CO2
|
109.0 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Comments
|
Windscreen. | - | Dynamic Traction Control | 3 Ride Modes (ECO, Rain and Road). Traction Control. | 3 Ride Modes (ECO, Rain and Road). Traction Control. Hill Start Control. |
|
Seat Height
|
890 mm to 910 mm / 35 in to 35.8 in 820 mm to 910 mm / 32 in to 35.8 in - possible | 890 mm to 910 mm / 35 in to 35.8 in 820 mm to 910 mm / 32 in to 35.8 in - possible | 890 mm to 910 mm / 35 in to 35.8 in 820 mm to 910 mm / 32 in to 35.8 in - possible | 890 mm / 35.0 in. | 890 mm / 35.0 in. |
|
Frame Type
|
Two-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine | Two-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine | Two-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine | Two-section frame, front- and bolted on rear frame, load-bearing engine | Two-section frame, front- and bolted on rear frame, load-bearing engine |
|
Brakes - Front
|
2x 305mm floating discs, 4-piston radial brake calipers | 2x 305mm floating discs, 4-piston radial brake calipers | 2x 305mm floating discs, 4-piston radial brake calipers | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. |
|
Wheelbase
|
1504 mm / 59.2 in | 1504 mm / 59.2 in | 1504 mm / 59.2 in | 1504 mm / 59.2 in. | 1504 mm / 59.2 in. |
|
Engine Detail
|
Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm | Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm | Four stroke, two cylinder horizontally opposed Boxer, with two overhead spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, intake 40mm, outlet 34 mm | Balance shaft and variable engine timing system | Balance shaft and variable engine timing system |
|
Fuel Capacity
|
30 Litres / 7.9 US gal | 30 Litres / 7.9 US gal | 30 Litres / 7.9 US gal | 29.90 litres / 7.90 US gallons ↓ | 29.90 litres / 7.90 US gallons |
|
Brakes - Rear
|
Single 276mm disc, 2-piston floating caliper | Single 276mm disc, 2-piston floating caliper | Single 276mm disc, 2-piston floating caliper | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. |
|
Suspension - Front
|
BMW Motorrad 37mm Telelever, central spring strut | BMW Motorrad 37mm Telelever, central spring strut | BMW Motorrad 37mm Telelever, central spring strut | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut |
|
Top Speed
|
200.0 km/h / 124.3 mph | 200.0 km/h / 124.3 mph | 200.0 km/h / 124.3 mph | 193.1 km/h / 120.0 mph ↓ | 193.1 km/h / 120.0 mph |
|
Suspension - Rear
|
Cast aluminium single-sided swing arm with BMW Motorrad Paralever, WAD spring strut, continuously adjustable spring preload by means of hand wheel, rebound-stage damping adjustable by hand wheel (Option: Dynamic ESA) | Cast aluminium single-sided swing arm with BMW Motorrad Paralever, WAD spring strut, continuously adjustable spring preload by means of hand wheel, rebound-stage damping adjustable by hand wheel (Option: Dynamic ESA) | Cast aluminium single-sided swing arm with BMW Motorrad Paralever, WAD spring strut, continuously adjustable spring preload by means of hand wheel, rebound-stage damping adjustable by hand wheel (Option: Dynamic ESA) | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel. | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel. |
|
Colours
|
Ice Grey, Style HP, Style Exclusive | Ice Grey, Style HP, Style Exclusive | White/Red/Blue, White/Red/Black, Black/Grey, Grey/Yellow | Black Storm Metallic/Black/Agate Gray, Ice Grey, Light White/Racing Blue Metallic/Racing Red, Black/Yellow | Black Storm Metallic/Black/Agate Gray, Ice Grey, Light White/Racing Blue Metallic/Racing Red, Gravity Blue Metallic |
|
Battery Capacity
|
12V/12Ah | 12V/12Ah | 12 V / 11.8 Ah, maintenance-free | - | - |
|
Clutch
|
Wet clutch with anti-hopping function, hydraulically activated | Wet clutch with anti-hopping function, hydraulically activated | Wet clutch with anti-hopping function, hydraulically activated | Wet clutch with an anti-hopping function, hydraulic activation | Wet clutch with an anti-hopping function, hydraulic activation |
|
Final Drive
|
Shaft | Shaft | Shaft | Shaft drive (cardan) (final drive) | Shaft drive (cardan) (final drive) |
|
Rims
|
Aluminium-Gussräder | Aluminium-Gussräder | - | - | Cross spoke wheels |
|
Height
|
1460 mm / 57.5 in. | 1460 mm / 57.5 in. | 1460 mm / 57.5 in | 1430 mm / 56.3 in. ↓ | 1430 mm / 56.3 in. |
|
Length
|
952 mm / 37.5 in (including mirrors) | 952 mm / 37.5 in (including mirrors) | 2270 mm / 89.4 in ↑ | 2207 mm / 86.9 in. ↓ | 2207 mm / 86.9 in. |
|
Wet Weight
|
268 kg / 591 lbs | 268 kg / 591 lbs | 268 kg / 591 lbs | 268.1 kg / 591.0 lbs ↑ | 268.1 kg / 591.0 lbs |
|
Emissions
|
Closed-loop three-way catalytic converter, exhaust standard , Euro 4 | Closed-loop three-way catalytic converter, exhaust standard , Euro 4 | Regulated three-way catalytic converter, compliant with EU5 emission standard ↑ | Regulated three-way catalytic converter, compliant with Euro 5 emission standard | Regulated three-way catalytic converter, compliant with Euro 5 emission standard |
|
Tyres - Front
|
120/70 R19 | 120/70 R19 | 120/70 R19 | 120/70-R19 | 120/70-R19 |
|
Width
|
952 mm / 37.5 in (including mirrors) | 952 mm / 37.5 in (including mirrors) | 980 mm / 38.6 in ↑ | 953 mm / 37.5 in. ↓ | 953 mm / 37.5 in. |
|
Rake
|
25.5° | 25.5° | 25.5° | 24.1° ↓ | 24.9° ↑ |
|
Wheels - Front
|
3.00 x 19 | 3.00 x 19 in | 3.00 x 19 in | - | - |
|
Instrumentation
|
- | - | TFT colour display | TFT color display with connectivity | TFT color display with connectivity |
|
Wheels - Rear
|
4.50 x 17 | 4.50 x 17 in | 4.50 x 17 in | - | - |
|
Fuel Consumption
|
4.70 litres/100 km (21.3 km/l or 50.05 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) ↑ | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) |
|
Trail
|
95.4 mm / 3.8 in | 95.4 mm / 3.8 in | 95.4 mm / 3.8 in | 97 mm / 3.8 in. ↑ | 97 mm / 3.8 in. |
|
Wheel Travel - Front
|
210 mm / in | 210 mm / in | 210 mm / 8.3 in | 210 mm / 8.3 in. | 210 mm / 8.3 in. |
|
Wheel Travel - Rear
|
220 mm / 8.7 in | 220 mm / 8.7 in | 220 mm / 8.7 in | 220 mm / 8.7 in. | 220 mm / 8.7 in. |
|
Max Torque
|
143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" |
|
Starter
|
Electric 900W | Electric 900W | Electric 900W | Electric | Electric |
