Key Specifications
Engine
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Power
127 kW / 173 hp @ 9250 rpm
Torque
140 Nm / 14.3 kgf-m / 103 lb-ft @ 8250 rpm
Top Speed
276.6 km/h / 171.9 mph
Fuel Capacity
19 Litres / 5.0 US gal
Full 2009 BMW K 1300 S Specifications
Year
2009
Make Model
BMW K 1300 S
Seat Height
820 mm/ 32.3 in - low seat 790 mm / 31.1 in
Wheelbase
1585 mm / 62.4 in
Height
1221 mm / 48.0 in (excl. mirrors)
Length
2182 mm / 85.9 in
Width
905 mm / 35.6 in (incl. mirrors)
Wet Weight (kg)
254
Dry Weight (kg)
228
Dry Weight
228 kg / 503 lbs
Fuel Capacity
19 Litres / 5.0 US gal
Wet Weight
254 kg / 550 lbs
Displacement
1298 cc / 79.2 cu in.
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
80 x 64.3 mm / 3.15 x 2.53 in
Compression Ratio
13.0:1
Cooling System
Liquid cooled
Exhaust management
Fully controlled three-way catalyst
Fuel Consumption
5.7 Litres/100 km 17.5 km/l / 41.2 US mpg
Fuel Induction
Electronic fuel injection, Digital Motor Electronics with integrated knock control (BMS-K)
Ignition
Digital CDI
Lubrication
Dry sump
Starter
Electric
Battery Capacity
12V / 14AH, maintenance free
Clutch
Multiple-plate clutch in oil bath, hydraulically operated
Final Drive
Shaft
Gear Ratios
1st 2.398 / 2nd 1.871 / 3rd 1.525 / 4th 1.296 / 5th 1.143 / 6th 1.015:1
Transmission / Drive
6 Speed
Frame Type
Bridge frame, aluminium, load-bearing engine
Suspension - Front
BMW Motorrad Duolever, central spring strut, Paralever; central spring strut with lever system
Suspension - Rear
Cast aluminium single swing arm with BMW Motorrad, spring pre-tension with infinite hydraulic adjustment
Steering Head Angle
60.4º
Trail
104.4 mm / 4.1 in
Wheel Travel - Front
115 mm / 4.5 in
Wheel Travel - Rear
135 mm / 5.3 in
Alternator
Three-phase alternator, 580W
Brakes - Front
2x 320mm discs, 4 piston calipers
Brakes - Rear
Single 265mm disc, 2 piston caliper
Rims - Front
3.50 x 17
Rims - Rear
6.00 x 17
Tyres - Front
120/70 ZR17
Tyres - Rear
190/55 ZR17
Wheels
Cast aluminium
