2013 Triumph Tiger 800 Specifications

Name: 2013 Triumph Tiger 800
Brand: Triumph

Enduro / Off-Road • Specs last verified 13 July 2026

No images available

Tap to enlarge

2013 Triumph Tiger 800 Overview

For 2013, Triumph offers the Tiger 800 as an enduro / off-road motorcycle with 799 cc on tap. The 2013 Triumph Tiger 800 is built around a Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder engine, a compression ratio of 12.0:1. Out on the road, the Tiger 800 delivers 69.1 kW @ 9300 rpm of peak power and 79 Nm @ 7850 rpm of torque. In everyday use, the 2013 Tiger 800 tips the scales at 209.6 kg, carries a 18.9-litre fuel tank, offers a seat height of 810 mm -830 mm and spans a 1530 mm wheelbase. That's roughly 10.8 kg heavier than the average enduro / off-road motorcycle in our database. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2013 Triumph Tiger 800 spec sheet below.

2013 Tiger 800 - Pros & Cons

Strengths

Strong power output: Peak output on the Tiger 800 is 69.1 kW @ 9300 rpm and 79 Nm @ 7850 rpm of torque - strong numbers for what it is.
Fuel injection: No choke, no jetting, no altitude compensation to think about - fuel injection just works across a wider range of conditions than carburetion.
Large fuel range: With a 18.9-litre tank, this isn't a bike you'll be stopping for fuel every hour - a real asset on longer trips.

Considerations

Chain final drive upkeep: A chain drivetrain is the most common setup in its class, but it's also the one that demands the most regular hands-on maintenance.

Wear Points & Servicing Notes

Cooling system servicing

With Liquid cooled, thermal management is largely automatic, but the coolant has a service life of its own - replace it on the manufacturer's interval to protect the water passages and thermostat.

Fuelling & injector care

Fuelling on the Tiger 800 comes from Multipoint sequential electronic fuel injection. Cold starts and throttle response stay consistent across altitude and temperature, the main practical edge over a carbureted equivalent.

Brake disc and pad wear

2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.

Suspension condition on used examples

Suspension duties are handled by Showa 45mm upside down forks up front and Showa monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.

Final drive maintenance

Chain final drive on the Tiger 800 means routine lubing and tension checks are part of ownership - skip them and sprocket wear accelerates noticeably.

Frame & chassis check

The Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.

Tiger 800 - Buying & Maintenance Guide

What to check before buying

A pre-purchase check on the 2013 Triumph Tiger 800 should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept Tiger 800 settles to a smooth idle within seconds.

Oil and filter changes

Oil changes are the cheapest insurance you can buy for a Tiger 800's engine - keep to the manufacturer's interval rather than stretching it. Use the viscosity grade the manual specifies, not whatever's on sale.

Fuel system care

Injector systems like the Tiger 800's hold up well with basic care - decent fuel, an occasional cleaner additive, and draining old fuel before any layup longer than three months.

2013 Triumph Tiger 800 - Frequently Asked Questions

What engine does the 2013 Triumph Tiger 800 have?

The 2013 Triumph Tiger 800 uses a Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder engine with 799 cc of displacement. It is liquid cooled.

How much does the 2013 Triumph Tiger 800 weigh?

The 2013 Triumph Tiger 800 weighs 209.6 kg. This is the manufacturer's wet figure.

How much power does the 2013 Triumph Tiger 800 make?

The 2013 Triumph Tiger 800 produces 69.1 kW @ 9300 rpm of power and 79 Nm @ 7850 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2013 Triumph Tiger 800?

The 2013 Triumph Tiger 800 has a 18.9-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 315-377 km between stops.

Is the 2013 Triumph Tiger 800 suitable for shorter riders?

The 2013 Triumph Tiger 800 has a seat height of 810 mm -830 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2013 Triumph Tiger 800 have?

The 2013 Triumph Tiger 800 uses 2 x 308 mm Floating discs, Nissin 2-piston floating caliper at the front and Single 255 mm disc, Nissin single-piston floating caliper at the rear.

What tyre sizes does the 2013 Triumph Tiger 800 use?

The 2013 Triumph Tiger 800 runs 110/80 ZR19 front and 150/70 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2013 Triumph Tiger 800 have?

The 2013 Triumph Tiger 800 is fitted with a 6 Speed transmission.

Triumph Tiger 800 Spec Evolution

The Triumph Tiger 800 was produced across 5 model years (2011-2015). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2011	2012	2013	2014	2015
Max Power	69.1 kW / 93.9 hp @ 9300 rpm	69.1 kW / 93.9 hp @ 9300 rpm	69.1 kW / 93.9 hp @ 9300 rpm	69.1 kW / 93.9 hp @ 9300 rpm	70.8 KW / 95 hp @ 9300 rpm
Wet Weight	209.6 kg / 462 lbs	209.6 kg / 462 lbs	209.6 kg / 462 lbs	209.6 kg / 462 lbs	210 kg / 462 lbs
Engine Detail	Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder	Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder.
Fuel Capacity	18.9 Litres / 5.0 gal / 4.2 Imp gal	18.9 Litres / 5.0 gal / 4.2 Imp gal	18.9 Litres / 5.0 gal / 4.2 Imp gal	18.9 Litres / 5.0 gal / 4.2 Imp gal	19 Litres / 5.0 gal / 4.3 Imp gal
Frame Type	Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels	Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels	Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels	Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels	Tubular steel trellis frame, swingarm: twin-sided, cast aluminum alloy
Displacement	799 cc / 48.7 cu-in	799 cc / 48.7 cu-in	799 cc / 48.7 cu-in	799 cc / 48.7 cu-in	799 cc / 48.7 cub in
Brakes - Front	2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter	2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter	2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter	2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter	2 x 308 mm Foating discs, Nissin 2-piston sliding caliper, ABS available
Brakes - Rear	Single 255 mm disc, Nissin single-piston floating caliper (ABS available)	Single 255 mm disc, Nissin single-piston floating caliper (ABS available)	Single 255 mm disc, Nissin single-piston floating caliper (ABS available)	Single 255 mm disc, Nissin single-piston floating caliper (ABS available)	Single 255 mm disc, Nissin single-piston sliding caliper, ABS available

Key Specifications

Engine

Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder

Power

69.1 kW / 93.9 hp @ 9300 rpm

Torque

79 Nm / 8.1 kgf-m /58 ft.lb @ 7850 rpm

Top Speed

Not published by manufacturer

Weight

209.6 kg / 462 lbs

Fuel Capacity

18.9 Litres / 5.0 gal / 4.2 Imp gal

Full 2013 Triumph Tiger 800 Specifications

Year 2013

Make Model Triumph Tiger 800

Seat Height 810 mm -830 mm / 31.9 in- 32.7 in adjustable

Wheelbase 1530 mm / 60.2in

Height 1350 mm / 53.1 in

Length 2215 mm / 87.1in

Width 795 mm / 31.3 in

Fuel Capacity 18.9 Litres / 5.0 gal / 4.2 Imp gal

Wet Weight 209.6 kg / 462 lbs

Max Power 69.1 kW / 93.9 hp @ 9300 rpm

Max Torque 79 Nm / 8.1 kgf-m /58 ft.lb @ 7850 rpm

Displacement 799 cc / 48.7 cu-in

Engine Detail Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder

Bore x Stroke 74 x 61.9 mm

Compression Ratio 12.0:1

Cooling System Liquid cooled

Exhaust Stainless Steel, 3 into 1, high-level stainless steel silencer

Fuel Induction Multipoint sequential electronic fuel injection

Ignition Digital CDI

Lubrication Wet sump

Starter Electric

Clutch Wet, multi-plate

Final Drive Chain

Transmission / Drive 6 Speed

Frame Type Tubular steel trellis frame. Swingarm: twin-sided, cast aluminum alloy wheels

Suspension - Front Showa 45mm upside down forks

Suspension - Rear Showa monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment

Rake 23.9°

Trail 92.4mm / 3.6 in

Wheel Travel - Front 180 mm / 7.1 in

Wheel Travel - Rear 170 mm / 6.7 in

Brakes - Front 2 x 308 mm Floating discs, Nissin 2-piston floating caliper (ABS available), Nissin master cylinder, 14mm diameter

Brakes - Rear Single 255 mm disc, Nissin single-piston floating caliper (ABS available)

Tyres - Front 110/80 ZR19

Tyres - Rear 150/70 ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
