Ride-By-Wire. Riding Modes Rain and Road. | - | 2 Riding modes, rain or road. | Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket. | Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket. | Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket. |
|
Frame Type
|
Steel bridge frame in monocoque design, load-bearing engine | Steel bridge frame in monocoque design, load-bearing engine | Steel bridge frame in monocoque design, load-bearing engine | Steel bridge frame in monocoque design, load-bearing engine | Tubular steel space frame, load bearing engine | Tubular steel space frame, load bearing engine |
|
Seat Height
|
770-830 mm / 30.3-32.7 in | 770-830 mm / 30.3-32.7 in | 770-830 mm / 30.3-32.7 in | 815 mm / 32 in - OE suspension lowering kit: 770 mm / 30.3 in - OE low seat: 790 mm / 31.1 in - OE comfort seat: 830 mm / 32.6 in ↑ | 815 mm / 32.1 in. | 815 mm / 32.1 in. |
|
Wheelbase
|
1559 mm / 61.4 in | 1559 mm / 61.4 in | 1559 mm / 61.4 in | 1559 mm / 61.4 in | 1559 mm / 61.4 in. | 1559 mm / 61.4 in. |
|
Brakes - Front
|
2 x 305mm discs, 2 piston calipers, ABS | 2 x 305mm discs, 2 piston calipers, ABS | 2 x 305mm discs, 2 piston calipers, ABS | 2 x 305mm discs, 2 piston floating calipers | Double disc. ABS. Floating discs. Two-piston calipers. | Double disc. ABS. Floating discs. Two-piston calipers. |
|
Fuel Capacity
|
15 Litres / 4.0 US gal | 15 Litres / 4.0 US gal | 15 Litres / 4.0 US gal | 15 Litres / 4.0 US gal | 15.00 litres / 3.96 US gallons | 15.00 litres / 3.96 US gallons |
|
Brakes - Rear
|
Single 265mm disc,1 piston caliper, ABS | Single 265mm disc,1 piston caliper, ABS | Single 265mm disc,1 piston caliper, ABS | Single 265mm disc,1 piston floating caliper | Single disc. ABS. Floating disc. Single-piston caliper. | Single disc. ABS. Floating disc. Single-piston caliper. |
|
Suspension - Front
|
41mm telescopic forks | 41mm telescopic forks | 41mm telescopic forks | 41mm telescopic forks | Telescopic fork, 41 mm | Telescopic fork, 41 mm |
|
Suspension - Rear
|
Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA) | Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA) | Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA) | Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable | Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable | Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable |
|
Fuel System
|
Injection. Electroinc intake pipe injection, digital engine management (BMS-K+) | Injection. Electroinc intake pipe injection, digital engine management (BMS-K+) | Injection. Electroinc intake pipe injection, digital engine management (BMS-K+) | Injection. Electronic fuel injection | Injection. Electronic fuel injection | Injection. Electronic fuel injection |
|
Colours
|
Light White, Austin Yellow Metallic, Stereo Metallic Matt | Austin Yellow Metallic, Light White, Style Exclusive | Austin Yellow Metallic, Light White, Stereo Metallic Matte | Black Storm Metallic/Yellow, Light White, San Marino Blue Metallic | Triple Black, Light White, San Marino Blue Metallic | Triple Black, Light White, Light White/Racing Blue Metallic/Racing Red |
|
Clutch
|
Multiplate wet clutch (anti-hopping), mechanically controlled | Multiplate wet clutch (anti-hopping), mechanically controlled | Multiplate wet clutch (anti-hopping), mechanically controlled | Multiplate wet clutch (anti-hopping), mechanically controlled | Multiple-disc clutch in oil bath, mechanically operated | Multiple-disc wet clutch (anti hopping), mechanically operated |
|
Final Drive
|
O-ring chain | O-ring chain | O-ring chain | Endless O-ring chain with shock damping in rear wheel hub | Chain (final drive) | Chain (final drive) |
|
Height
|
1,225 mm / 48.2 in. | 1225 mm / 48.2 in. ↑ | 1225 mm / 48.2 in. | 1225 mm / 48.2 in (ecxl. mirrors) | 1225 mm / 48.2 in. | 1225 mm / 48.2 in. |
|
Length
|
2255 mm / 88.8 in | 2255 mm / 88.8 in | 2255 mm / 88.8 in | 2255 mm / 88.8 in | 2255 mm / 88.8 in. | 2255 mm / 88.8 in. |
|
Wet Weight
|
224 kg / 494 lbs | 224 kg / 494 lbs | 224 kg / 494 lbs | 227 kg / 500 lbs ↑ | 224.0 kg / 493.8 lbs ↓ | 224.0 kg / 493.8 lbs |
|
Emissions
|
Closed-loop 3-way catalytic converter, emission standard EU-4 | Closed-loop 3-way catalytic converter, emission standard EU-4 | Closed-loop 3-way catalytic converter, emission standard EU-4 | Closed-loop 3-way catalytic converter, emission standard EU-5 | Closed-loop 3-way catalytic converter, emission standard EU-4 | Closed-loop 3-way catalytic converter, emission standard EU-4 |
|
Tyres - Front
|
110/80-19 | 110/80-19 | 110/80-19 | 110/80 R19 | 110/80-19 | 110/80-R19 |
|
Width
|
922 mm / 36.3 in (incl. mirrors) | 922 mm / 36.3 in (incl. mirrors) | 922 mm / 36.3 in (incl. mirrors) | 922 mm / 36.3 in (incl. mirrors) | 922 mm / 36.3 in. | 922 mm / 36.3 in. |
|
Tyres - Rear
|
150/70-17 | 150/70-17 | 150/70-17 | 150/70 R17 | - | - |
|
Rake
|
27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° |
|
Lighting system
|
LED headlamps | LED headlamps | LED headlamps | LED headlight | LED headlight | LED headlight |
|
Transmission / Drive
|
Constant-Mesh 6 speed | Constant-Mesh 6 speed | Constant-Mesh 6 speed | Constant-Mesh 6 speed gearbox integrated in crankcase | - | - |
|
Fuel Reserve
|
3.50 litres / 0.92 gallons | 3.50 litres / 0.92 US gallons | 3.50 litres / 0.92 US gallons | 3.50 litres / 0.92 US gallons | 3.50 litres / 0.92 US gallons | 3.50 litres / 0.92 US gallons |
|
Trail
|
105 mm / 4.1 in. | 105 mm / 4.1 in. | 105 mm / 4.1 in. | 104.5 mm / 4.1 in ↓ | 105 mm / 4.1 in. ↑ | 105 mm / 4.1 in. |
|
Wheel Travel - Front
|
151 mm / 5.1 in | 151 mm / 5.1 in | 151 mm / 5.1 in | 170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in ↑ | 170 mm / 6.7 in. | 170 mm / 6.7 in. |
|
Wheel Travel - Rear
|
177 mm / 7.0 in | 177 mm / 7.0 in | 177 mm / 7.0 in | 170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in ↓ | 170 mm / 6.7 in. | 170 mm / 6.7 in. |
|
Ignition
|
Knock control and oxygen sensors. | Knock control and oxygen sensors. | Knock control and oxygen sensors. | Knock control and oxygen sensors | - | - |
|
Max Torque
|
83 Nm / 61.2 lb-ft @ 6000rpm | 83 Nm / 61.2 lb-ft @ 6000rpm | 83 Nm / 61.2 lb-ft @ 6000rpm | 83 Nm / 61.2 lb-ft @ 6000rpm | 83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 6000 Revolutions" | 83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 6000 Revolutions" |
