match.

2017 XSR900 - Pros & Cons

Strengths

Fuel injection: Fuel injection means consistent cold starts and clean throttle response without the fussiness of a carbureted setup.
Strong front braking: Stopping power up front is strong thanks to the double disc setup, with plenty of room to upgrade further with braided lines.

Considerations

Tall seat height: At 830 mm, shorter riders will likely be on tiptoes at a standstill - worth sitting on one before you buy.
Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.

Wear Points & Servicing Notes

Fuelling & injector care

The fuel injection on the XSR900 needs little beyond good fuel and periodic use of an injector-cleaner additive - no jetting or float-bowl maintenance to worry about.

Valve clearance checks

With Double Overhead Cams/Twin Cam (DOHC) valve gear, the XSR900 needs periodic clearance checks; caught early they're a cheap adjustment, left unchecked they accelerate valve seat wear.

Brake disc and pad wear

Braking up front comes from double disc with hydraulic - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.

Suspension condition on used examples

The XSR900's suspension runs Telescopic forks at the front. The rear uses Link type suspension. Fork-seal condition and rear linkage play are the two things worth checking before buying used.

Final drive maintenance

The XSR900 uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.

Frame & chassis check

Built around a Diamond, the XSR900's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.

XSR900 - Buying & Maintenance Guide

What to check before buying

Before handing over money for a used 2017 Yamaha XSR900 with its 847 cc classic, cover the fundamentals: service book and oil change history, drivetrain wear, and any sign of oil weeping around the casings. This model runs chain final drive, so check chain slack and sprocket tooth profile specifically - a worn sprocket is a cheaper fix now than after it's chewed up the next chain. Now 9 years old, this classic is as likely to show age-related wear (perished rubber, seized fasteners, degraded seals) as mileage-related wear. Cold-starting it yourself tells you a lot - a healthy XSR900 should catch quickly and settle into a smooth idle.

Oil and filter changes

Nothing protects the XSR900's 847 cc in-line three, four-stroke like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). The sump holds 3.40 litres, so budget for that volume of quality motorcycle-specific engine oil. With an 11.5:1 compression ratio, running the octane grade specified in the manual matters more than on a lower-compression engine. Match the viscosity grade to what the owner's manual specifies, not what's cheapest.

Fuel system care

Fuel injection on the XSR900 needs little attention beyond decent fuel and an occasional system-cleaner additive. Anything left standing for three months or more should have its fuel drained and replaced before it varnishes the injectors.

Valve clearance service

Valve clearances are easy to overlook on a used XSR900 since a bike out of spec doesn't always feel obviously wrong - but the wear it causes is real. Ask the seller for documentation before assuming it's been done.

2017 Yamaha XSR900 - Frequently Asked Questions

What engine does the 2017 Yamaha XSR900 have?

The 2017 Yamaha XSR900 uses an In-line three, four-stroke engine with 847 cc of displacement.

How much does the 2017 Yamaha XSR900 weigh?

The 2017 Yamaha XSR900 weighs 195 kg. This is the manufacturer's wet figure.

How much torque does the 2017 Yamaha XSR900 produce?

The 2017 Yamaha XSR900 produces 87.50 Nm @ 8500 Revolutions of torque.

What is the fuel tank capacity of the 2017 Yamaha XSR900?

The 2017 Yamaha XSR900 has a 14-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 233-280 km between stops.

Is the 2017 Yamaha XSR900 suitable for shorter riders?

The 2017 Yamaha XSR900 has a seat height of 830 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2017 Yamaha XSR900 have?

The 2017 Yamaha XSR900 uses double disc with hydraulic at the front and single disc with hydraulic at the rear.

What tyre sizes does the 2017 Yamaha XSR900 use?

The 2017 Yamaha XSR900 runs 120/70-ZR17 front and 180/55-ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

How much oil does the 2017 Yamaha XSR900 take?

The 2017 Yamaha XSR900 takes 3.40 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.

Yamaha XSR900 Spec Evolution

The Yamaha XSR900 was produced across 8 model years (2016-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2016	2017	2018	2019	2020	2021	2022	2023
Wet Weight	195.0 kg / 429.9 lbs	195.0 kg / 429.9 lbs	195.0 kg / 430.0 lbs	195.0 kg / 430.0 lbs	195.0 kg / 430.0 lbs	195.0 kg / 430.0 lbs	193.0 kg / 425.5 lbs	193.0 kg / 425.5 lbs
Seat Height	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	810 mm / 31.9 in.	810 mm / 31.9 in.
Fuel Capacity	14.00 litres / 3.70 gallons	14.00 litres / 3.70 gallons	14.00 litres / 3.70 gallons	14.00 litres / 3.70 US gallons	14.00 litres / 3.70 US gallons	14.00 litres / 3.70 US gallons	14.00 litres / 3.70 US gallons	14.00 litres / 3.70 US gallons
Oil Capacity (Quarts)	0.22 quarts	0.22 quarts	0.22 quarts	3.59 US quarts	3.59 US quarts	3.59 US quarts	3.7 US quarts	3.7 US quarts
Oil Capacity (l)	3.40 litres	3.40 litres	3.40 litres	3.40 litres	3.40 litres	3.40 litres	3.50 litres	3.50 litres
Ground Clearance (mm)	135 mm	135 mm	135 mm	135 mm	135 mm	135 mm	140 mm	140 mm
Ground Clearance (in.)	5.3 inches	5.3 inches	5.3 inches	5.3 inches	5.3 inches	5.3 inches	5.5 inches	5.5 inches
Displacement (ci)	51.68 cubic inches	51.68 cubic inches	-	51.68 cubic inches	51.68 cubic inches	51.68 cubic inches	51.68 cubic inches	54.31 cubic inches

Key Specifications

Engine

In-line three, four-stroke

Power

Not recorded

Torque

87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8500 Revolutions

Top Speed

Not recorded

Weight

195.0 kg / 429.9 lbs

Fuel Capacity

14.00 litres / 3.70 gallons

Full 2017 Yamaha XSR900 Specifications

Colours Black, blue, silver

Ground Clearance (in.) 5.3 inches

Ground Clearance (mm) 135 mm

Seat Height 830 mm / 32.7 in.

Height 1,135 mm / 44.7 in.

Length 2,075 mm / 81.7 in.

Width 815 mm / 32.1 in.

Oil Capacity (l) 3.40 litres

Oil Capacity (Quarts) 0.22 quarts

Fuel Capacity 14.00 litres / 3.70 gallons

Wet Weight 195.0 kg / 429.9 lbs

Max Torque 87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8500 Revolutions

CO2 120.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Displacement (cc) 847.00 cc

Displacement (ci) 51.68 cubic inches

Engine Type In-line three, four-stroke

Fuel Control Double Overhead Cams/Twin Cam (DOHC)

Bore x Stroke (in,) 3.1 x 2.3 inches

Bore x Stroke (mm) 78.0 x 59.1 mm

Fuel System Injection

Compression Ratio 11.5:1

Emissions EU4

Engine Lubrication Wet sump

Fuel Consumption 5.20 litres/100 km (19.2 km/l or 45.23 mpg)

Ignition TCI

Starter Electric

Valve System 4

Clutch Wet, Multiple Disc

Final Drive Chain

Gearbox 6-speed

Primary Drive Frame

Frame Type Diamond

Suspension - Front Telescopic forks

Suspension - Rear Link type suspension

Rake 25.0°

Trail 103 mm / 4.1 in.

Wheel Travel - Front 137 mm / 5.4 in.

Wheel Travel - Rear 130 mm / 5.1 in.

Brakes - Front Diameter (in.) 11.7 inches

Brakes - Front Diameter (mm) 298 mm

Brakes - Rear Diameter (in.) 9.6 inches

Brakes - Rear Diameter (mm) 245 mm

Brakes - Front Double disc. Hydraulic.

Brakes - Rear Single disc. Hydraulic.

Tyres - Front 120/70-ZR17

Tyres - Rear 180/55-ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
