Key Specifications
Engine
Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder
Power
32 kW / 43 hp @ 9500 rpm
Torque
35.3 Nm / 26 lb-ft @7250 rpm
Weight
149 kg / 328.5 lbs
Fuel Capacity
10 Liters / 2.64 US gal
Full 2018 KTM RC 390 Specifications
Year
2018
Make Model
KTM RC 390
Seat Height
820 mm / 32.2 in
Wheelbase
1340 mm / 52.7 in
Ground Clearance
179 mm / 7.0 in
Height
1267 mm / 49.9 in
Length
2002 mm / 78.8 in
Width
873 mm / 34.4 in
Dry Weight (kg)
149
Dry Weight
149 kg / 328.5 lbs
Fuel Capacity
10 Liters / 2.64 US gal
Displacement
373 cc / 22.7 cu-in
Engine Detail
Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Cooling System
Liquid Cooled
Engine Management
Bosch EMS with RBW
Fuel Induction
Bosch Injection
Lubrication
Forced oil lubrication with 2 Eaton pumps
Starter
Electric
Clutch
Wet multi-disc clutch / mechanically operated
Final Drive
Chain 5/8 x 1/4" X‑Ring
Transmission / Drive
6 Speed
Frame Type
Tubular space frame made from steel, powder-coated
Suspension - Front
WP Suspension Up Side Down
Suspension - Rear
WP Monoshock
Steering Head Angle
65 °
Trail
100mm / 3.9 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
150 mm / 5.9 in
Brakes - Front
Single 320 mm disc 4 piston radial caliper
Brakes - Rear
Single 230 mm disc 1 piston caliper
Tyres - Front
110/70 R17
Tyres - Rear
150/60 R17
