Honda NC 750X / DCT Specs

2014 - 2025 • 5 variants

The Honda NC 750X / DCT is a scooter produced from 2014 to 2025 across 5 variants. It is powered by a four stroke , parallel twin, sohc, 4 valves per cylinder. Peak power output is 54 hp. Peak torque is 68 Nm.

About the Honda NC 750X / DCT

Documented here are the full technical specifications for the Honda NC 750X / DCT, a Scooter motorcycle with a production run from 2014 to 2025. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

AdSense - 728Ã90

Honda NC 750X / DCT by Year

2025 Honda NC 750X / DCT View specs →

2021 Honda NC 750X / DCT View specs →

2019 Honda NC 750X / DCT View specs →

2017 Honda NC 750X / DCT View specs →

2015 Honda NC 750X / DCT View specs →

Spec Evolution

How key specs changed across production years.

Specification	2015	2017	2019	2021	2025
Seat Height	790 mm (Europe) - 775 mm (Japan)	830 mm / 32.7 in ↑	830 mm / 32.7 in	800 mm / 31.5 in ↓	802 mm / 31.5 in ↑
Wheelbase	1540 mm / 60.6 in	1540 mm / 60.6 in	1540 mm / 60.6 in	1535 mm / 60.4 in ↓	1525 mm / 60.0 in / DCT: 1530 mm / 69.2 in ↓
Brakes - Front	Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads	Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads	Single 320 mm hydraulic disc 2 piston calipers and sintered metal pads	Single 320 mm wavy hydraulic disc 2 piston calipers and sintered metal pads	2x 296mm wavy hydraulic disc 2 piston calipers and sintered metal pads ↓
Brakes - Rear	Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads	Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads	Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads	Single 240 mm wavy hydraulic disc 1 piston caliper and sintered metal pads	Single 240 mm wavy hydraulic disc 1 piston caliper and sintered metal pads
Ground Clearance	165 mm / 6.5 in	165 mm / 6.5 in	165 mm / 6.5 in	145 mm / 5.7 in ↓	145 mm / 5.7 in
Suspension - Rear	Single monoshock damper	Single monoshock damper	Single monoshock damper	Single monoshock damper, Pro-Link swingarm	Single monoshock damper, Pro-Link swingarm
Clutch	Wet multiplate hydraulic 2-clutch	Wet multiplate hydraulic 2-clutch	Wet multiplate hydraulic 2-clutch	Wet multiplate / DCT: Wet multiplate hydraulic 2-clutch	Wet multiplate / DCT: Wet multiplate hydraulic 2-clutch
Height	1285 mm / 50.6 in	-	-	1330 mm / 52.3 in	1330 mm / 52.3 in
Rims - Front	-	-	-	17 x 3.50	17M/C x MT3.50
Length	2210 mm / 87.0 in	-	-	2210 mm / 87 in	2210 mm / 87 in
Rims - Rear	-	-	-	17 x 4.50	17M/C x MT4.50
Wet Weight	218 kg / 480.6 in	220 kg / 485 lbs ↑	220 kg / 485 lbs / DCT: 230kg / 500 lbs	214 kg / 471.7 lbs / DCT: 224 kg / 493.8 lbs ↓	216 kg / 476 lbs / DCT: 226 kg / 498 lbs ↑
Emissions	-	-	-	EURO5	EURO 5+
Tyres - Front	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17	120/70-ZR17 M/C
Width	830 mm / 32.7 in	-	-	846 mm / 33.3 in	846 mm / 33.3 in
Tyres - Rear	160/60-ZR17	160/60-ZR17	160/60-ZR17	160/60-ZR17	160/60-ZR17 M/C
Transmission / Drive	6 Speed Manual	6 Speed Manual	6 Speed Manual	6 Speed Manual / DCT: 6-Speed Dual Clutch Transmission	6 Speed Manual / DCT: 6-Speed Dual Clutch Transmission
Max Power	40.3 kW / 54 hp @ 6250 rpm	40.3 kW / 54 hp @ 6250 rpm	40.3 kW / 54 hp @ 6250 rpm	43.1 kW / 57.8 hp @ 6750 rpm ↑	43.1 kW / 57.8 hp @ 6750 rpm
Wheel Travel - Front	153 mm / 6.0 in	153 mm / 6.0 in	137 mm / 5.4 in ↓	120 mm / 4.7 in ↓	120 mm / 4.7 in
Wheel Travel - Rear	150 mm / 5.9 in	150 mm / 5.9 in	150 mm / 5.9 in	120 mm / 4.7 in ↓	120 mm / 4.7 in
Max Torque	68 Nm / 50.8 lb-ft@ 4750 rpm	68 Nm / 50.8 lb-ft@ 4750 rpm	68 Nm / 50.8 lb-ft@ 4750 rpm	69 Nm / 50.9 lb-ft @ 4750 rpm ↑	69 Nm / 50.9 lb-ft @ 4750 rpm
