| General |
| Comments | Adjustable Windscreen. On-board Computer. Removable Rear foot rests. | - |
| Year | - | 2026 |
| Colours | Racing Red, Light White/Cordoba Blue, Black Storm Metallic/Dark Slate Metallic Matte/Achat Grey | - |
| Make Model | - | KTM 690 Enduro R |
| Dimensions |
| Seat Height (mm) | 890 mm | - |
| Seat Height (in.) | 35.0 inches | - |
| Length (mm) | 2255 mm | - |
| Width (mm) | 980 mm | - |
| Width (in.) | 38.6 inches | - |
| Wheelbase (mm) | 1469 mm | - |
| Wheelbase (in.) | 57.8 inches | - |
| Length (in.) | 88.8 inches | - |
| Height (mm) | 1450 mm | - |
| Height (in.) | 57.1 inches | - |
| Seat Height | 890 mm / 35.0 in. | 935 mm / 36.8 in |
| Wheelbase | 1469 mm / 57.8 in. | 1506 mm / 59.3 in |
| Ground Clearance | - | 265 mm / 10.4 in |
| Height | 1450 mm / 57.1 in. | - |
| Length | 2255 mm / 88.8 in. | - |
| Width | 980 mm / 38.6 in. | - |
| Weights & Capacities |
| Wet Weight (lbs.) | 573.2 pounds | - |
| Wet Weight (kg) | 260.0 kg | 162 |
| Fuel Capacity (l) | 30.00 litres | - |
| Fuel Capacity (gal.) | 7.93 US gallons | - |
| Dry Weight (lbs.) | 505.0 pounds | - |
| Dry Weight (kg) | 229.1 | - |
| Dry Weight | 229.1 kg / 505.0 lbs | - |
| Fuel Capacity | 30.00 litres / 7.93 US gallons | 13.3 Litres / 3.5 US gal |
| Wet Weight | 260.0 kg / 573.2 lbs | 162 kg / 357 lbs |
| Performance |
| Top Speed (km/h) | 200.0 km/h | - |
| Top Speed (mph.) | 124.3 mph | - |
| Top Speed | 200.0 km/h / 124.3 mph | - |
| Max Power | - | 79 hp / 58.1 kW |
| Max Torque | 125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions" | 73 Nm / 54 lb-ft |
| Power-to-Weight Ratio | 0.5457 HP/kg | - |
| Engine |
| Displacement (ci) | 71.39 cubic inches | - |
| Displacement (cc) | 1170.0 cc | - |
| CO2 | 115.1 CO2 g/km. (CO2 - Carbon dioxide emission) | - |
| Engine Type | Two cylinder boxer, four-stroke | - |
| Bore x Stroke (mm) | 101.0 x 73.0 mm | - |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | - |
| Fuel Reserve (gal.) | 1.06 US gallons | - |
| Fuel Reserve (l) | 4.00 litres | - |
| Bore x Stroke (in,) | 4.0 x 2.9 inches | - |
| Displacement | - | 692.7 cc / 42.27 cu in |
| Engine Detail | Balance shaft | Single cylinder, 4-stroke, SOHC, 4-valve |
| Fuel System | Injection. Electronic intake pipe injection | - |
| Compression Ratio | 12.5:1 | - |
| Cooling System | - | Liquid cooled |
| Emissions | Three-way catalytic converter, compliant with EU4 emission standard | - |
| Exhaust | - | Stainless steel primary and secondary silencer |
| Fuel Consumption | 4.96 litres/100 km (20.2 km/l or 47.42 mpg) | - |
| Fuel Induction | - | Keihin EFI (throttle body 50 mm) |
| Fuel Reserve | 4.00 litres / 1.06 US gallons | - |
| Ignition | - | Keihin EMS with RBW, double ignition |
| Lubrication System | - | Pressure lubrication with 2 oil pumps |
| Starter | Electric | Electric |
| Valve System | 4 | - |
| Drivetrain |
| Clutch | Wet eight-disc clutch with anti-hopping function, hydraulically operated | PASC slipper clutch, hydraulically operated |
| Final Drive | Shaft drive (cardan) (final drive) | Chain, 520 X-ring |
| Gearbox | 6-speed | - |
| Transmission / Drive | - | 6-Speed |
| Chassis |
| Wheel Travel - Rear (mm) | 220 mm | - |
| Wheel Travel - Rear (in.) | 8.7 inches | - |
| Wheel Travel - Front (mm) | 210 mm | - |
| Wheel Travel - Front (in.) | 8.3 inches | - |
| Trail (mm) | 93 mm | - |
| Trail (in.) | 3.6 inches | - |
| Frame Type | Two-section frame, front- and bolted on rear frame, load-bearing engine | Chromium-molybdenum-steel trellis frame, powder coated |
| Suspension - Front | BMW Motorrad Telelever, front, stanchion diameter 37 mm | WP USD XPLOR 48 forks, compression and rebound adjustable |
| Suspension - Rear | BMW Motrrad EVO Paralever, rear | WP XPLOR shock absorber with Pro-Lever linkage, preload adjuster |
| Rake | 24.5° | - |
| Steering Head Angle | - | 62.3° |
| Subframe | - | Self-supporting plastic tank |
| Trail | 93 mm / 3.6 in. | 120 mm / 4.7 in |
| Wheel Travel - Front | 210 mm / 8.3 in. | 265 mm / 10.4 in |
| Wheel Travel - Rear | 220 mm / 8.7 in. | 250 mm / 9.8 in |
| Wheels & Brakes |
| Brakes - Front | Double disc. ABS. Four-piston calipers. | Single 300 mm disc, Brembo 2 piston floating caliper |
| Brakes - Rear | Single disc. ABS | Single 240 mm disc, Brembo single piston floating caliper |
| ABS | - | Bosch 9.1 MP (incl. Cornering ABS and offroad mode, disengageable) |
| Rims | Cross Spoke Wheels | - |
| Tyres - Front | 120/70-R19 | 90/90 -21 |
| Tyres - Rear | - | 140/80 -18 |
| Wheels - Front | - | Spoked wheels with aluminum rims, 1.85 x 21″ |
| Wheels - Rear | - | Spoked wheels with aluminum rims, 2.50 x 18″ |
