2026 Ducati Panigale V4 R Overview
The 2026 Ducati Panigale V4 R is a sport motorcycle built around 998 cc of displacement. Under the tank sits a Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder engine, a compression ratio of 14.0:1. 2026 Ducati Panigale V4 R delivers 160.4 kW @ 15750 rpm of peak power and 114.5 Nm @ 12000 rpm of torque. From a practical standpoint, the 2026 Panigale V4 R tips the scales at 186.5 kg, carries a 17-litre fuel tank, offers a seat height of 850 mm and spans a 1471 mm wheelbase. That's roughly 8.2 kg lighter than the average sport motorcycle in our database. Scroll down for the complete 2026 Ducati Panigale V4 R spec sheet covering every technical detail from suspension travel to tyre sizes.
2026 Ducati Panigale V4 R compared with other bikes in the Sport category
Here is how the 2026 Ducati Panigale V4 R stacks up against other bikes in the Sport category in our database. Each model counts once, using the model year closest to this one, and the comparison covers up to 1607 models.
- Power-to-weight ratio of 860 W/kg is higher than that of 720 of the other 726 bikes in the Sport category.
- Only 15 of the other 1340 bikes in the Sport category have a higher power output than the 160.4 kW of the Panigale V4 R.
- With 850 mm, the Panigale V4 R has the joint 47th tallest seat height of 1607 bikes in the Sport category, 6% above the category average of 803 mm.
- Narrowing the field to the 147 models within five model years of it, the power-to-weight ratio of 860 W/kg is higher than that of every one of the other 146.
Versus the 2023 model
Compared with the 2023 model, peak power rose from 159.1 kW to 160.4 kW (+1.3 kW), peak torque increased from 111.3 Nm to 114.5 Nm (+3.2 Nm) and wet weight came down from 193.5 kg to 186.5 kg (-7 kg). Displacement and seat height are unchanged.
2026 Panigale V4 R - Pros & Cons
Strengths
-
⚡
Strong power output: 2026 Ducati Panigale V4 R makes 160.4 kW @ 15750 rpm with 114.5 Nm @ 12000 rpm of torque - competitive figures for its class.
-
🔧
Fuel injection: The fuel injectionsystem system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
-
🛑
Strong front braking: The disc front brake gives excellent stopping power and responds well to aftermarket braided lines.
Considerations
-
📏
Tall seat height: The 850 mm seat height will challenge shorter riders - tiptoeing at low speeds is something to factor into your decision.
-
⚙️
Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.
Wear Points & Servicing Notes
Cooling system servicing
The Liquid cooled system on the Panigale V4 R needs a coolant change roughly every two years (or per the service schedule) - skipping it lets the coolant turn acidic and corrode the aluminium water passages over time.
Fuelling & injector care
Fuelling comes from fuel injectionsystem. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.
Brake disc and pad wear
The disc front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.
Suspension condition on used examples
Up front, the Panigale V4 R runs 43 mm Fully adjustable Öhlins NPX pressurized fork with TiN treatment and Fully adjustable Öhlins TTX 36 unit with hydraulic spring preload adjuster at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.
Final drive maintenance
Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.
Frame & chassis check
The frame is Aluminum alloy Front Frame with optimized stiffnesses - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.
Panigale V4 R - Buying & Maintenance Guide
What to check before buying
When inspecting a used 2026 Ducati Panigale V4 R with its 998 cc sport, start with the basics: check the service book for oil change frequency, inspect the drivetrain for wear, and look for oil seepage around the engine casings and rocker covers. This model runs chain final drive, so check chain slack and sprocket tooth profile specifically - a worn sprocket is a cheaper fix now than after it's chewed up the next chain. A cold start test is invaluable - a well-maintained Panigale V4 R should fire up cleanly and settle to a smooth idle within a few seconds.
Oil and filter changes
Regular oil changes are the single most important maintenance task for the Panigale V4 R's 998 cc four stroke, desmosedici stradale 90° v4, rearward-rotating crankshaft, 4 desmodromically actuated valves per cylinder. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. With a 14.0:1 compression ratio, running the octane grade specified in the manual matters more than on a lower-compression engine. Always use the correct viscosity grade as specified in the owner's manual.
Fuel system care
The Panigale V4 R's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.
2026 Ducati Panigale V4 R - Frequently Asked Questions
What engine does the 2026 Ducati Panigale V4 R have?
The 2026 Ducati Panigale V4 R uses a Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder engine with 998 cc of displacement. It is liquid cooled.
How much does the 2026 Ducati Panigale V4 R weigh?
The 2026 Ducati Panigale V4 R weighs 186.5 kg. This is the manufacturer's wet figure.
How much power does the 2026 Ducati Panigale V4 R make?
The 2026 Ducati Panigale V4 R produces 160.4 kW @ 15750 rpm of power and 114.5 Nm @ 12000 rpm of torque. These are peak figures.
What is the fuel tank capacity of the 2026 Ducati Panigale V4 R?
The 2026 Ducati Panigale V4 R has a 17-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 283-340 km between stops.
Is the 2026 Ducati Panigale V4 R suitable for shorter riders?
The 2026 Ducati Panigale V4 R has a seat height of 850 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.
What brakes does the 2026 Ducati Panigale V4 R have?
The 2026 Ducati Panigale V4 R uses 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure, 4-piston calipers with Self bleeding master cylinder at the front and single 245 mm disc, 2-piston caliper at the rear.
What tyre sizes does the 2026 Ducati Panigale V4 R use?
The 2026 Ducati Panigale V4 R runs 120/70 ZR17, Pirelli Diablo Supercorsa SP-V4 front and 200/60 ZR17, Pirelli Diablo Supercorsa SP-V4 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2026 Ducati Panigale V4 R have?
The 2026 Ducati Panigale V4 R is fitted with a Six-speed with Ducati Quick Shift transmission.
Ducati Panigale V4 R Spec Evolution
The Ducati Panigale V4 R was produced across 3 model years (2019-2026). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.
| Specification |
2019 |
2023 |
2026 |
| Max Power |
172 kW / 231 hp @ 15500 rpm with Ducati Performance exhaust |
159.1 kW / 218 hp @ 15500 rpm |
160.4 kW / 218 hp @ 15750 rpm |
| Wet Weight |
193 kg / 425 lbs |
193.5 kg / 426.5 lbs 188.5 kg / 415.5 lbs with full racing exhaust |
186.5 kg / 411.2 lbs |
| Seat Height |
830 mm / 32.4 in Single seat |
850 mm / 33.4 Single seat |
850 mm / 33.4 Single seat |
| Fuel Capacity |
16 Litres / 4.3 US gal / 3.9 Imp gal |
17 Litres / 4.49 US gal |
17 Litres / 4.49 US gal |
| Brakes - Front |
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers with Bosch Cornering ABS EVO |
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema, (M4.30) 4-piston callipers. Self bleeding master cylinder |
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure, 4-piston calipers. Self bleeding master cylinder |
| Brakes - Rear |
Single 245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO |
Single 245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO |
Single 245 mm disc, 2-piston caliper |
| Suspension - Front |
Fully adjustable 43 mm Öhlins NPX 25/30 pressurized fork with TiN treatment |
Fully adjustable 43 mm Öhlins NPX 25/30 pressurized fork with TiN treatment |
43 mm Fully adjustable Öhlins NPX pressurized fork with TiN treatment |
| Suspension - Rear |
Fully adjustable Öhlins TTX36 unit. Aluminium single-sided swingarm. Adjustable pivot position +/- 3 mm |
Fully adjustable Öhlins TTX 36 unit with hydraulic spring preload adjuster |
Fully adjustable Öhlins TTX 36 unit with hydraulic spring preload adjuster |
Key Specifications
Engine
Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder
Power
160.4 kW / 218 hp @ 15750 rpm
Torque
114.5 Nm / 84 lb-ft @ 12000 rpm
Weight
186.5 kg / 411.2 lbs
Fuel Capacity
17 Litres / 4.49 US gal
Advertisement
Full 2026 Ducati Panigale V4 R Specifications
Year
2026
Make Model
Ducati Panigale V4 R
Seat Height
850 mm / 33.4 Single seat
Wheelbase
1471 mm / 57.9 in
Fuel Capacity
17 Litres / 4.49 US gal
Wet Weight
186.5 kg / 411.2 lbs
Displacement
998 cc / 60.9 cu-in
Engine Detail
Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder
Bore x Stroke
81 x 48.4 mm
Compression Ratio
14.0:1
Cooling System
Liquid cooled
Emissions
Euro 5
Exhaust
4-2-1-2 system, with 2 catalytic converters and 4 lambda probes
Fuel Induction
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies with aerodynamic valves. Variable length intake system
Starter
Electric
Clutch
Hydraulically controlled slipper dry clutch. Self bleeding master cylinder.
Final Drive
Chain 520; Front sprocket 16; Rear sprocket 43
Gear Ratios
1st = 36/15, 2nd = 34/17, 3rd = 33/19, 4th = 32/21, 5th = 30/22, 6th = 27/22
Primary Drive
Straight cut gears; Ratio 1.80:1
Transmission / Drive
Six-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame Type
Aluminum alloy Front Frame with optimized stiffnesses
Suspension - Front
43 mm Fully adjustable Öhlins NPX pressurized fork with TiN treatment
Suspension - Rear
Fully adjustable Öhlins TTX 36 unit with hydraulic spring preload adjuster
Rake
24,5°
Seat
Single seat
Trail
100 mm / 3.9 in
Wheel Travel - Front
125 mm / 4.9 in
Wheel Travel - Rear
130 mm / 5.1 in
Equipment / Features
Öhlins suspension, Lithium-ion battery, Quick adjustment buttons, Forged aluminium wheels, Coming home, Single seat configuration, Ducati Power Launch (DPL DVO, TFT colour display, Full LED lighting system,Full LED headlight, Daytime Running Light (DRL), Self cancelling turning indicators, Lap Timer, Pit Limiter, Rear suspension rod with adjustable length, Ducati Racing Gearbox (DRG) with Ducati Neutral Lock (DNL), Ducati Quick Shift (DQS) up/down 2.0, Billet aluminium steering stem with bike number, Öhlins SD20 steering damper.
Safety Equipment
Riding Modes, Power Modes, Bosch Cornering ABS, Ducati Traction Control (DTC) EVO, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) DVO, Auto tyre calibration, Race brake control, Road eCBS
Instrumentation
Last generation digital unit with 5in TFT colour display
Brakes - Front
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure, 4-piston calipers. Self bleeding master cylinder
Brakes - Rear
Single 245 mm disc, 2-piston caliper
ABS
Cornering ABS with eCBS
Tyres - Front
120/70 ZR17, Pirelli Diablo Supercorsa SP-V4
Tyres - Rear
200/60 ZR17, Pirelli Diablo Supercorsa SP-V4
Wheels - Front
3.50 x 17 in, 5-spoke aluminium alloy
Wheels - Rear
6.00 x 17 in, 5-spoke aluminium alloy
Specifications are compiled from manufacturer documentation and cross-referenced
technical sources, and corrected on an ongoing basis.
