2020 Ducati Diavel 1260 S Overview
Ducati Diavel 1260 S is a custom / cruiser motorcycle, displacing 1262 cc. Power comes from a Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark engine, a compression ratio of 13.0:1. On the performance side, it delivers 159 hp @ 9500 rpm of peak power and 128.9 Nm @ 7500 rpm of torque. On the road, the 2020 Diavel 1260 S tips the scales at 244 kg, carries a 17-litre fuel tank, offers a seat height of 780 mm and spans a 1600 mm wheelbase. That's roughly 56.6 kg lighter than the average custom / cruiser motorcycle in our database. The full 2020 Ducati Diavel 1260 S spec sheet below covers every technical detail, from suspension travel to tyre sizes.
2020 Diavel 1260 S - Pros & Cons
Strengths
-
⚡
Strong power output: With 159 hp @ 9500 rpm and 128.9 Nm @ 7500 rpm of torque on tap, the Diavel 1260 S is no slouch for its class.
-
🔧
Fuel injection: Fuel injection means consistent cold starts and clean throttle response without the fussiness of a carbureted setup.
Considerations
-
⚙️
Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.
Wear Points & Servicing Notes
Cooling system servicing
Diavel 1260 S's Liquid cooled setup is low-maintenance provided the coolant interval is kept - old, acidic coolant is the main cause of long-term corrosion in the water passages.
Fuelling & injector care
The fuel injectionsystem on the Diavel 1260 S needs little beyond good fuel and periodic use of an injector-cleaner additive - no jetting or float-bowl maintenance to worry about.
Brake disc and pad wear
Braking up front comes from 2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.
Suspension condition on used examples
The Diavel 1260 S's suspension runs 48 mm USD Öhlins adjustable fork, TiN treatment at the front. The rear uses Öhlins fully adjustable monoshock, Aluminium casted single-sided swingarm. Fork-seal condition and rear linkage play are the two things worth checking before buying used.
Final drive maintenance
The Diavel 1260 S uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.
Frame & chassis check
Built around a Tubular steel trellis frame, the Diavel 1260 S's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.
Handling the weight at a standstill
244 kg puts the Diavel 1260 S toward the heavier end of its class. It's most noticeable at walking pace; once underway the mass settles into the handling rather than fighting it.
Diavel 1260 S - Buying & Maintenance Guide
What to check before buying
Before handing over money for a used 2020 Ducati Diavel 1260 S, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy Diavel 1260 S should catch quickly and settle into a smooth idle.
Oil and filter changes
Nothing protects a Diavel 1260 S's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). Match the viscosity grade to what the owner's manual specifies, not what's cheapest.
Fuel system care
Fuel injection on the Diavel 1260 S needs little attention beyond decent fuel and an occasional system-cleaner additive. Anything left standing for three months or more should have its fuel drained and replaced before it varnishes the injectors.
2020 Ducati Diavel 1260 S - Frequently Asked Questions
What engine does the 2020 Ducati Diavel 1260 S have?
The 2020 Ducati Diavel 1260 S uses a Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark engine with 1262 cc of displacement. It is liquid cooled.
How much does the 2020 Ducati Diavel 1260 S weigh?
The 2020 Ducati Diavel 1260 S weighs 244 kg. This is the manufacturer's wet figure.
How much power does the 2020 Ducati Diavel 1260 S make?
The 2020 Ducati Diavel 1260 S produces 159 hp @ 9500 rpm of power and 128.9 Nm @ 7500 rpm of torque. These are peak figures.
What is the fuel tank capacity of the 2020 Ducati Diavel 1260 S?
The 2020 Ducati Diavel 1260 S has a 17-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 283-340 km between stops.
Is the 2020 Ducati Diavel 1260 S suitable for shorter riders?
The 2020 Ducati Diavel 1260 S has a seat height of 780 mm. This is a moderate seat height that suits a wide range of rider heights.
What brakes does the 2020 Ducati Diavel 1260 S have?
The 2020 Ducati Diavel 1260 S uses 2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder at the front and Single 265mm disc, 2-piston Brembo floating calliper at the rear.
What tyre sizes does the 2020 Ducati Diavel 1260 S use?
The 2020 Ducati Diavel 1260 S runs 120/70 ZR17 Pirelli Diablo Rosso II front and 240/45 ZR17 Pirelli Diablo Rosso II rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2020 Ducati Diavel 1260 S have?
The 2020 Ducati Diavel 1260 S is fitted with a 6-Speed transmission.
Ducati Diavel 1260 S Spec Evolution
The Ducati Diavel 1260 S was produced across 3 model years (2019-2021). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.
| Specification |
2019 |
2020 |
2021 |
| Max Power |
159 hp / 117 kW @ 9500 rpm |
159 hp / 117 kW @ 9500 rpm |
157 hp / 116 kW @ 9250 rpm |
| Wet Weight |
244 kg / 538 lbs |
244 kg / 538 lbs |
247 kg / 544 lbs |
| Dry Weight |
214 kg / 481 lbs |
214 kg / 481 lbs |
221 kg / 487 lbs |
| Brakes - Front |
2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder. |
2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder |
2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder |
| ABS |
Cornering ABS Evo |
Cornering ABS Evo |
Bosh cornering ABS Evo |
| Equipment / Features |
Öhlins fully adjustable suspension, Ducati Quick Shift up/down Evo (DQS), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Daytime Running | Safety Equipment Riding Modes, Power Modes, Ducati Safety Pack (Cornering ABS Evo, Ducati Traction Control Evo DTC), Ducati Wheelie Control Evo (DWC), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Self cancelling turn indicators |
Öhlins fully adjustable suspension, Ducati Quick Shift up/down Evo (DQS), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Daytime Running | Safety Equipment Riding Modes, Power Modes, Ducati Safety Pack (Cornering ABS Evo, Ducati Traction Control Evo DTC), Ducati Wheelie Control Evo (DWC), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Self cancelling turn indicators |
Fully adjustable Öhlins suspension, Ducati Power Launch, cruise control, hands-free, backlit handlebar switches, 3.5" TFT colour display, Ducati Quick Shift, Ducati Multimedia System |
| Emissions |
Euro4 |
Euro4 |
Euro5 |
| Tyres - Front |
120/70 ZR17 Pirelli Diablo Rosso II |
120/70 ZR17 Pirelli Diablo Rosso II |
120/70 ZR17 Pirelli Diablo Rosso III |
Key Specifications
Engine
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Power
159 hp / 117 kW @ 9500 rpm
Torque
128.9 Nm / 95 lb-ft @ 7500 rpm
Top Speed
Not published by manufacturer
Fuel Capacity
17 Litres / 4.5 US gal
Advertisement
Full 2020 Ducati Diavel 1260 S Specifications
Year
2020
Make Model
Ducati Diavel 1260 S
Seat Height
780 mm / 30.7 in
Wheelbase
1600 mm / 63.0 in
Dry Weight
214 kg / 481 lbs
Fuel Capacity
17 Litres / 4.5 US gal
Wet Weight
244 kg / 538 lbs
Displacement
1262 cc / 77 cu-in
Engine Detail
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Bore x Stroke
106 x 71.5 mm
Compression Ratio
13.0:1
Cooling System
Liquid cooled
Emissions
Euro4
Exhaust
Stainless steel pipes and single muffler with twin tail pipes, Catalytic converter and 2 lambda probes
Fuel Induction
Electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Ignition
Electronic
Starter
Electric
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Final Drive
Chain, Front sprocket Z15, Rear sprocket Z43
Gear Ratios
1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 22/25
Primary Drive
Straight cut gears, Ratio 1.84:1
Transmission / Drive
6-Speed
Frame Type
Tubular steel trellis frame
Suspension - Front
48 mm USD Öhlins adjustable fork, TiN treatment
Suspension - Rear
Öhlins fully adjustable monoshock, Aluminium casted single-sided swingarm
Rake
27°
Trail
120 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
110 mm / 4.33 in
Equipment / Features
Öhlins fully adjustable suspension, Ducati Quick Shift up/down Evo (DQS), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Daytime Running | Safety Equipment Riding Modes, Power Modes, Ducati Safety Pack (Cornering ABS Evo, Ducati Traction Control Evo DTC), Ducati Wheelie Control Evo (DWC), Cruise control, Ducati Power Launch Evo (DPL), Hands-Free, Backlit handlebar switches, 3.5″ TFT colour display, Full LED lighting system, Self cancelling turn indicators
Instrumentation
3.5 in TFT colour display and dedicated warning light display
Brakes - Front
2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder
Brakes - Rear
Single 265mm disc, 2-piston Brembo floating calliper
ABS
Cornering ABS Evo
Tyres - Front
120/70 ZR17 Pirelli Diablo Rosso II
Tyres - Rear
240/45 ZR17 Pirelli Diablo Rosso II
Wheels
Light alloy, casted and machined,
Wheels - Front
3.50 x 17
Wheels - Rear
8.00 x 17
Specifications are compiled from manufacturer documentation and cross-referenced
technical sources, and corrected on an ongoing basis.
