2009 Suzuki GSX-R 750 Specifications

Name: 2009 Suzuki GSX-R 750
Brand: Suzuki

Sport • Specs last verified 13 July 2026

No images available

Tap to enlarge

2009 Suzuki GSX-R 750 Overview

The 2009 Suzuki GSX-R 750 is a sport motorcycle built around 749 c of displacement. Under the tank sits an In-line four engine running DOHC valve actuation, a compression ratio of 12.5:1. 2009 Suzuki GSX-R 750 delivers 110.3 kW @ 12800 rpm of peak power and 86.3 Nm @ 11200 rpm of torque. The factory-quoted top speed stands at 270.7 km/h, making it a capable performer in its class. From a practical standpoint, the 2009 GSX-R 750 tips the scales at 198 kg, carries a 17-litre fuel tank, offers a seat height of 810 mm and spans a 1390 mm wheelbase. Scroll down for the complete 2009 Suzuki GSX-R 750 spec sheet covering every technical detail from suspension travel to tyre sizes.

2009 GSX-R 750 - Pros & Cons

Strengths

Strong power output: 2009 Suzuki GSX-R 750 makes 110.3 kW @ 12800 rpm with 86.3 Nm @ 11200 rpm of torque - competitive figures for its class.

Considerations

Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.

Wear Points & Servicing Notes

Heat management in traffic

GSX-R 750's air-cooled design means engine-bay temperatures build up more in stop-start traffic than on a liquid-cooled equivalent - a function of the cooling method itself, not a defect. Mesh riding gear and avoiding prolonged idling help in hot climates.

Valve clearance checks

DOHC valve actuation on the GSX-R 750 means clearances should be checked at the manufacturer's specified interval - they can tighten as mileage accumulates, and a light top-end tick is usually the first sign.

Brake disc and pad wear

The 2 x 310 mm Discs, radial-mount opposed-four-piston Tokico 4 piston calipers front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Suspension condition on used examples

Up front, the GSX-R 750 runs Showa inverted 41 mm cartridge front forks fully adjustable for high and low speed compression, spring preload, and rebound damping and Showa 41mm aluminum alloy rear shock with a 16mm rod diameter are fully adjustable for high and low speed compression, spring preload and rebound damping at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.

Final drive maintenance

Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.

Frame & chassis check

The frame is Ultra-lightweight frame built entirely of aluminum alloy castings. - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.

GSX-R 750 - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2009 Suzuki GSX-R 750, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained GSX-R 750 should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any GSX-R 750. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

Carburetor upkeep

Keep the carburetors clean and free of deposits. If the GSX-R 750 has been stored, strip and clean the carb float bowls before attempting to start it. Pilot jets are the first to block and the last to be checked - always include them in any carb rebuild.

Valve clearance service

Check that valve clearances have been adjusted at the correct intervals on any used GSX-R 750. A bike with clearances out of spec doesn't always feel obviously wrong - but tight clearances accelerate valve seat wear. Ask for service documentation proving it's been done.

2009 Suzuki GSX-R 750 - Frequently Asked Questions

What engine does the 2009 Suzuki GSX-R 750 have?

The 2009 Suzuki GSX-R 750 uses an In-line four engine with 749 c of displacement. It is liquid. high capacity large trapezoidal-shaped radiator which includes compact cooling fan assembly designed for improved air flow..

What is the top speed of the 2009 Suzuki GSX-R 750?

The 2009 Suzuki GSX-R 750 has a factory-quoted top speed of 270.7 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.

How much does the 2009 Suzuki GSX-R 750 weigh?

The 2009 Suzuki GSX-R 750 weighs 198 kg. This is the manufacturer's wet figure.

How much power does the 2009 Suzuki GSX-R 750 make?

The 2009 Suzuki GSX-R 750 produces 110.3 kW @ 12800 rpm of power and 86.3 Nm @ 11200 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2009 Suzuki GSX-R 750?

The 2009 Suzuki GSX-R 750 has a 17-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 283-340 km between stops.

Is the 2009 Suzuki GSX-R 750 suitable for shorter riders?

The 2009 Suzuki GSX-R 750 has a seat height of 810 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2009 Suzuki GSX-R 750 have?

The 2009 Suzuki GSX-R 750 uses 2 x 310 mm Discs, radial-mount opposed-four-piston Tokico 4 piston calipers at the front and Single 220 mm disc, Tokico 2 piston caliper at the rear.

What tyre sizes does the 2009 Suzuki GSX-R 750 use?

The 2009 Suzuki GSX-R 750 runs 120/70 ZR17 front and 180/55 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2009 Suzuki GSX-R 750 have?

The 2009 Suzuki GSX-R 750 is fitted with a 6 Speed, constant mesh transmission.

Suzuki GSX-R 750 Spec Evolution

The Suzuki GSX-R 750 was produced across 38 model years (1985-2026). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	1985	1986	1987	1988	1989	1990	1991	1993	1995	1996	1997	1998	1999	2000	2001	2002	2003	2004	2005	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017	2018	2019	2020	2021	2022	2023	2026
Max Power	-	-	-	-	80.2 kW /	83.8 kW /	83.8 kW /	-	83.5 kW / 112 hp @ 10500 rpm	-	-	-	-	-	-	-	-	-	-	110.3 kW /	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	110.3 kW / 148 hp @ 12800 rpm	-	-	-	110.3 kW / 148 hp @ 12800 rpm
Wet Weight	201.0 kg / 443.1 lbs	201.0 kg / 443.1 lbs	201.0 kg / 443.1 lbs	228.0 kg / 502.7 lbs	223.6 kg / 493 lbs.	234 kg / 515.8 lbs.	249 kg / 549 lbs.	-	229.5 kg / 506 lbs.	-	-	-	205.0 kg / 451.9 lbs	-	-	-	-	-	-	-	-	198 kg / 419 lbs	198 kg / 419 lbs	198 kg / 419 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190 kg / 418 lbs	190.0 kg / 418.9 lbs	190.0 kg / 418.9 lbs	190.0 kg / 418.9 lbs	190 kg / 418 lbs
Dry Weight	-	-	-	-	195 kg / 430 lbs	193 kg / 425 lbs	208 kg / 459 lbs	208 kg / 458.6 lbs	199 kg / 438.6 lbs	179 kg / 394.6 lbs	186 kg / 410.1 lbs	179 kg / 394.6 lbs	-	166 kg / 366.0 lbs	166 kg / 366.0 lbs	166 kg / 366.0 lbs	166 kg / 366.0 lbs	163 kg / 359.4 lbs	163 kg / 359.4 lbs	163 kg / 359 lbs	163 kg / 359 lbs	165 kg / 363.8 lbs	163 kg / 359 lbs	163 kg / 359.4 lbs	156 kg / 344 lbs	156 kg / 343.9 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	156 kg / 344 lbs	-	-	-	156 kg / 344 lbs
Engine Detail	-	-	-	-	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	-	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	-	-	-	-	-	-	-	-	-	-	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.	Titanium alloy valves	Titanium alloy valves	Titanium alloy valves	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Engine Type	In-line four	In-line four	In-line four	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four	-	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	In-line four, four-stroke	-
Top Speed	-	-	-	-	248.3 km/h / 154.3 mph	247.3 km/h / 153.6 mph	247.3 km/h / 153.6 mph	-	246 km/h / 153 mph	-	265.0 km/h / 164.7 mph	265.0 km/h / 164.7 mph	265.0 km/h / 164.7 mph	280.0 km/h / 174.0 mph	275.0 km/h / 170.9 mph	-	-	-	-	279.3 km/h / 173.5 mph	279.3 km/h / 173.5 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	270.7 km/h / 168 mph	-	-	-	270.7 km/h / 168 mph
Seat Height	-	-	-	-	-	790 mm / 31.1 in	790 mm / 31.1 in	790 mm / 31.1 in.	795 mm / 31.3	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	829 mm / 32.6 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	830 mm / 32.7 in.	825 mm / 32.5 in.	825 mm / 32.5 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.8 in.	810 mm / 31.9 in.	810 mm / 31.9 in.	810 mm / 31.9 in.	810 mm / 31.8 in.
Fuel Capacity	19.00 litres / 5.02 gallons	19.00 litres / 5.02 gallons	19.00 litres / 5.02 gallons	21.00 litres / 5.55 gallons	21 Litres / 5.5 US gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21.00 litres / 5.55 gallons	21 Litres / 5.5 US gal / 4.6 Imp gal	-	-	-	18.00 litres / 4.76 gallons	18.00 litres / 4.76 gallons	18.00 litres / 4.76 gallons	18.00 litres / 4.76 gallons	18.00 litres / 4.76 gallons	17.00 litres / 4.49 gallons	17.00 litres / 4.49 gallons	16.5 Litres / 4.4 US gal / 3.6 Imp gal	16.5 Litres / 4.4 US gal / 3.6 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17.00 litres / 4.49 US gallons	17.00 litres / 4.49 US gallons	17.00 litres / 4.49 US gallons	17 Litres / 4.5 US gal / 3.7 Imp gal

Key Specifications

Engine

In-line four

Power

110.3 kW / 148 hp @ 12800 rpm

Torque

86.3 Nm / 8.8 kgf-m / 64 ft-lb @ 11200 rpm

Top Speed

270.7 km/h / 168 mph

Weight

198 kg / 419 lbs

Fuel Capacity

17 Litres / 4.5 US gal / 3.7 Imp gal

Full 2009 Suzuki GSX-R 750 Specifications

Year 2009

Colours Blue/White, Orange/Black, Matte Black/Black

Make Model Suzuki GSX-R 750

Ground Clearance (mm) 130 mm

Ground Clearance (in.) 5.1 inches

Seat Height 810 mm / 31.8 in.

Wheelbase 1390 mm / 54.7 in.

Ground Clearance 130 mm / 5.1 in

Height 1125 mm / 44.6 in.

Length 2040 mm / 80.4 in.

Width 715 mm / 28.5 in.

Dry Weight 163 kg / 359 lbs

Fuel Capacity 17 Litres / 4.5 US gal / 3.7 Imp gal

Wet Weight 198 kg / 419 lbs

Top Speed 270.7 km/h / 168 mph

Acceleration (0-100 km/h) 3.2 sec

Max Power 110.3 kW / 148 hp @ 12800 rpm

Max Torque 86.3 Nm / 8.8 kgf-m / 64 ft-lb @ 11200 rpm

Standing Start ¼ Mile 10.7 sec

Top Gear Acceleration 4.5 sec

Top Gear Acceleration 3.9 sec

Top Gear Acceleration 4.1 sec

Stroke 4

Fuel Control DOHC

Engine Type In-line four

Displacement 749 c / 45.7 cub. in.

Engine Detail Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Fuel System Injection

Bore x Stroke 70 x 48.7 mm

Compression Ratio 12.5:1

Cooling System Liquid. High capacity large trapezoidal-shaped radiator which includes compact cooling fan assembly designed for improved air flow.

Engine Lubrication Wet sump

Engine Oil Specification Synthetic,10W/40

Exhaust Suzuki Advanced Exhaust System (SAES) with under engine muffler layout and Suzuki Exhaust Tuning (SET) system.

Fuel Consumption 5.5 l/100 km / 18.3 km/l / 43 US mpg / 51 Imp mpg

Fuel Induction New 32 bit ECM features 1024 kilobytes of ROM for maximum engine performance working in conjunction with the new S-DMS engine management system

Ignition Digital DC-CDI

Lubrication Wet sump

Spark Plug NGK, CR9E

Starter Electric

Clutch Wet, multiple discs

Final Drive Chain, RK525ROZ5Y, 116 links

Gear Ratios 1st 2.79 / 2nd 2.05 / 3rd 1.71 / 4th 1.50 / 5th 1.35 / 6th 1.20:1

Gearbox 6-speed

Transmission / Drive 6 Speed, constant mesh

Frame Type Ultra-lightweight frame built entirely of aluminum alloy castings.

Suspension - Front Showa inverted 41 mm cartridge front forks fully adjustable for high and low speed compression, spring preload, and rebound damping

Suspension - Rear Showa 41mm aluminum alloy rear shock with a 16mm rod diameter are fully adjustable for high and low speed compression, spring preload and rebound damping

Rake 23.8°

Trail 97 mm / 3.8 in.

Wheel Travel - Front 120 mm / 4.7 in.

Wheel Travel - Rear 130 mm / 5.1 in.

Brakes - Front 2 x 310 mm Discs, radial-mount opposed-four-piston Tokico 4 piston calipers

Brakes - Rear Single 220 mm disc, Tokico 2 piston caliper

Rims - Front 3.8 x 17

Rims - Rear 5.5 x 17

Tyres - Front 120/70 ZR17

Tyres - Rear 180/55 ZR17

Wheels Aluminum, 3 spoke

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
