Model ID: CRF300R | Model ID: CRF300L. | Model ID: CRF300L. | - |
|
Seat Height
|
880 mm / 34.6 in | 881 mm / 34.7 in. ↑ | 880 mm / 34.6 in ↓ | 880 mm / 34.6 in |
|
Engine Detail
|
Four stroke single cylinder, DOHC, 4 valves | 33mm intake valve, titanium; 26mm exhaust, titanium ↑ | Four stroke single cylinder, DOHC, 4 valves ↓ | Four stroke single cylinder, DOHC, 4 valves |
|
Wheelbase
|
1455 mm / 57.2 in | 1455 mm / 57.3 in. | 1455 mm / 57.2 in | 1455 mm / 57.2 in |
|
Brakes - Front
|
Single 256mm disc 2 piston caliper | Single disc. Two-piston calipers. ABS. | Single 256mm disc 2 piston caliper | Single 256mm disc 2 piston caliper |
|
Fuel Capacity
|
7.8 Litres / 2 US gal | 7.80 litres / 2.06 US gallons | 7.8 Litres / 2 US gal | 7.8 Litres / 2 US gal |
|
Brakes - Rear
|
Single 220mm disc 1 piston caliper | Single disc. ABS. | Single 220mm disc 1 piston caliper | Single 220mm disc 1 piston caliper |
|
Suspension - Front
|
43mm Telescopic USD forks | 43mm telescopic USD fork | 43mm Telescopic USD forks | 43mm Telescopic USD forks |
|
Suspension - Rear
|
Pro-Link single shock with spring | Pro-Link system | Pro-Link single shock with spring | Pro-Link single shock with spring |
|
Fuel System
|
Injection. Programmed Fuel-Injection system (PGM-FI); 44mm throttle bore | Injection. Programmed Fuel-Injection system (PGM-FI); 44mm throttle bore | Injection. Programmed Fuel-Injection system (PGM-FI); 38mm throttle bore ↓ | - |
|
Clutch
|
Wet multiplate, assist/slipper clutch | Wet multiplate, assist/slipper clutch | Wet multiplate, assist/slipper clutch | Wet multiplate, assisted slipper clutch |
|
Final Drive
|
#520 chain | Chain (final drive) | #520 chain | #520 chain |
|
Height
|
1200 mm / 47.2 in | 1200 mm / 47.2 in. | 1200 mm / 47.2 in | 1200 mm / 47.2 in |
|
Length
|
2230 mm / 87.7 in | 2230 mm / 87.8 in. | 2230 mm / 87.7 in | 2230 mm / 87.7 in |
|
Wet Weight
|
142 kg / 313 lbs | 142.0 kg / 313.1 lbs | 142 kg / 313 lbs | 142 kg / 313 lbs |
|
Emissions
|
EURO5 | Euro 5 | EURO5 | EURO 5+ |
|
Tyres - Front
|
80/100-21M/C 51P | 80/100-21 | 80/100-21M/C 51P | 80/100-21M/C 51P |
|
Width
|
820 mm / 32.2 in | 820 mm / 32.3 in. | 820 mm / 32.2 in | 820 mm / 32.2 in |
|
Rake
|
27.5° | 27.5° | 27.5° | 27.5° |
|
Trail
|
109 mm / 4.3 in | 109 mm / 4.3 in. | 109 mm / 4.3 in | 109 mm / 4.3 in |
|
Wheel Travel - Front
|
305 mm / 12.0 in. | 305 mm / 12.0 in. | 259 mm / 10.2 in. ↓ | 234 mm / 9.2 in ↓ |
|
Wheel Travel - Rear
|
315 mm / 12.4 in. | 315 mm / 12.4 in. | 259 mm / 10.2 in. ↓ | 260 mm / 10.2 in ↑ |
|
Ignition
|
Full transistor digital | Computer-controlled digital transistorized with electronic advance | Full transistor digital | Full transistor digital |
|
Max Torque
|
26.6 Nm / 19.6 lb-ft @ 6500rpm | 26.6 Nm (2.7 kgf-m or 19.6 ft.lbs) @ 6500 Revolutions | 26.6 Nm / 19.6 lb-ft @ 6500rpm | 26.6 Nm / 19.6 lb-ft @ 6500rpm |
