2003 Yamaha FJR 1300 / ABS Overview
For 2003, Yamaha offers the FJR 1300 / ABS as a sport touring motorcycle with 1298 cc on tap. The 2003 Yamaha FJR 1300 / ABS is built around a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder engine, a compression ratio of 10.8:1. Out on the road, the FJR 1300 / ABS delivers 145 hp @ 8500 rpm of peak power and 125 Nm @ 6000 rpm of torque. Flat out, it's quoted at 249 km/h. In everyday use, the 2003 FJR 1300 / ABS tips the scales at 291 kg, carries a 25-litre fuel tank, offers a seat height of 805 mm and spans a 1545 mm wheelbase. That's roughly 39.7 kg heavier than the average sport touring motorcycle in our database. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2003 Yamaha FJR 1300 / ABS spec sheet below.
2003 FJR 1300 / ABS - Pros & Cons
Strengths
-
⚡
Strong power output: Peak output on the FJR 1300 / ABS is 145 hp @ 8500 rpm and 125 Nm @ 6000 rpm of torque - strong numbers for what it is.
-
⛽
Large fuel range: With a 25-litre tank, this isn't a bike you'll be stopping for fuel every hour - a real asset on longer trips.
-
⚙️
Low-maintenance final drive: Shaft final drive is about as close to maintenance-free as motorcycle drivetrains get.
Considerations
-
ℹ️
Age-related wear: No particular mechanical concern flags for the FJR 1300 / ABS - condition on any used example comes down to how well it's been looked after.
Wear Points & Servicing Notes
Cooling system servicing
With Liquid cooled,, thermal management is largely automatic, but the coolant has a service life of its own - replace it on the manufacturer's interval to protect the water passages and thermostat.
Brake disc and pad wear
2x 320mm discs 4 piston calipers up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.
Suspension condition on used examples
Suspension duties are handled by 48mm Soqi telescopic fork w/adjustable preload, compression and rebound damping up front and Single shock, link-type, w/adjustable preload and rebound damping at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.
Final drive maintenance
Shaft final drive on the FJR 1300 / ABS removes chain and belt maintenance entirely - the trade-off is a little extra unsprung weight and periodic gear-oil changes.
Frame & chassis check
The Aluminium, twin spar chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.
Handling the weight at a standstill
The FJR 1300 / ABS's 291 kg kerb weight is worth factoring into how you handle it at a standstill - parking-lot manoeuvres need a bit more deliberate technique than on a lighter machine.
FJR 1300 / ABS - Buying & Maintenance Guide
What to check before buying
A pre-purchase check on the 2003 Yamaha FJR 1300 / ABS should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept FJR 1300 / ABS settles to a smooth idle within seconds.
Oil and filter changes
Oil changes are the cheapest insurance you can buy for a FJR 1300 / ABS's engine - keep to the manufacturer's interval rather than stretching it. Use the viscosity grade the manual specifies, not whatever's on sale.
Carburetor upkeep
A FJR 1300 / ABS that's sat unused is almost always a carb-cleaning job before it runs right again - float bowls and pilot jets first, since they clog before anything else.
2003 Yamaha FJR 1300 / ABS - Frequently Asked Questions
What engine does the 2003 Yamaha FJR 1300 / ABS have?
The 2003 Yamaha FJR 1300 / ABS uses a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder. engine with 1298 cc of displacement. It is liquid cooled,.
What is the top speed of the 2003 Yamaha FJR 1300 / ABS?
The 2003 Yamaha FJR 1300 / ABS has a factory-quoted top speed of 249 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.
How much does the 2003 Yamaha FJR 1300 / ABS weigh?
The 2003 Yamaha FJR 1300 / ABS weighs 291 kg. This is the manufacturer's wet figure.
How much power does the 2003 Yamaha FJR 1300 / ABS make?
The 2003 Yamaha FJR 1300 / ABS produces 145 hp @ 8500 rpm of power and 125 Nm @ 6000 rpm of torque. These are peak figures.
What is the fuel tank capacity of the 2003 Yamaha FJR 1300 / ABS?
The 2003 Yamaha FJR 1300 / ABS has a 25-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 416-500 km between stops.
Is the 2003 Yamaha FJR 1300 / ABS suitable for shorter riders?
The 2003 Yamaha FJR 1300 / ABS has a seat height of 805 mm. This is a moderate seat height that suits a wide range of rider heights.
What brakes does the 2003 Yamaha FJR 1300 / ABS have?
The 2003 Yamaha FJR 1300 / ABS uses 2x 320mm discs 4 piston calipers at the front and Single 283mm disc 2 piston caliper at the rear.
What tyre sizes does the 2003 Yamaha FJR 1300 / ABS use?
The 2003 Yamaha FJR 1300 / ABS runs 120/70 ZR17 front and 180/55 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2003 Yamaha FJR 1300 / ABS have?
The 2003 Yamaha FJR 1300 / ABS is fitted with a 5 Speed transmission.
Yamaha FJR 1300 / ABS Spec Evolution
The Yamaha FJR 1300 / ABS was produced across 3 model years (2003-2005). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.
| Specification |
2003 |
2004 |
2005 |
| Top Speed |
249 km/h / 154.7 mph |
249 km/h / 154.7 mph |
249 km/h / 154.7 mp |
| Clutch |
Wet, multiple discs, hydraulic operated |
Wet, multiple discs, cable operated |
Wet, multiple discs, cable operated |
Key Specifications
Engine
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Power
145 hp / 105.7 kW @ 8500 rpm
Torque
125 Nm / 13.7kgf-m / 99.1 ft-lb @ 6000 rpm
Top Speed
249 km/h / 154.7 mph
Weight
291 kg / 641.5 lbs
Fuel Capacity
25 Liters / 6.6 US gal
Advertisement
Full 2003 Yamaha FJR 1300 / ABS Specifications
Year
2003
Make Model
Yamaha FJR 1300 / ABS
Seat Height
805 mm / 31.7 in to 825 mm / 32.5 in
Wheelbase
1545 mm / 60.8 in
Ground Clearance
130 mm / 5.1 in
Height
1450mm / 57.1 in
Length
2230 mm / 87.8 in
Width
750 mm / 29.5 in
Dry Weight
264 kg / 582 lbs
Fuel Capacity
25 Liters / 6.6 US gal
Wet Weight
291 kg / 641.5 lbs
Displacement
1298 cc / 79.2 cu-in cc / 79.2 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Bore x Stroke
79 x 66.2 mm
Compression Ratio
10.8:1
Cooling System
Liquid cooled,
Fuel Consumption
18.5 km/lit
Fuel Induction
Mikuni 42mm throttle body F.I.
Ignition
CDI
Lubrication
Wet sump
Spark Plug
NGK, CR8E
Starter
Electric
Clutch
Wet, multiple discs, hydraulic operated
Final Drive
Shaft
Transmission / Drive
5 Speed
Frame Type
Aluminium, twin spar
Suspension - Front
48mm Soqi telescopic fork w/adjustable preload, compression and rebound damping
Suspension - Rear
Single shock, link-type, w/adjustable preload and rebound damping
Rake
26°
Trail
109 mm / 4.3 in
Wheel Travel - Front
137 mm / 5.3 in
Wheel Travel - Rear
122 mm / 5.1 in
Brakes - Front
2x 320mm discs 4 piston calipers
Brakes - Rear
Single 283mm disc 2 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
180/55 ZR17
Specifications are compiled from manufacturer documentation and cross-referenced
technical sources, and corrected on an ongoing basis.
