Comments
|
Windscreen. | - | - | 3 Ride Modes (ECO, Rain and Road). Traction Control. | 3 Ride Modes (ECO, Rain and Road). Traction Control. Hill Start Control. USB charging. |
|
CO2
|
109.0 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Frame Type
|
Two-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine | Two-section frame, front- and bolted on rear frame, load-bearing engine | Two-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine | Two-section frame, front- and bolted on rear frame, load-bearing engine | Two-section frame, front- and bolted on rear frame, load-bearing engine |
|
Seat Height
|
850 mm to 870 mm / 33.5 in to 34.3 in 800 mm to 900 mm / 31.5 in to 35.4 in - Optional | 850 mm / 33.5 in. | 850 mm to 870 mm / 33.5 in to 34.3 in 800 mm to 820 mm / 31.5 in to 32.3 in - Optional | 850 mm / 33.5 in. | 850 mm / 33.5 in. |
|
Engine Detail
|
Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm | Balancer shaft | Four stroke, two cylinder horizontally opposed Boxer, with two overhead spur gear driven camshafts, a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, intake 40mm, outlet 34 mm | Balance shaft and variable engine timing system | Balance shaft and variable engine timing system |
|
Wheelbase
|
1525 mm / 60 in | 1525 mm / 60.0 in. | 1514 mm / 60 in ↓ | 1514 mm / 59.6 in. | 1514 mm / 59.6 in. |
|
Brakes - Front
|
2x 305mm floating discs, 4-piston radial brake calipers | Double disc. ABS. Floating discs. Four-piston calipers. | 2x 305mm floating discs, 4-piston radial brake calipers | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. ABS. Floating discs. Four-piston calipers. |
|
Brakes - Rear
|
Single 276mm disc, 2-piston floating caliper | Single disc. ABS. Floating disc. Two-piston calipers. | Single 276mm disc, 2-piston floating caliper | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. |
|
Fuel Capacity
|
20 Litres / 5.3 US gal | 20.00 litres / 5.28 US gallons | 20 Litres / 5.3 US gal | 19.68 litres / 5.20 US gallons ↓ | 19.68 litres / 5.20 US gallons |
|
Suspension - Front
|
BMW Motorrad 37mm Telelever, central spring strut | BMW Motorrad Telelever | BMW Motorrad 37mm Telelever, central spring strut | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut |
|
Top Speed
|
201.2 km/h / 125.0 mph | 200.0 km/h / 124.3 mph ↓ | 200.0 km/h / 124.3 mph | 193.1 km/h / 120.0 mph ↓ | 199.6 km/h / 124.0 mph ↑ |
|
Suspension - Rear
|
Cast aluminium single-sided swing arm with BMW Motorrad Paralever, WAD spring strut, continuously adjustable spring preload by means of hand wheel, rebound-stage damping adjustable by hand wheel (Option: Dynamic ESA) | Cast aluminium single-sided swing arm with BMW Motorrad Paralever | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel. | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel. |
|
Fuel System
|
Injection. Electronic intake pipe injection | Injection. Electronic intake pipe injection | Injection. Electronic intake manifold injection | Injection. Electronic intake pipe injection | Injection. Electronic intake pipe injection |
|
Colours
|
Black Storm Metallic, Cosmic Blue Metallic, Style HP, Style Exclusive | Black Storm Metallic, Cosmic Blue Metallic, Style HP, Style Exclusive | Black/Grey, Grey/White, White/Red/Blue, Black/Yellow | Black Storm Metallic/Black/Agate Gray, Ice Grey, Light White/Racing Blue Metallic/Racing Red, Black/Yellow | Black Storm Metallic/Black/Agate Gray, Gravity Blue Metallic, Light White/Racing Blue Metallic/Racing Red, Light White |
|
ABS
|
BMW Motorrad Integral ABS as standard (part integral), disengageable | - | BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized) | - | - |
|
Battery Capacity
|
V/Ah 12/11.8 12/16 | - | 12 V / 11.8 Ah, maintenance-free | - | - |
|
Clutch
|
Wet clutch with anti-hopping function, hydraulically activated | Oil lubricated clutch, hydraulically operated | Wet clutch with anti-hopping function, hydraulically activated | Wet clutch with an anti-hopping function, hydraulic activation | Wet clutch with an anti-hopping function, hydraulic activation |
|
Final Drive
|
Shaft | Shaft drive (cardan) (final drive) | Shaft | Shaft drive (cardan) (final drive) | Shaft drive (cardan) (final drive) |
|
Rims
|
Aluminium-Gussräder | Aluminium-Gussräder | Cast aluminium | Cast aluminium | Cast aluminium |
|
Height
|
1430 mm / 56.3 in. | 1430 mm / 56.3 in. | 1430 mm / 56.3 in | 1430 mm / 56.3 in. | 1430 mm / 56.3 in. |
|
Length
|
2207 mm / 86.9 in | 2207 mm / 86.9 in. | 2207 mm / 86.9 in | 2207 mm / 86.9 in. | 2207 mm / 86.9 in. |
|
Warranty
|
- | - | 3 years | Up to 3-years or 36,000 miles | Up to 3-years or 36,000 miles |
|
Wet Weight
|
249 kg / 549 lbs | 249.0 kg / 549.0 lbs | 249 kg / 549 lbs | 249.0 kg / 549.0 lbs | 249.0 kg / 549.0 lbs |
|
Emissions
|
Closed-loop three-way catalytic converter, exhaust standard , Euro 4 | EU-4 ↓ | Regulated three-way catalytic converter, compliant with EU5 emission standard ↑ | Regulated three-way catalytic converter, compliant with Euro 5 emission standard | Regulated three-way catalytic converter, compliant with Euro 5 emission standard |
|
Tyres - Front
|
120/70 R19 | 120/70-R19 | 120/70 R19 | 120/70-R19 | 120/70-R19 |
|
Width
|
952.5 mm / 37.5 in | 953 mm / 37.5 in. ↑ | 952.5 mm / 37.5 in ↓ | 953 mm / 37.5 in. ↑ | 953 mm / 37.5 in. |
|
Rake
|
25.5° | 25.5° | 25.5° | 25.7° ↑ | 25.7° |
|
Wheels
|
Die-cast aluminium wheels | - | Cast aluminium wheels | - | - |
|
Fuel Consumption
|
4.70 litres/100 km (21.3 km/l or 50.05 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) ↑ | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) |
|
Steering Angle
|
62.9° | - | 64.3° | - | - |
|
Trail
|
109 mm / 4.3 in | 100 mm / 3.9 in. ↓ | 100.6 mm / 4.0 in ↑ | 102 mm / 4.0 in. ↑ | 102 mm / 4.0 in. |
|
Wheel Travel - Front
|
190 mm / 7.4 in | 190 mm / 7.5 in. | 190 mm / 7.4 in | 190 mm / 7.5 in. | 190 mm / 7.5 in. |
|
Wheel Travel - Rear
|
200 mm / 7.8 in | 200 mm / 7.9 in. | 200 mm / 7.8 in | 200 mm / 7.9 in. | 200 mm / 7.9 in. |
|
Max Torque
|
143 Nm / 105.4 lb-ft @ 6250 rpm | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" |
