Key Specifications
Engine
In-line four, four-stroke
Power
110.3 kW / 148 hp @ 12800 rpm
Torque
86.3 Nm / 8.8 kgf-m / 64 ft-lb @ 11200 rpm
Top Speed
270.7 km/h / 168 mph
Fuel Capacity
17.00 litres
Full 2020 Suzuki GSX-R 750 Specifications
Year
2020
Colours
Glass Sparkle Black/Pearl Glacier White, Metallic Matte Black No.2/Glass Sparkle Black
Make Model
Suzuki GSX-R 750
Warranty
12 month unlimited mileage limited warranty.
Width (mm)
710 mm
Width (in.)
28.0 inches
Wheelbase (mm)
1390 mm
Wheelbase (in.)
54.7 inches
Seat Height (mm)
810 mm
Seat Height (in.)
31.9 inches
Length (mm)
2030 mm
Length (in.)
79.9 inches
Height (mm)
1135 mm
Height (in.)
44.7 inches
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
810 mm / 31.8 in.
Wheelbase
1390 mm / 54.7 in.
Ground Clearance
130 mm / 5.1 in
Height
1125 mm / 44.6 in.
Length
2030 mm / 79.9 in.
Width
710 mm / 28.0 in.
Dry Weight (kg)
156
Wet Weight (lbs.)
418.9 pounds
Wet Weight (kg)
190.0 kg
Fuel Capacity (l)
17.00 litres
Fuel Capacity (gal.)
4.49 US gallons
Dry Weight
156 kg / 344 lbs
Fuel Capacity
17 Litres / 4.5 US gal / 3.7 Imp gal
Wet Weight
190 kg / 418 lbs
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
Displacement (ci)
45.77 cubic inches
Bore x Stroke (in,)
2.8 x 1.9 inches
Bore x Stroke (mm)
70.0 x 48.7 mm
Displacement (cc)
750.0 cc
Displacement
749 c / 45.7 cub. in.
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Fuel System
Injection. Suzuki Dual Throttle Valve fuel injection
Bore x Stroke
70 x 48.7 mm
Compression Ratio
12.5:1
Cooling System
Liquid. High capacity large trapezoidal-shaped radiator which includes compact cooling fan assembly designed for improved air flow.
Engine Lubrication
Wet sump
Engine Oil Specification
Synthetic,10W/40
Exhaust
Four-into-one stainless steel
Fuel Consumption
5.5 l/100 km / 18.3 km/l / 43 US mpg / 51 Imp mpg
Fuel Induction
New 32 bit ECM features 1024 kilobytes of ROM for maximum engine performance working in conjunction with the new S-DMS engine management system
Ignition
Digital DC-CDI
Lubrication
Wet sump
Spark Plug
NGK, CR9E
Starter
Electric
Valve System
4
Clutch
Wet, multiple discs
Final Drive
Chain, RK525ROZ5Y, 116 links
Gear Ratios
1st 2.79 / 2nd 2.05 / 3rd 1.71 / 4th 1.50 / 5th 1.35 / 6th 1.20:1
Gearbox
6-speed
Primary Drive
RK525ROZ5Y, 116 links, Chain
Transmission / Drive
6 Speed, constant mesh
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Rear (in.)
5.1 inches
Wheel Travel - Rear (mm)
130 mm
Frame Type
Ultra-lightweight frame built entirely of aluminum alloy castings.
Suspension - Front
Showa inverted 41 mm cartridge front forks fully adjustable for high and low speed compression, spring preload, and rebound damping
Suspension - Rear
Showa 41mm aluminum alloy rear shock with a 16mm rod diameter are fully adjustable for high and low speed compression, spring preload and rebound damping
Rake
23.8°
Trail
97 mm / 3.8 in.
Wheel Travel - Front
120 mm / 4.7 in.
Wheel Travel - Rear
130 mm / 5.1 in.
Instrumentation
Analog tachometer and LCD panel with speed, odometer, dual trip meter, reserve trip meter, clock, coolant temperature/oil pressure indicator, S-DMS, and gear position indicators
Lighting system
Vertically stacked high- and low-beam halogen bulbs
Brakes - Front
2 x 310 mm Discs, radial-mount opposed-four-piston Brembo 4 piston monoblock calipers
Brakes - Rear
Single 220 mm disc, Nissin single piston caliper
Rims
Three-spoke cast aluminum alloy
Rims - Front
3.8 x 17
Rims - Rear
5.5 x 17
Tyres - Front
120/70 ZR17
Tyres - Rear
180/55 ZR17
Wheels
Aluminum, 3 spoke
