2015 Harley-Davidson V-Rod Muscle Specifications

Name: 2015 Harley-Davidson V-Rod Muscle
Brand: Harley-Davidson

Custom / cruiser • Specs last verified 13 July 2026

No images available

Tap to enlarge

2015 Harley-Davidson V-Rod Muscle Overview

The 2015 Harley-Davidson V-Rod Muscle is a custom / cruiser motorcycle. Under the tank sits a V2, four-stroke engine, a compression ratio of 11.5:1. The bore and stroke measures 105 x 72 mm. 2015 Harley-Davidson V-Rod Muscle delivers 116.62 Nm @ 6500 Revolutions of torque. From a practical standpoint, the 2015 V-Rod Muscle tips the scales at 307.1 kg, carries a 18.93-litre fuel tank, offers a seat height of 650 mm and spans a 1,702 mm wheelbase. That's roughly 6.5 kg heavier than the average custom / cruiser motorcycle in our database. Scroll down for the complete 2015 Harley-Davidson V-Rod Muscle spec sheet covering every technical detail from suspension travel to tyre sizes.

2015 V-Rod Muscle - Pros & Cons

Strengths

Fuel injection: The fuel injection system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
Accessible seat height: At 650 mm, the seat height is approachable for a wide range of rider heights and builds confidence in low-speed manoeuvring.
Large fuel range: The 18.93-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.
Low-maintenance final drive: Belt final drive means no chain to clean, lube or adjust - meaningfully less routine maintenance than a chain-driven equivalent.

Considerations

Age-related wear: As with any used V-Rod Muscle, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.

Wear Points & Servicing Notes

Fuelling & injector care

Fuelling comes from fuel injection. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.

Brake disc and pad wear

The Double disc. ABS. 4-piston front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Final drive maintenance

Final drive is by belt - lower maintenance than chain with no lubrication needed, but tension and tooth wear should still be checked at service intervals.

Handling the weight at a standstill

At 307.1 kg, the V-Rod Muscle is a substantial machine - low-speed manoeuvring in car parks takes more physical effort than on a lighter bike, though the weight disappears once rolling.

V-Rod Muscle - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2015 Harley-Davidson V-Rod Muscle, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained V-Rod Muscle should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any V-Rod Muscle. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. The sump holds 4.70 litres, so budget for that volume of quality motorcycle-specific engine oil. Always use the correct viscosity grade as specified in the owner's manual.

Fuel system care

The V-Rod Muscle's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.

2015 Harley-Davidson V-Rod Muscle - Frequently Asked Questions

What engine does the 2015 Harley-Davidson V-Rod Muscle have?

The 2015 Harley-Davidson V-Rod Muscle is powered by a V2, four-stroke engine.

How much does the 2015 Harley-Davidson V-Rod Muscle weigh?

The 2015 Harley-Davidson V-Rod Muscle weighs 307.1 kg. This is the manufacturer's wet figure.

How much power does the 2015 Harley-Davidson V-Rod Muscle make?

The 2015 Harley-Davidson V-Rod Muscle produces 116.62 Nm @ 6500 Revolutions of torque.

What is the fuel tank capacity of the 2015 Harley-Davidson V-Rod Muscle?

The 2015 Harley-Davidson V-Rod Muscle has a 18.93-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 315-378 km between stops.

Is the 2015 Harley-Davidson V-Rod Muscle suitable for shorter riders?

The 2015 Harley-Davidson V-Rod Muscle has a seat height of 650 mm. This is a comfortable, accessible height for most riders.

What brakes does the 2015 Harley-Davidson V-Rod Muscle have?

The 2015 Harley-Davidson V-Rod Muscle uses Double disc. ABS. 4-piston at the front and Single disc. 2-piston at the rear.

What tyre sizes does the 2015 Harley-Davidson V-Rod Muscle use?

The 2015 Harley-Davidson V-Rod Muscle runs 120/70-ZR19 front and 240/40-R18 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

How much oil does the 2015 Harley-Davidson V-Rod Muscle take?

The 2015 Harley-Davidson V-Rod Muscle takes 4.70 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.

Harley-Davidson V-Rod Muscle Spec Evolution

The Harley-Davidson V-Rod Muscle was produced across 5 model years (2013-2017). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2013	2014	2015	2016	2017
Engine Detail	Liquid-cooled, Revolution®, 60° V-Twin	Liquid-cooled, Revolution®, 60° V-Twin	Liquid-cooled, Revolution®, 60° V-Twin	Liquid-cooled, Revolution®, 60° V-Twin	Revolution®, 60° V-Twin
Seat Height	650 mm / 25.6 in.	650 mm / 25.6 in.	650 mm / 25.6 in.	705 mm / 27.8 in.	705 mm / 27.8 in.
Ground Clearance (mm)	122 mm	122 mm	122 mm	105 mm	105 mm
Ground Clearance (in.)	4.8 inches	4.8 inches	4.8 inches	4.1 inches	4.1 inches
CO2	147.6 CO	147.6 CO	146.2 CO2 g/km. (CO2 - Carbon dioxide emission)	146.2 CO2 g/km. (CO2 - Carbon dioxide emission)	146.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Comments	Amphibian.	Lithium Iron Phosphate 48V/20Ah battery, 16.8 kg. Range 60 km. Recharging time: 4 hours. Made in Taiwan.	-	-	-
Wheelbase	1,702 mm / 67.0 in.	1,702 mm / 67.0 in.	1,702 mm / 67.0 in.	1,700 mm / 66.9 in.	1,700 mm / 66.9 in.
Brakes - Front	Single disc. 4-piston	Single disc. 4-piston	Double disc. ABS. 4-piston	Double disc. ABS. 4-piston	Double disc. ABS. 4-piston

Key Specifications

Engine

V2, four-stroke

Power

Not published by manufacturer

Torque

116.62 Nm (11.9 kgf-m or 86.0 ft.lbs) @ 6500 Revolutions

Top Speed

Not published by manufacturer

Weight

307.1 kg / 677.0 lbs

Fuel Capacity

18.93 litres / 5.00 gallons

Full 2015 Harley-Davidson V-Rod Muscle Specifications

Colours Black Quartz, Mysterious Red Sunglo, Sand Cammo Denim, Vivid Black

Ground Clearance (in.) 4.8 inches

Ground Clearance (mm) 122 mm

Seat Height 650 mm / 25.6 in.

Wheelbase 1,702 mm / 67.0 in.

Length 2,357 mm / 92.8 in.

Oil Capacity (l) 4.70 litres

Oil Capacity (Quarts) 0.31 quarts

Dry Weight 292.1 kg / 644.0 lbs

Fuel Capacity 18.93 litres / 5.00 gallons

Wet Weight 307.1 kg / 677.0 lbs

Max Torque 116.62 Nm (11.9 kgf-m or 86.0 ft.lbs) @ 6500 Revolutions

Power-to-Weight Ratio 0.4086 HP/kg

Bore x Stroke (in,) 4.1 x 2.8 inches

Bore x Stroke (mm) 105.0 x 72.0 mm

CO2 146.2 CO2 g/km. (CO2 - Carbon dioxide emission)

Engine Type V2, four-stroke

Engine Detail Liquid-cooled, Revolution®, 60° V-Twin

Fuel System Injection. Electronic Sequential Port Fuel Injection

Compression Ratio 11.5:1

Engine Lubrication Dry sump

Exhaust Satin chrome, dual side exhaust system with turnouts

Fuel Consumption 6.30 litres/100 km (15.9 km/l or 37.34 mpg)

Starter Electric

Clutch Multi-plate with diaphragm spring in oil bath

Final Drive Belt

Gearbox 6-speed

Primary Drive Gear, 117/64 ratio primary drive

Rake 34.0°

Trail 142 mm / 5.6 in.

Instrumentation Electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, tachometer

Lighting system High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), coolant temperature, low fuel warnings

Brakes - Front Double disc. ABS. 4-piston

Brakes - Rear Single disc. 2-piston

Rims Black, 5-Spoke Cast Aluminum

Tyres - Front 120/70-ZR19

Tyres - Rear 240/40-R18

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
