2017 Honda NC 750X / DCT Specifications

Scooter • Specs last verified 13 July 2026

No images available
Tap to enlarge

2017 Honda NC 750X / DCT Overview

For 2017, Honda offers the NC 750X / DCT as a scooter motorcycle with 745 cc on tap. The 2017 Honda NC 750X / DCT is built around a Four stroke , Parallel twin, SOHC, 4 valves per cylinder engine, a compression ratio of 10.7:1. Out on the road, the NC 750X / DCT delivers 40.3 kW @ 6250 rpm of peak power and 68 Nm of torque. In everyday use, the 2017 NC 750X / DCT tips the scales at 220 kg, carries a 14.1-litre fuel tank, offers a seat height of 830 mm and spans a 1540 mm wheelbase. That's roughly 22.3 kg heavier than the average scooter motorcycle in our database. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2017 Honda NC 750X / DCT spec sheet below.

2017 NC 750X / DCT - Pros & Cons

Strengths

  • Strong power output: Peak output on the NC 750X / DCT is 40.3 kW @ 6250 rpm and 68 Nm of torque - strong numbers for what it is.
  • Fuel injection: No choke, no jetting, no altitude compensation to think about - fuel injection just works across a wider range of conditions than carburetion.

Considerations

  • Tall seat height: A 830 mm seat puts flat-footing out of reach for a lot of riders - sit on it in person before committing.
  • Chain final drive upkeep: A chain drivetrain is the most common setup in its class, but it's also the one that demands the most regular hands-on maintenance.

Wear Points & Servicing Notes

Cooling system servicing

With Liquid-cooled, thermal management is largely automatic, but the coolant has a service life of its own - replace it on the manufacturer's interval to protect the water passages and thermostat.

Fuelling & injector care

Fuelling on the NC 750X / DCT comes from PGM-FI electronic fuel injection. Cold starts and throttle response stay consistent across altitude and temperature, the main practical edge over a carbureted equivalent.

Brake disc and pad wear

Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.

Suspension condition on used examples

Suspension duties are handled by 41 mm telescopic forks up front and Single monoshock damper at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.

Final drive maintenance

Chain final drive on the NC 750X / DCT means routine lubing and tension checks are part of ownership - skip them and sprocket wear accelerates noticeably.

Frame & chassis check

The Rigid tube steel diamond chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.

Handling the weight at a standstill

The NC 750X / DCT's 220 kg kerb weight is worth factoring into how you handle it at a standstill - parking-lot manoeuvres need a bit more deliberate technique than on a lighter machine.

NC 750X / DCT - Buying & Maintenance Guide

What to check before buying

A pre-purchase check on the 2017 Honda NC 750X / DCT should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept NC 750X / DCT settles to a smooth idle within seconds.

Oil and filter changes

Oil changes are the cheapest insurance you can buy for a NC 750X / DCT's engine - keep to the manufacturer's interval rather than stretching it. Use the viscosity grade the manual specifies, not whatever's on sale.

Fuel system care

Injector systems like the NC 750X / DCT's hold up well with basic care - decent fuel, an occasional cleaner additive, and draining old fuel before any layup longer than three months.

2017 Honda NC 750X / DCT - Frequently Asked Questions

What engine does the 2017 Honda NC 750X / DCT have?
The 2017 Honda NC 750X / DCT uses a Four stroke , Parallel twin, SOHC, 4 valves per cylinder engine with 745 cc of displacement. It is liquid-cooled.
How much does the 2017 Honda NC 750X / DCT weigh?
The 2017 Honda NC 750X / DCT weighs 220 kg. This is the manufacturer's wet figure.
How much power does the 2017 Honda NC 750X / DCT make?
The 2017 Honda NC 750X / DCT produces 40.3 kW @ 6250 rpm of power and 68 Nm of torque. These are peak figures.
What is the fuel tank capacity of the 2017 Honda NC 750X / DCT?
The 2017 Honda NC 750X / DCT has a 14.1-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 235-282 km between stops.
Is the 2017 Honda NC 750X / DCT suitable for shorter riders?
The 2017 Honda NC 750X / DCT has a seat height of 830 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.
What brakes does the 2017 Honda NC 750X / DCT have?
The 2017 Honda NC 750X / DCT uses Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads at the front and Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads at the rear.
What tyre sizes does the 2017 Honda NC 750X / DCT use?
The 2017 Honda NC 750X / DCT runs 120/70-ZR17 front and 160/60-ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2017 Honda NC 750X / DCT have?
The 2017 Honda NC 750X / DCT is fitted with a 6 Speed Manual transmission.

Honda NC 750X / DCT Spec Evolution

The Honda NC 750X / DCT was produced across 5 model years (2015-2025). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification 2015 2017 2019 2021 2025
Max Power 40.3 kW / 54 hp @ 6250 rpm 40.3 kW / 54 hp @ 6250 rpm 40.3 kW / 54 hp @ 6250 rpm 43.1 kW / 57.8 hp @ 6750 rpm 43.1 kW / 57.8 hp @ 6750 rpm
Wet Weight 218 kg / 480.6 in 220 kg / 485 lbs 220 kg / 485 lbs / DCT: 230kg / 500 lbs 214 kg / 471.7 lbs / DCT: 224 kg / 493.8 lbs 216 kg / 476 lbs / DCT: 226 kg / 498 lbs
Seat Height 790 mm (Europe) - 775 mm (Japan) 830 mm / 32.7 in 830 mm / 32.7 in 800 mm / 31.5 in 802 mm / 31.5 in
Wheelbase 1540 mm / 60.6 in 1540 mm / 60.6 in 1540 mm / 60.6 in 1535 mm / 60.4 in 1525 mm / 60.0 in / DCT: 1530 mm / 69.2 in
Brakes - Front Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads Single 320 mm hydraulic disc 2 piston calipers and sintered metal pads Single 320 mm wavy hydraulic disc 2 piston calipers and sintered metal pads 2x 296mm wavy hydraulic disc 2 piston calipers and sintered metal pads
Brakes - Rear Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads Single 240 mm wavy hydraulic disc 1 piston caliper and sintered metal pads Single 240 mm wavy hydraulic disc 1 piston caliper and sintered metal pads
Ground Clearance 165 mm / 6.5 in 165 mm / 6.5 in 165 mm / 6.5 in 145 mm / 5.7 in 145 mm / 5.7 in
Suspension - Rear Single monoshock damper Single monoshock damper Single monoshock damper Single monoshock damper, Pro-Link swingarm Single monoshock damper, Pro-Link swingarm

Key Specifications

Engine

Four stroke , Parallel twin, SOHC, 4 valves per cylinder

Power

40.3 kW / 54 hp @ 6250 rpm

Torque

68 Nm / 50.8 lb-ft@ 4750 rpm

Top Speed

Not published by manufacturer

Weight

220 kg / 485 lbs

Fuel Capacity

14.1 Litres / 3.7 US gal

Advertisement

Full 2017 Honda NC 750X / DCT Specifications

Year 2016 - 17
Make Model Honda NC 750X / DCT
Seat Height 830 mm / 32.7 in
Wheelbase 1540 mm / 60.6 in
Ground Clearance 165 mm / 6.5 in
Fuel Capacity 14.1 Litres / 3.7 US gal
Wet Weight 220 kg / 485 lbs
Max Power 40.3 kW / 54 hp @ 6250 rpm
Max Torque 68 Nm / 50.8 lb-ft@ 4750 rpm
Displacement 745 cc / 45.4 cu-in
Engine Detail Four stroke , Parallel twin, SOHC, 4 valves per cylinder
Bore x Stroke 77 x 80mm
Compression Ratio 10.7:1
Cooling System Liquid-cooled
Fuel Induction PGM-FI electronic fuel injection
Ignition Computer-controlled digital transistorised with electronic advance
Starter Electric
Clutch Wet multiplate hydraulic 2-clutch
Final Drive Chain
Final Drive Ratio 2.687 (DCT 2.437)
Gear Ratios 1 2.812 (DCT 2.666) 2 1.894 (DCT 1.904) 3 1.454 (DCT 1.454) 4 1.200 (DCT 1.200) 5 1.033 (DCT 1.033) 6 0.837 (DCT 0.837)
Transmission / Drive 6 Speed Manual
Transmission / Drive 6-Speed Dual Clutch Transmission
Frame Type Rigid tube steel diamond
Suspension - Front 41 mm telescopic forks
Suspension - Rear Single monoshock damper
Rake 27˚
Trail 110 mm / 4.3 IN
Wheel Travel - Front 153 mm / 6.0 in
Wheel Travel - Rear 150 mm / 5.9 in
Brakes - Front Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads
Brakes - Rear Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads
Tyres - Front 120/70-ZR17
Tyres - Rear 160/60-ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
