KTM RC 390 Specs

2015 - 2022 • 6 variants

The KTM RC 390 is a sport motorcycle produced from 2015 to 2022 across 6 variants. It is powered by a four stroke, single cylinder, dohc with finger followers, 4 valve per cylinder. Peak power output is 43 hp. Peak torque is 35.3 Nm.

About the KTM RC 390

The RC 390 represents KTM's contribution to the Sport motorcycle segment, spanning the 2014 to 2022 production run. Our database contains detailed technical specifications for each model year, covering powertrain details, chassis geometry, suspension and braking systems, fuel capacity, and certified weight figures. Use the year navigation above to drill into year-specific data. All specifications are referenced from official KTM documentation.

AdSense - 728Ã90

KTM RC 390 by Year

2022 KTM RC 390 View specs →

2020 KTM RC 390 View specs →

2018 KTM RC 390 View specs →

2017 KTM RC 390 View specs →

2016 KTM RC 390 View specs →

2015 KTM RC 390 View specs →

Spec Evolution

How key specs changed across production years.

Specification	2014	2015	2016	2017	2018	2019	2020	2022
Frame Type	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Tubular space frame made from steel, powder-coated	Steel trellis frame, powder coated and bolt-on subframe
Dry Weight	139 kg / 306.4 lbs	139 kg / 306.4 lbs	139 kg / 306.4 lbs	149 kg / 328.5 lbs ↑	149 kg / 328.5 lbs	149 kg / 328.5 lbs	149 kg / 328.5 lbs	155 kg / 341.7 lbs ↑
Seat Height	820 mm / 32.2 in	820 mm / 32.2 in	820 mm / 32.2 in	820 mm / 32.2 in	820 mm / 32.2 in	820 mm / 32.2 in	820 mm / 32.2 in	824 mm / 32.4 in ↑
Engine Detail	Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder, DOHC with finger followers, 4 Valve per cylinder	Four stroke, single cylinder, DOHC with finger followers, 4 valves per cylinder
Brakes - Front	Single 300 mm disc 4 piston radial caliper	Single 300 mm disc 4 piston radial caliper	Single 300 mm disc 4 piston radial caliper	Single 320 mm disc 4 piston radial caliper ↑	Single 320 mm disc 4 piston radial caliper	Single 320 mm disc 4 piston radial caliper	Single 320 mm disc 4 piston radial caliper	Single 320 mm disc 4 piston radial fixed ByBre calliper
Fuel Capacity	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	10 Liters / 2.64 US gal	13.7 Liters / 3.6 US gal ↑
Brakes - Rear	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston caliper	Single 230 mm disc 1 piston floating ByBre calliper
Ground Clearance	179 mm / 7.0 in	179 mm / 7.0 in	179 mm / 7.0 in	179 mm / 7.0 in	179 mm / 7.0 in	179 mm / 7.0 in	179 mm / 7.0 in	158 mm / 6.2 in ↓
Suspension - Front	WP Suspension Up Side Down	WP Suspension Up Side Down	WP Suspension Up Side Down	WP Suspension Up Side Down	WP Suspension Up Side Down	WP Suspension Up Side Down	WP Suspension Up Side Down	USD WP APEX 43
Suspension - Rear	WP Monoshock	WP Monoshock	WP Monoshock	WP Monoshock	WP Monoshock	WP Monoshock	WP Monoshock	WP APEX - Monoshock
Clutch	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	Wet multi-disc clutch / mechanically operated	PASC antihopping clutch, mechanically operated
Final Drive	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	Chain 5/8 x 1/4" X‑Ring	520 X-Ring ↑
Transmission / Drive	5 Speed	5 Speed	5 Speed	6 Speed ↑	6 Speed	6 Speed	6 Speed	6 Speed
Steering Head Angle	65 °	65 °	65 °	65 °	65 °	65 °	65 °	66.5 ° ↑
Max Torque	3.6 kgm /35.3 Nm @7250rpm	3.6 kgm /35.3 Nm @7250rpm	3.6 kgm /35.3 Nm @7250rpm	35.3 Nm / 26 lb-ft @7250 rpm ↑	35.3 Nm / 26 lb-ft @7250 rpm	35.3 Nm / 26 lb-ft @7250 rpm	35.3 Nm / 26 lb-ft @7250 rpm	37 Nm / 27.2 lb-ft ↑
Lubrication	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Forced oil lubrication with 2 Eaton pumps	Wet sump
