Key Specifications
Engine
Single cylinder, four-stroke
Power
42.1 hp / 31 kW @ 7000 rpm
Torque
47 Nm / 4.7 kgf-m @ 5000 rpm
Fuel Capacity
6.10 gallons
Full 2013 Kawasaki KLR 650 Specifications
Year
2012 -13
Colours
Ebony, Pearl Solar Yellow, Candy Lime Green/Ebony
Colours
Red/gray, black/gray, blue/white
Make Model
Kawasaki KLR 650
Warranty
12 Months
Warranty
12 Months
Width (mm)
960 mm
Width (in.)
37.8 inches
Wheelbase (mm)
1,481 mm
Wheelbase (in.)
58.3 inches
Seat Height (mm)
889 mm
Seat Height (in.)
35.0 inches
Length (mm)
2,296 mm
Length (in.)
90.4 inches
Height (mm)
1,349 mm
Height (in.)
53.1 inches
Ground Clearance (mm)
211 mm
Ground Clearance (in.)
8.3 inches
Ground Clearance (in.)
8.3 inches
Ground Clearance (mm)
211 mm
Height (in.)
53.1 inches
Height (mm)
1,349 mm
Length (in.)
90.4 inches
Length (mm)
2,296 mm
Seat Height (in.)
35.0 inches
Seat Height (mm)
889 mm
Wheelbase (in.)
58.3 inches
Wheelbase (mm)
1,481 mm
Width (in.)
37.8 inches
Width (mm)
960 mm
Seat Height
889 mm / 35 in
Wheelbase
1480 mm / 58.3 in
Ground Clearance
210 mm / 8.3 in
Height
1350 mm / 53.1 in
Length
2295 mm / 90.4 in
Width
960 mm / 37.8 in
Fuel Capacity (gal.)
6.10 gallons
Fuel Capacity (l)
23.09 litres
Fuel Capacity (gal.)
6.10 gallons
Fuel Capacity (l)
23.09 litres
Wet Weight (kg)
196.0 kg
Wet Weight (lbs.)
432.0 pounds
Wet Weight (kg)
196.0 kg
Wet Weight (lbs.)
432.0 pounds
Fuel Capacity
23 Litres / 5.8 US gal.
Wet Weight
194 kg / 432 lbs
Fuel Control
DOHC
Engine Type
Single cylinder, four-stroke
Fuel Control
DOHC
Engine Type
Single cylinder, four-stroke
Displacement (ci)
39.72 cubic inches
Displacement (cc)
651.00 cc
Bore x Stroke (mm)
100.0 x 83.0 mm
Bore x Stroke (in,)
3.9 x 3.3 inches
Bore x Stroke (in,)
3.9 x 3.3 inches
Bore x Stroke (mm)
100.0 x 83.0 mm
Displacement (cc)
651.00 cc
Displacement (ci)
39.72 cubic inches
Displacement
651 cc / 39.7 cu-in
Engine Detail
Four stroke, single cylinder, DOHC, 4 valves per cylinder
Fuel System
Carburettor. Keihin CVK40
Fuel System
Carburettor. Keihin CVK40
Bore x Stroke
100 x 83 mm.
Compression Ratio
9.8:1
Compression Ratio
9.8:1
Cooling System
Liquid cooled
Fuel Induction
Keihin CVK40
Ignition
Transistorized
Ignition
Electric CDI
Lubrication
Forced lubrication (wet sump)
Starter
Electric
Starter
Electric
Valve System
4
Clutch
Wet multi-disc, cable operation
Final Drive
Chain
Final Drive
Sealed Chain
Final Drive Ratio
2.867 (43/15)
Gear Ratios
1st 2.266 (34/15) 2nd 1.444 (26/18) 3rd 1.136 (25/22) 4th 0.954 (21/22) 5th 0.791 (19/24)
Gearbox
5-speed
Gearbox
5-speed
Primary Drive Ratios
2.272 / 75/33
Transmission / Drive
5 Speed
Trail (mm)
112 mm
Trail (in.)
4.4 inches
Trail (mm)
112 mm
Trail (in.)
4.4 inches
Frame Type
Semi-double cradle, high-tensile steel
Frame Type
Semi-double Cradle Made of high-tech, round-section, high-tensile steel
Suspension - Front
41mm telescopic fork / 7.9 in.
Suspension - Front
41mm Air-adjustable forks,
Suspension - Rear
Uni-Trak® linkage, 5-way preload shock absorber with 4way rebound damping.
Suspension - Rear
Uni-Trak single-shock system with 5-way preload and stepless rebound damping / 7.3 in.
Rake
28.0°
Rake
28.0°
Trail
112 mm / 4.4 in
Wheel Travel - Front
200 mm / 7.8 in
Wheel Travel - Rear
185 mm / 7.2 in
Instrumentation
Neutral indicator, reverse indicator
Instrumentation
Speedometer, odometer, clock, fuel gauge and coolant temp light
Lighting system
Dual removable 30w headlights / LED taillight / brake light
Lighting system
Dual removable 30w headlights / LED taillight / brake light
Brakes - Rear Diameter (mm)
240 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Front Diameter (mm)
280 mm
Brakes - Front Diameter (in.)
11.0 inches
Brakes - Front Diameter (in.)
11.0 inches
Brakes - Front Diameter (mm)
280 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front
Single 280mm disc 2 piston caliper
Brakes - Front
Single disc. Petal-type disc, two-piston caliper
Brakes - Rear
Single disc. Single-piston caliper
Brakes - Rear
Single 203mm disc 1 piston caliper
Tyres - Front
90/90-21
Tyres - Front
18/7-8
Tyres - Front
90/90 -21
Tyres - Rear
18/9-8
Tyres - Rear
130/80-17
Tyres - Rear
130/80 -17
