Key Specifications
Engine
Four stroke single cylinder, DOHC, 4 valves
Power
27 hp / 20.1 kW @ 8500rpm
Torque
26.6 Nm / 19.6 lb-ft @ 6500rpm
Fuel Capacity
7.8 Litres / 2 US gal
Advertisement
Full 2025 Honda CRF 300L Specifications
Year
2025
Make Model
Honda CRF 300L
Seat Height
880 mm / 34.6 in
Wheelbase
1455 mm / 57.2 in
Ground Clearance
285 mm / 11.2 in
Height
1200 mm / 47.2 in
Length
2230 mm / 87.7 in
Width
820 mm / 32.2 in
Fuel Capacity
7.8 Litres / 2 US gal
Wet Weight
142 kg / 313 lbs
Displacement
286 cc / 17.4 cu-in
Engine Detail
Four stroke single cylinder, DOHC, 4 valves
Bore x Stroke
76 x 63 mm
Compression Ratio
10.7:1
Cooling System
Liquid cooled
Emissions
EURO 5+
Fuel Induction
PGM-FI electronic fuel injection
Ignition
Full transistor digital
Lubrication
Wet sump
Starter
Electric
Clutch
Wet multiplate, assisted slipper clutch
Final Drive
#520 chain
Transmission / Drive
6 Speed
Frame Type
Steel semi-double cradle
Suspension - Front
43mm Telescopic USD forks
Suspension - Rear
Pro-Link single shock with spring
Rake
27.5°
Trail
109 mm / 4.3 in
Wheel Travel - Front
234 mm / 9.2 in
Wheel Travel - Rear
260 mm / 10.2 in
Brakes - Front
Single 256mm disc 2 piston caliper
Brakes - Rear
Single 220mm disc 1 piston caliper
ABS
2 channel ABS
Tyres - Front
80/100-21M/C 51P
Tyres - Rear
120/80-18M/C 62P
Wheels
Aluminium spoke
