2022 KTM 250 SX-F Specifications

Name: 2022 KTM 250 SX-F
Brand: KTM

Cross / motocross • Specs last verified 13 July 2026

No images available

Tap to enlarge

2022 KTM 250 SX-F Overview

For 2022, KTM offers the 250 SX-F as a cross / motocross motorcycle with 249.9 cc on tap. The 2022 KTM 250 SX-F is built around a Single cylinder, four-stroke engine. Internally, bore and stroke are 78 x 52.3 mm. In everyday use, the 2022 250 SX-F tips the scales at 99 kg, carries a 7.50-litre fuel tank, offers a seat height of 950 mm and spans a 1495 mm wheelbase. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2022 KTM 250 SX-F spec sheet below.

2022 250 SX-F - Pros & Cons

Strengths

Factory engineering: There's nothing exotic about the 2022 KTM 250 SX-F's spec sheet - just solid, proven engineering for what it's meant to do.

Considerations

Tall seat height: A 950 mm seat puts flat-footing out of reach for a lot of riders - sit on it in person before committing.
Modest fuel capacity: A 7.50-litre tank keeps things light but means budgeting for more frequent fuel stops on any longer ride.
Chain final drive upkeep: A chain drivetrain is the most common setup in its class, but it's also the one that demands the most regular hands-on maintenance.

Wear Points & Servicing Notes

Brake disc and pad wear

Single disc up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.

Suspension condition on used examples

Suspension duties are handled by WP XACT-USD, Ø 48 mm up front and WP XACT Monoshock with linkage at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.

Final drive maintenance

Chain final drive on the 250 SX-F means routine lubing and tension checks are part of ownership - skip them and sprocket wear accelerates noticeably.

Frame & chassis check

The Central double-cradle-type 25CrMo4 steel chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.

Low-speed handling

The 250 SX-F's 99 kg kerb weight makes low-speed control noticeably less effort than on a heavier machine.

250 SX-F - Buying & Maintenance Guide

What to check before buying

A pre-purchase check on the 2022 KTM 250 SX-F should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept 250 SX-F settles to a smooth idle within seconds.

Oil and filter changes

Oil changes are the cheapest insurance you can buy for a 250 SX-F's engine - keep to the manufacturer's interval rather than stretching it. Use the viscosity grade the manual specifies, not whatever's on sale.

2022 KTM 250 SX-F - Frequently Asked Questions

What engine does the 2022 KTM 250 SX-F have?

The 2022 KTM 250 SX-F uses a Single cylinder, four-stroke engine with 249.9 cc of displacement.

How much does the 2022 KTM 250 SX-F weigh?

The 2022 KTM 250 SX-F weighs 99 kg. This is the manufacturer's dry figure.

What is the fuel tank capacity of the 2022 KTM 250 SX-F?

The 2022 KTM 250 SX-F has a 7.50-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 125-150 km between stops.

Is the 2022 KTM 250 SX-F suitable for shorter riders?

The 2022 KTM 250 SX-F has a seat height of 950 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2022 KTM 250 SX-F have?

The 2022 KTM 250 SX-F uses Single disc at the front and Single disc at the rear.

What tyre sizes does the 2022 KTM 250 SX-F use?

The front tyre size on the 2022 KTM 250 SX-F is 80/100-21.

What suspension does the 2022 KTM 250 SX-F have?

The 2022 KTM 250 SX-F uses WP XACT-USD, Ø 48 mm up front and WP XACT Monoshock with linkage at the rear.

KTM 250 SX-F Spec Evolution

The KTM 250 SX-F was produced across 17 model years (2006-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017	2018	2019	2021	2022	2023
Wet Weight	-	-	-	-	-	104.0 kg / 229.3 lbs	292.1 kg / 643.9 lbs	-	112.0 kg / 246.9 lbs	-	-	-	-	-	-	-	-
Dry Weight	98.5 kg / 217.2 lbs	98.5 kg / 217.2 lbs	98 kg / 216.1 lbs	98 kg / 216.1 lbs	98 kg / 216.1 lbs	99.9 kg / 220.2 lbs	103.4 kg / 228.0 lbs	102.8 kg / 226.6 lbs	102.8 kg / 226.6 lbs	102.8 kg / 226.6 lbs	98.5 kg / 217.2 lbs	98.2 kg / 216.5 lbs	98.2 kg / 216.5 lbs	99 kg / 218.3 lbs	99 kg / 218.3 lbs	99 kg / 218.3 lbs	101 kg / 222.7 lbs
Engine Detail	-	-	-	-	-	-	-	-	-	-	-	-	Balancer shaft	Balancer shaft	Reed intake	-	-
Engine Type	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke
Seat Height	925 mm / 36.4 in.	925 mm / 36.4 in.	960 mm / 37.8 in.	985 mm / 38.8 in.	985 mm / 38.8 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	950 mm / 37.4 in.	950 mm / 37.4 in.	958 mm / 37.7 in.
Fuel Capacity	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.20 litres / 1.90 gallons	8.00 litres / 2.11 gallons	8.00 litres / 2.11 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 US gallons	7.00 litres / 1.85 US gallons	7.50 litres / 1.98 US gallons	7.20 litres / 1.90 US gallons
Displacement (cc)	249.50 cc	249.50 cc	248.60 cc	248.60 cc	248.60 cc	248.60 cc	248.60 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.9 cc	249.9 cc	249.9 cc	249.9 cc
Displacement (ci)	15.22 cubic inches	15.22 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches

Key Specifications

Engine

Single cylinder, four-stroke

Power

Not published by manufacturer

Torque

Not published by manufacturer

Top Speed

Not published by manufacturer

Weight

99 kg / 218.3 lbs

Fuel Capacity

7.50 litres / 1.98 US gallons

Full 2022 KTM 250 SX-F Specifications

Colours Orange/white/blue

Ground Clearance (in.) 14.6 inches

Ground Clearance (mm) 370 mm

Seat Height 950 mm / 37.4 in.

Wheelbase 1495 mm / 58.9 in.

Dry Weight 99 kg / 218.3 lbs

Fuel Capacity 7.50 litres / 1.98 US gallons

Bore x Stroke (in,) 3.1 x 2.1 inches

Bore x Stroke (mm) 78.0 x 52.3 mm

Displacement (cc) 249.9 cc

Displacement (ci) 15.25 cubic inches

Engine Type Single cylinder, four-stroke

Ignition Keihin EMS

Starter Electric

Clutch Wet multi-disc clutch, Brembo hydraulics

Final Drive Chain (final drive)

Gearbox 5-speed

Primary Drive 5/8 x 1/4´ chain.

Frame Type Central double-cradle-type 25CrMo4 steel

Suspension - Front WP XACT-USD, Ø 48 mm

Suspension - Rear WP XACT Monoshock with linkage

Rake 26.5°

Wheel Travel - Front 310 mm / 12.2 in.

Wheel Travel - Rear 300 mm / 11.8 in.

Brakes - Front Single disc

Brakes - Rear Single disc

Rims Wire spoked.

Tyres - Front 80/100-21

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
