BMW F 800GS Specs

2009 - 2024 • 10 variants

The BMW F 800GS is an enduro motorcycle produced from 2009 to 2024 across 10 variants. It is powered by a four stroke, parallel twin cylinder, dohc, 4 valves per cylinder displacing 798.00 cc. Peak power output is 85 hp. Peak torque is 80 Nm.

About the BMW F 800GS

BMW introduced the F 800GS as part of their Enduro / Off-Road range, with production running from 2008 to 2024. This technical reference page documents the full specification sheet for the BMW F 800GS, including engine displacement, power and torque figures, frame and suspension geometry, braking systems, and overall dimensions. Select a model year above to view year-specific technical data. Specifications are compiled from official manufacturer sources.

AdSense - 728Ã90

BMW F 800GS by Year

2024 BMW F 800GS View specs →

2018 BMW F 800GS View specs →

2016 BMW F 800GS View specs →

2015 BMW F 800GS View specs →

2014 BMW F 800GS View specs →

2013 BMW F 800GS View specs →

2012 BMW F 800GS View specs →

2011 BMW F 800GS View specs →

2010 BMW F 800GS View specs →

2009 BMW F 800GS View specs →

Spec Evolution

How key specs changed across production years.

Specification	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017	2018	2024
Fuel Control	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	-
Engine Type	Twin	Twin	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	Twin, four-stroke	-
Comments	-	-	-	Power Steering	Blata is from the Czech Republic.	-	-	-	Switchable ABS.	-	Ride-By-Wire. Riding Modes Rain and Road.	-
CO2	-	-	88.2 CO	88.2 CO	88.2 CO	87.9 CO ↓	88.2 CO2 g/km. (CO2 - Carbon dioxide emission) ↑	88.2 CO2 g/km. (CO2 - Carbon dioxide emission)	88.2 CO2 g/km. (CO2 - Carbon dioxide emission)	-	99.8 CO2 g/km. (CO2 - Carbon dioxide emission)	-
Seat Heigth -Alternate (in.)	-	33.5 inches	-	-	30.1 inches	-	-	-	-	-	-	-
Seat Heigth -Alternate (mm)	-	850 mm	-	-	765 mm	-	-	-	-	-	-	-
Seat Height	880 mm - 850 mm / 34.6 in. - 33.5 in.	880 mm - 850 mm / 34.6 in. - 33.5 in.	880 mm - 850 mm / 34.6 in. - 33.5 in.	880 mm - 850 mm / 34.6 in. - 33.5 in.	880 mm / 850 mm / 34.6 in. / 33.5 in.	880 mm - 820 mm / 34.6 in. - 32.3 in.	880 mm - 820 mm / 34.6 in. - 32.3 in.	880 mm / 820 mm / 34.6 in. / 32.3 in.	880 mm / 820 mm / 34.6 in. / 32.3 in.	880 mm / 820 mm / 34.6 in. / 32.3 in.	880 mm / 34.6 in.	815 mm / 32.1 in ↓
Displacement	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub-in	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	798 cc / 47.7 cub. in.	-	895 cc / 54.6 cu-in
Frame Type	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular frame in steal partly carrying the engine	Tubular steel space frame, load-bearing engine	Bridge-type frame, steel shell construction, load bearing engine
Brakes - Front	2 x ∅300mm discs, 4 piston calipers	2 x ∅300mm discs, 4 piston calipers	2 x ∅300mm discs, 4 piston calipers	2 x ∅300mm discs, 4 piston calipers	2 x ∅300mm discs, 4 piston calipers	2 x ∅300mm discs, 4 piston calipers, ABS	2 x ∅300mm discs, 4 piston calipers, ABS	2 x ∅300mm discs, 4 piston calipers, ABS	2 x ∅300mm discs, 4 piston calipers, ABS	2 x ∅300mm discs, 4 piston calipers, ABS	Double disc. ABS. Floating discs. Two-piston calipers.	2 x 305mm floating discs, 2-piston floating calipers
Wheelbase	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1577 mm / 62.1 in	1,573 mm / 61.9 in. ↓	1590 mm / 62.6 in ↑
Fuel Capacity	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / US 4.2 gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16 Litres / 4.2 US gal.	16.00 litres / 4.23 gallons	15 Litres / 4.0 US gal ↓
Brakes - Rear	Single ∅265mm disc, 2 piston caliper	Single ∅265mm disc, 2 piston caliper	Single ∅265mm disc, 2 piston caliper	Single ∅265mm disc, 2 piston caliper	Single ∅265mm disc, 2 piston caliper	Single ∅265mm disc, 2 piston caliper, ABS	Single ∅265mm disc, 2 piston caliper, ABS	Single ∅265mm disc, 2 piston caliper, ABS	Single ∅265mm disc, 2 piston caliper, ABS	Single ∅265mm disc, 2 piston caliper, ABS	Single disc. ABS. Floating disc. Single-piston caliper.	Single 265mm discs, single-piston floating caliper
Suspension - Front	∅43mm Marzocchi. Upside down forks	∅43mm Marzocchi. Upside down forks	∅43mm Marzocchi. Upside down forks	43mm Marzocchi. Upside down forks	∅43mm Marzocchi. Upside down forks	∅43mm Marzocchi upside down forks	43mm Marzocchi. Upside down forks,	43mm Marzocchi. Upside down forks	43mm Marzocchi. Upside down forks	43mm Marzocchi. Upside down forks	Upside-down telescopic fork, 43 mm	41mm Upside-down telescopic fork ↓
Suspension - Rear	Double strut swing arm aluminium coast in one piece,	Double strut swing arm aluminium coast in one piece,	Double strut swing arm aluminium coast in one piece,	Double strut swing arm aluminium coast in one piece	Double strut swing arm aluminium coast in one piece	Double strut swing arm aluminium coast in one piece	Double strut swing arm aluminium coast in one piece,	Double strut swing arm aluminium coast in one piece	Double strut swing arm aluminium coast in one piece	Double strut swing arm aluminium coast in one piece	Cast aluminium dual swing arm, WAD strut (travel related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Aluminium double-sided swinging arm, directly linked WAD central spring strut, spring base and rebound damping adjustable
Fuel System	Injection. Electronic intake pipe injection / digital engine management (BMS-K)	Injection. Electronic intake pipe injection / digital engine management (BMS-K)	Injection. Electronic intake pipe injection / digital engine management (BMS-K)	Injection. Electronic intake pipe injection / digital engine management (BMS-K)	Injection. Electronic intake pipe injection / digital engine management (BMS-K)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	-
Colours	-	Sunset yellow/black satin, Dark magnesium metallic matt	White, orange/black	Arctic Green Metallic Paint	Black/gray	Olive, blue, white	Kalamata, blue, white	White/black, red, white	Blackstorm Metallic, Racing Blue Metallic Matte, Light White	Light White, Ostra Grey, Black Storm Metallic	Racing Blue Metallic	-
Clutch	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiple-disc clutch in oil bath, mechanically operated	Multiple-disc wet clutch (anti hopping), mechanically operated
Bore x Stroke	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	82 x 75.8 mm	-	86 x 77 mm
Final Drive	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Endless O-ring chain with shock damping in rear wheel hub
Rims	-	-	-	Wire spoke	Wire spoke	Wire spoke wheels	Wire spoke wheels	Wire spoke wheels	Wire spoke wheels	Rim, front 2.15 x 21in.	Wire wheels	-
Height	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1350 mm / 53.1 in (excl. mirrors)	1,350 mm / 53.1 in. ↓	-
Length	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2320 mm / 91.3 in	2,300 mm / 90.6 in. ↓	2296 mm / 90.4in ↑
Compression Ratio	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	13.1:1 ↑
Wet Weight	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	207 kg / 456 lbs	217.0 kg / 478.4 lbs ↑	227 kg / 500 lbs ↑
Gear Ratios	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96	-	1st 2.833, 2nd 2.067, 3rd 1,600, 4th 1.308, 5th 1,103, 6th 0,968
Emissions	-	-	-	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	EU-4 ↓	EU-4	Closed-loop 3-way catalytic converter, emission standard EU-5 ↑
Tyres - Front	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90 - 21 54V	90/90-21	110/80 x R19 ↑
Width	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in (incl. mirrors)	945 mm / 37.2 in.	910m / 35.8 in ↓
Tyres - Rear	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70 - 17 69V	150/70-17	150/70 x R17
Wheels	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	Wire spoke	-	Aluminum cast wheels
Rake	26°	26°	26°	26°	26°	26°	26°	26°	26°	26°	26.0°	-
Wheels - Front	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	2.15 x 21"	-	2.5″ x 19″
Exhaust	-	Euro 3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	-	-	-	-	-	-	-	-
Wheels - Rear	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	4.25 x 17"	-	4.25″ x 17"
Fuel Consumption	5.1 l/100km 19.6 km/l / 45.9 US mpg	5.1 l/100km 19.6 km/l / 45.9 US mpg	5.1 l/100km 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	5.1 l/100km / 19.6 km/l / 45.9 US mpg	4.30 litres/100 km (23.3 km/l or 54.70 mpg) ↓	-
Transmission / Drive	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	6 Speed	-	Claw-shift 6-speed gearbox integrated in crankcase
Fuel Induction	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	Electronic intake injection, ∅45mm throttle bodies	-	Electronic injection
Fuel Reserve	-	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	3.79 litres / 1.00 gallons ↓	4.00 litres / 1.06 gallons ↑	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	2.70 litres / 0.71 gallons ↓	-
Trail	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 9.1 in.	117 mm / 4.6 in.	106.1mm / 4.2 in ↓
Wheel Travel - Front	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	230 mm / 9.1 in.	170 mm / 6.7 in ↓
Max Power	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	62.5 kW / 85 hp @ 7500 rpm	-	64 kW / 87hp @ 6750 rpm
Wheel Travel - Rear	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	215 mm / 8.5 in.	170mm / 6.7 in ↓
Ignition	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	-	Electronic
Max Torque	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm	83.00 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 5750 Revolutions ↑	91 Nm / 67.1 lb-ft @ 6750 rpm ↑
Power-to-Weight Ratio	0.4566 HP/kg	0.4566 HP/kg	0.4566 HP/kg	0.4566 HP/kg	0.2595 HP/kg ↓	0.4424 HP/kg ↑	0.4423 HP/kg	0.4450 HP/kg	0.4450 HP/kg	0.4450 HP/kg	-	-
Valve System	4	4	4	4	4	2 ↓	2	4 ↑	4	4	4	-
