Yamaha FZ1 ABS Specs
2008–2011 • 2 variants
Yamaha has built the FZ1 ABS, a sport motorcycle, across 2 variants since 2008, most recently updated for 2011. Displacement comes in at 998.00 cc.
About the Yamaha FZ1 ABS
Documented here are the full technical specifications for the Yamaha FZ1 ABS, a Naked bike motorcycle with a production run from 2008 to 2013. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.
Yamaha FZ1 ABS by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2008
|
2009
|
2010
|
2011
|
2013
|
|
Engine Type
|
In-line four | In-line four | In-line four, four-stroke | In-line four, four-stroke | In-line four, four-stroke |
|
Dry Weight
|
194 kg / 427.7 lbs | - | - | 230 kg / 507.0 lbs | 210.5 kg / 464.1 lbs ↓ |
|
Brakes - Front
|
Double disc. ABS | Double disc. ABS | Double disc | Double disc. Anti-lock braking | Double disc. ABS. Floating disc. Four-piston calipers. |
|
Wheelbase
|
1,460 mm / 57.5 in. | 1,460 mm / 57.5 in. | 1,460 mm / 57.5 in. | 1,460 mm / 57.5 in. | 1,461 mm / 57.5 in. |
|
Fuel Capacity
|
18.00 litres / 4.76 gallons | 18.00 litres / 4.76 gallons | 18.00 litres / 4.76 gallons | 18.00 litres / 4.76 gallons | 18.17 litres / 4.80 gallons ↑ |
|
Brakes - Rear
|
Single disc. ABS | Single disc. ABS | Single disc | Single disc | Single disc. ABS. Single-piston caliper. |
|
Suspension - Front
|
Telescopic upside down forks | Telescopic forks | Telescopic forks | Telescopic forks | Upside-down telescopic fork |
|
Suspension - Rear
|
Swingarm (link suspension) | Swingarm (link suspension) | Swingarm (link suspension) | Swingarm, (link suspension) | Linked monoshock with spring preload adjustment |
|
Fuel System
|
Injection | Injection | Injection | Injection. EFI | Injection |
|
Colours
|
- | Yellow, black, gray | White, black, blue | Hunter Green, Steel Blue, Red | Black, white |
|
Height
|
1,060 mm / 41.7 in. | 1,060 mm / 41.7 in. | 1,060 mm / 41.7 in. | 1,205 mm / 47.4 in. ↑ | 1,204 mm / 47.4 in. |
|
Length
|
2,140 mm / 84.3 in. | 2,140 mm / 84.3 in. | 2,140 mm / 84.3 in. | 2,140 mm / 84.3 in. | 2,141 mm / 84.3 in. |
|
Warranty
|
- | - | - | 6 Month (Limited Factory Warranty) | 1 year / 5000 miles limited warranty. ↓ |
|
Wet Weight
|
- | 214.0 kg / 471.8 lbs | 214.0 kg / 471.8 lbs | 226.0 kg / 498.2 lbs ↑ | 221.0 kg / 487.2 lbs ↓ |
|
Primary Drive
|
- | - | - | 2WD; Yamaha Ultramatic® V-Belt / Forward, Neut.,Rev. | O-ring chain. Constant mesh. |
|
Ignition
|
TCI (digital) | TCI (digital) | TCI | TCI (digital) | Digital TCI: Transistor Controlled Ignition with 32-bit ECU |
|
Max Torque
|
106.00 | 106.00 | 106.00 Nm (10.8 kgf-m or 78.2 ft.lbs) @ 10800 | 106.00 Nm (10.8 kgf-m or 78.2 ft.lbs) @ 8000 | 106.00 Nm (10.8 kgf-m or 78.2 ft.lbs) @ 8000 |
|
Power-to-Weight Ratio
|
0.7624 HP/kg | - | - | - | 0.1143 HP/kg |
|
Valve System
|
- | - | - | 4 | 5 ↑ |
