Key Specifications
Engine
Two cylinder boxer, four-stroke
Power
81 kW / 110 hp @ 7750 rpm
Torque
120 Nm / 12.2 kgf-m / 88 lb-ft @ 6000 rpm
Top Speed
220 km/h / 137 mph
Fuel Capacity
18.00 litres
Full 2011 BMW R 1200R Specifications
Comments
Power Steering
Year
2011
Year
2011
Colours
Blue, black, white, grey
Make Model
BMW R 1200R
Make Model
BMW R 1200R
Ground Clearance (in.)
50.3 inches
Ground Clearance (mm)
1,278 mm
Height (in.)
50.6 inches
Height (mm)
1,285 mm
Length (in.)
84.4 inches
Length (mm)
2,145 mm
Seat Height (in.)
31.5 inches
Seat Height (mm)
800 mm
Storage
Front Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg
Wheelbase (in.)
58.9 inches
Wheelbase (mm)
1,495 mm
Width (in.)
34.3 inches
Width (mm)
872 mm
Seat Height
800mm / 31.5 in (Standard, OE, OA, sport seat) 830mm / 32.7 in (OE, OA, comfort seat, high) / 760mm / 29.9 in (OE, OA, seat, low) / 750mm / 29.5 in (OE, low slung)
Seat Height
800mm / 31.5" (Standard, OE, OA, sport seat) 830mm / 32.7" (OE, OA, comfort seat, high) / 760mm / 29.9" (OE, OA, seat, low) / 750mm / 29.5" (OE, low slung)
Wheelbase
1495 mm / 59.1 in
Wheelbase
1495 mm / 59.1 in
Height
1273 mm / 50.1 in (excl. mirrors)
Height
1273 mm / 50.1 in (excl. mirrors)
Length
2145 mm / 84.4 in
Length
1273 mm / 50.1 in (excl. mirrors)
Width
906 mm / 35.6 in (incl. mirrors)
Width
906 mm / 35.6 in (incl. mirrors)
Wet Weight (lbs.)
491.6 pounds
Wet Weight (kg)
223.0 kg
Fuel Capacity (l)
18.00 litres
Dry Weight (kg)
198
Fuel Capacity (gal.)
4.76 gallons
Dry Weight (lbs.)
436.5 pounds
Dry Weight (kg)
198
Wet Weight (kg)
223
Dry Weight
198 kg / 436.5 lbs
Dry Weight
198 kg / 436.5 lbs
Fuel Capacity
18 Litres / 4.7 US gal
Fuel Capacity
18 Litres / 4.7 gal
Wet Weight
223 kg / 492 lbs
Wet Weight
223 kg / 492 lbs
Bore x Stroke (in,)
4.0 x 2.9 inches
Bore x Stroke (mm)
101.0 x 73.0 mm
CO2
95.1 CO
Displacement (cc)
1170.00 cc
Displacement (ci)
71.39 cubic inches
Engine Type
Two cylinder boxer, four-stroke
Fuel Control
SOHC
Fuel Reserve (gal.)
0.79 gallons
Fuel Reserve (l)
3.00 litres
Displacement
1170 cc / 71.4 cu in
Displacement
1170 cc / 71.4 cu in
Engine Detail
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder
Engine Detail
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder
Fuel System
Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin-spark ignition
Bore x Stroke
101 x 73 mm
Bore x Stroke
101 x 73 mm
Compression Ratio
11.0:1
Compression Ratio
12.0:1
Cooling System
Air/Oil-cooled
Cooling System
Air/Oil-cooled
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-3
Engine Lubrication
Dry sump
Exhaust
Closed-loop 3-way catalytic converter, emission standard EU-3
Fuel Consumption
5.2 L/100 km / 19.2 km/l / 45.2 US mpg
Fuel Consumption
5.2 L/100 km / 19.2 km/l / 45.2 mpg
Fuel Induction
Electronic intake manifold injection BMS-K
Fuel Induction
Electronic intake manifold injection BMS-K
Ignition
Digital engine management
Ignition
Digital engine management
Starter
Electric
Starter
Electric
Valve System
4
Battery Capacity
12 V / 14 Ah, maintenance-free
Battery Capacity
12 V / 14 Ah, maintenance-free
Clutch
Single disc dry clutch, hydraulically actuated
Clutch
Single disc dry clutch, hydraulically actuated
Final Drive
Shaft
Final Drive
Shaft
Gear Ratios
1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848
Gear Ratios
1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848
Gearbox
6-speed
Primary Drive
Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD + Diff Lock
Transmission / Drive
6 Speed
Transmission / Drive
6 Speed
Trail (in.)
4.7 inches
Trail (mm)
119 mm
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (in.)
10.0 inches
Wheel Travel - Front (mm)
254 mm
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Rear (in.)
10.0 inches
Wheel Travel - Rear (mm)
254 mm
Frame Type
Tubular steel spaceframe, load-bearing engine
Frame Type
Tubular steel spaceframe, load-bearing engine
Suspension - Front
BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut
Suspension - Front
BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut
Suspension - Rear
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Suspension - Rear
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Rake
27.1°
Seat
Removable Passenger Seat and Optional 3-in-1 Versatility
Steering Head Angle
62.9°
Steering Head Angle
62.9°
Trail
119.1 mm / 4.7 in
Trail
119.1 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
140 mm / 5.5 in
Wheel Travel - Rear
140 mm / 5.5 in
Alternator
Three-phase alternator 720 W
Alternator
Three-phase alternator 720 W
Brakes - Rear Diameter (mm)
265 mm
Brakes - Rear Diameter (in.)
10.4 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front
2 x 320mm Discs, ABS
Brakes - Front
2 x 320mm Discs, ABS
Brakes - Rear
Single 265mm disc, ABS
Brakes - Rear
Single 265mm disc, ABS
Rims
Cast aluminium
Rims - Front
3.50 x 17
Rims - Rear
5.50 x 17
Tyres - Front
120/70-ZR 17
Tyres - Front
120/70-ZR 17
Tyres - Rear
180/55-ZR 17
Tyres - Rear
180/55-ZR 17
Wheels
Cast aluminium wheels
Wheels
Cast aluminium wheels
Wheels - Front
3.50 x 17''
Wheels - Rear
5.50 x 17''
