2017 KTM 250 SX-F Specifications

Name: 2017 KTM 250 SX-F
Brand: KTM

Cross / motocross • Specs last verified 13 July 2026

No images available

Tap to enlarge

2017 KTM 250 SX-F Overview

The 2017 KTM 250 SX-F is a cross / motocross motorcycle built around 249.91 cc of displacement. Under the tank sits a Single cylinder, four-stroke engine running Double Overhead Cams/Twin Cam (DOHC) valve actuation. The bore and stroke measures 78 x 52.3 mm. From a practical standpoint, the 2017 250 SX-F tips the scales at 98.2 kg, carries a 7-litre fuel tank, offers a seat height of 960 mm and spans a 1,485 mm wheelbase. Scroll down for the complete 2017 KTM 250 SX-F spec sheet covering every technical detail from suspension travel to tyre sizes.

2017 250 SX-F - Pros & Cons

Strengths

Factory engineering: The 2017 KTM 250 SX-F represents KTM's engineering at the time, with a specification built around real-world usability.

Considerations

Tall seat height: The 960 mm seat height will challenge shorter riders - tiptoeing at low speeds is something to factor into your decision.
Modest fuel capacity: The 7-litre tank means more frequent fuel stops on longer rides, which is worth planning around on touring routes.
Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.

Wear Points & Servicing Notes

Valve clearance checks

Double Overhead Cams/Twin Cam (DOHC) valve actuation on the 250 SX-F means clearances should be checked at the manufacturer's specified interval - they can tighten as mileage accumulates, and a light top-end tick is usually the first sign.

Brake disc and pad wear

The Single disc. Brake calipers on floating bearings front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Suspension condition on used examples

Up front, the 250 SX-F runs WP-USD, AER 48, ? 48 mm and WP shock absorber with linkage at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.

Final drive maintenance

Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.

Frame & chassis check

The frame is 25CrMo4 steel central-tube frame - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.

Low-speed handling

At just 98.2 kg, the 250 SX-F is light enough to manhandle easily at a standstill - one of the practical advantages of its class.

250 SX-F - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2017 KTM 250 SX-F, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained 250 SX-F should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any 250 SX-F. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

Valve clearance service

Check that valve clearances have been adjusted at the correct intervals on any used 250 SX-F. A bike with clearances out of spec doesn't always feel obviously wrong - but tight clearances accelerate valve seat wear. Ask for service documentation proving it's been done.

2017 KTM 250 SX-F - Frequently Asked Questions

What engine does the 2017 KTM 250 SX-F have?

The 2017 KTM 250 SX-F uses a Single cylinder, four-stroke engine with 249.91 cc of displacement.

How much does the 2017 KTM 250 SX-F weigh?

The 2017 KTM 250 SX-F weighs 98.2 kg. This is the manufacturer's dry figure.

What is the fuel tank capacity of the 2017 KTM 250 SX-F?

The 2017 KTM 250 SX-F has a 7-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 116-140 km between stops.

Is the 2017 KTM 250 SX-F suitable for shorter riders?

The 2017 KTM 250 SX-F has a seat height of 960 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2017 KTM 250 SX-F have?

The 2017 KTM 250 SX-F uses Single disc. Brake calipers on floating bearings at the front and Single disc. Brake calipers on floating bearings at the rear.

What suspension does the 2017 KTM 250 SX-F have?

The 2017 KTM 250 SX-F uses WP-USD, AER 48, ? 48 mm up front and WP shock absorber with linkage at the rear.

What frame does the 2017 KTM 250 SX-F use?

The 2017 KTM 250 SX-F is built around a 25CrMo4 steel central-tube frame frame.

KTM 250 SX-F Spec Evolution

The KTM 250 SX-F was produced across 17 model years (2006-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016	2017	2018	2019	2021	2022	2023
Wet Weight	-	-	-	-	-	104.0 kg / 229.3 lbs	292.1 kg / 643.9 lbs	-	112.0 kg / 246.9 lbs	-	-	-	-	-	-	-	-
Dry Weight	98.5 kg / 217.2 lbs	98.5 kg / 217.2 lbs	98 kg / 216.1 lbs	98 kg / 216.1 lbs	98 kg / 216.1 lbs	99.9 kg / 220.2 lbs	103.4 kg / 228.0 lbs	102.8 kg / 226.6 lbs	102.8 kg / 226.6 lbs	102.8 kg / 226.6 lbs	98.5 kg / 217.2 lbs	98.2 kg / 216.5 lbs	98.2 kg / 216.5 lbs	99 kg / 218.3 lbs	99 kg / 218.3 lbs	99 kg / 218.3 lbs	101 kg / 222.7 lbs
Engine Detail	-	-	-	-	-	-	-	-	-	-	-	-	Balancer shaft	Balancer shaft	Reed intake	-	-
Engine Type	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke
Seat Height	925 mm / 36.4 in.	925 mm / 36.4 in.	960 mm / 37.8 in.	985 mm / 38.8 in.	985 mm / 38.8 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	992 mm / 39.1 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	960 mm / 37.8 in.	950 mm / 37.4 in.	950 mm / 37.4 in.	958 mm / 37.7 in.
Fuel Capacity	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.20 litres / 1.90 gallons	8.00 litres / 2.11 gallons	8.00 litres / 2.11 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.50 litres / 1.98 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 gallons	7.00 litres / 1.85 US gallons	7.00 litres / 1.85 US gallons	7.50 litres / 1.98 US gallons	7.20 litres / 1.90 US gallons
Displacement (cc)	249.50 cc	249.50 cc	248.60 cc	248.60 cc	248.60 cc	248.60 cc	248.60 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.91 cc	249.9 cc	249.9 cc	249.9 cc	249.9 cc
Displacement (ci)	15.22 cubic inches	15.22 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.17 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches	15.25 cubic inches

Key Specifications

Engine

Single cylinder, four-stroke

Power

Not published by manufacturer

Torque

Not published by manufacturer

Top Speed

Not published by manufacturer

Weight

98.2 kg / 216.5 lbs

Fuel Capacity

7.00 litres / 1.85 gallons

Full 2017 KTM 250 SX-F Specifications

Colours Orange/white/black

Ground Clearance (in.) 14.6 inches

Ground Clearance (mm) 370 mm

Seat Height 960 mm / 37.8 in.

Wheelbase 1,485 mm / 58.5 in.

Dry Weight 98.2 kg / 216.5 lbs

Fuel Capacity 7.00 litres / 1.85 gallons

Maximum RPM 14000

Bore x Stroke (in,) 3.1 x 2.1 inches

Bore x Stroke (mm) 78.0 x 52.3 mm

Displacement (cc) 249.91 cc

Displacement (ci) 15.25 cubic inches

Engine Type Single cylinder, four-stroke

Fuel Control Double Overhead Cams/Twin Cam (DOHC)

Ignition Keihin EMS

Starter Electric

Clutch Wet multi-disc clutch / hydraulically operated

Final Drive Chain

Gearbox 5-speed

Primary Drive 13:48. Primary drive: 22:68.

Frame Type 25CrMo4 steel central-tube frame

Suspension - Front WP-USD, AER 48, ? 48 mm

Suspension - Rear WP shock absorber with linkage

Rake 26.5°

Wheel Travel - Front 300 mm / 11.8 in.

Wheel Travel - Rear 300 mm / 11.8 in.

Brakes - Front Diameter (in.) 10.2 inches

Brakes - Front Diameter (mm) 260 mm

Brakes - Rear Diameter (in.) 8.7 inches

Brakes - Rear Diameter (mm) 220 mm

Brakes - Front Single disc. Brake calipers on floating bearings

Brakes - Rear Single disc. Brake calipers on floating bearings

Rims CNC machined hubs. Excel rims. Wire spoked.

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
