BMW F 750GS Specs

2019 - 2023 • 5 variants

The BMW F 750GS is an enduro motorcycle produced from 2019 to 2023 across 5 variants. It is powered by a four stroke, parallel twin cylinder, dohc, 4 valves per cylinder displacing 853.0 cc. Peak power output is 77 hp. Peak torque is 83 Nm.

About the BMW F 750GS

Documented here are the full technical specifications for the BMW F 750GS, a Enduro / Off-Road motorcycle with a production run from 2018 to 2023. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

AdSense - 728Ã90

BMW F 750GS by Year

2023 BMW F 750GS View specs →

2022 BMW F 750GS View specs →

2021 BMW F 750GS View specs →

2020 BMW F 750GS View specs →

2019 BMW F 750GS View specs →

Spec Evolution

How key specs changed across production years.

Specification	2018	2019	2020	2021	2022	2023
Comments	Ride-By-Wire. Riding Modes Rain and Road.	-	2 Riding modes, rain or road.	Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket.	Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket.	Automatic Stability Control. 2 Riding modes, rain or road. 12 V power socket.
Frame Type	Steel bridge frame in monocoque design, load-bearing engine	Steel bridge frame in monocoque design, load-bearing engine	Steel bridge frame in monocoque design, load-bearing engine	Steel bridge frame in monocoque design, load-bearing engine	Tubular steel space frame, load bearing engine	Tubular steel space frame, load bearing engine
Seat Height	770-830 mm / 30.3-32.7 in	770-830 mm / 30.3-32.7 in	770-830 mm / 30.3-32.7 in	815 mm / 32 in - OE suspension lowering kit: 770 mm / 30.3 in - OE low seat: 790 mm / 31.1 in - OE comfort seat: 830 mm / 32.6 in ↑	815 mm / 32.1 in.	815 mm / 32.1 in.
Wheelbase	1559 mm / 61.4 in	1559 mm / 61.4 in	1559 mm / 61.4 in	1559 mm / 61.4 in	1559 mm / 61.4 in.	1559 mm / 61.4 in.
Brakes - Front	2 x 305mm discs, 2 piston calipers, ABS	2 x 305mm discs, 2 piston calipers, ABS	2 x 305mm discs, 2 piston calipers, ABS	2 x 305mm discs, 2 piston floating calipers	Double disc. ABS. Floating discs. Two-piston calipers.	Double disc. ABS. Floating discs. Two-piston calipers.
Fuel Capacity	15 Litres / 4.0 US gal	15 Litres / 4.0 US gal	15 Litres / 4.0 US gal	15 Litres / 4.0 US gal	15.00 litres / 3.96 US gallons	15.00 litres / 3.96 US gallons
Brakes - Rear	Single 265mm disc,1 piston caliper, ABS	Single 265mm disc,1 piston caliper, ABS	Single 265mm disc,1 piston caliper, ABS	Single 265mm disc,1 piston floating caliper	Single disc. ABS. Floating disc. Single-piston caliper.	Single disc. ABS. Floating disc. Single-piston caliper.
Suspension - Front	41mm telescopic forks	41mm telescopic forks	41mm telescopic forks	41mm telescopic forks	Telescopic fork, 41 mm	Telescopic fork, 41 mm
Suspension - Rear	Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA)	Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA)	Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA)	Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable	Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Fuel System	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)	Injection. Electronic fuel injection	Injection. Electronic fuel injection	Injection. Electronic fuel injection
Colours	Light White, Austin Yellow Metallic, Stereo Metallic Matt	Austin Yellow Metallic, Light White, Style Exclusive	Austin Yellow Metallic, Light White, Stereo Metallic Matte	Black Storm Metallic/Yellow, Light White, San Marino Blue Metallic	Triple Black, Light White, San Marino Blue Metallic	Triple Black, Light White, Light White/Racing Blue Metallic/Racing Red
Clutch	Multiplate wet clutch (anti-hopping), mechanically controlled	Multiplate wet clutch (anti-hopping), mechanically controlled	Multiplate wet clutch (anti-hopping), mechanically controlled	Multiplate wet clutch (anti-hopping), mechanically controlled	Multiple-disc clutch in oil bath, mechanically operated	Multiple-disc wet clutch (anti hopping), mechanically operated
Final Drive	O-ring chain	O-ring chain	O-ring chain	Endless O-ring chain with shock damping in rear wheel hub	Chain (final drive)	Chain (final drive)
Height	1,225 mm / 48.2 in.	1225 mm / 48.2 in. ↑	1225 mm / 48.2 in.	1225 mm / 48.2 in (ecxl. mirrors)	1225 mm / 48.2 in.	1225 mm / 48.2 in.
Length	2255 mm / 88.8 in	2255 mm / 88.8 in	2255 mm / 88.8 in	2255 mm / 88.8 in	2255 mm / 88.8 in.	2255 mm / 88.8 in.
Wet Weight	224 kg / 494 lbs	224 kg / 494 lbs	224 kg / 494 lbs	227 kg / 500 lbs ↑	224.0 kg / 493.8 lbs ↓	224.0 kg / 493.8 lbs
Emissions	Closed-loop 3-way catalytic converter, emission standard EU-4	Closed-loop 3-way catalytic converter, emission standard EU-4	Closed-loop 3-way catalytic converter, emission standard EU-4	Closed-loop 3-way catalytic converter, emission standard EU-5	Closed-loop 3-way catalytic converter, emission standard EU-4	Closed-loop 3-way catalytic converter, emission standard EU-4
Tyres - Front	110/80-19	110/80-19	110/80-19	110/80 R19	110/80-19	110/80-R19
Width	922 mm / 36.3 in (incl. mirrors)	922 mm / 36.3 in (incl. mirrors)	922 mm / 36.3 in (incl. mirrors)	922 mm / 36.3 in (incl. mirrors)	922 mm / 36.3 in.	922 mm / 36.3 in.
Tyres - Rear	150/70-17	150/70-17	150/70-17	150/70 R17	-	-
Rake	27.0°	27.0°	27.0°	27.0°	27.0°	27.0°
Lighting system	LED headlamps	LED headlamps	LED headlamps	LED headlight	LED headlight	LED headlight
Transmission / Drive	Constant-Mesh 6 speed	Constant-Mesh 6 speed	Constant-Mesh 6 speed	Constant-Mesh 6 speed gearbox integrated in crankcase	-	-
Fuel Reserve	3.50 litres / 0.92 gallons	3.50 litres / 0.92 US gallons	3.50 litres / 0.92 US gallons	3.50 litres / 0.92 US gallons	3.50 litres / 0.92 US gallons	3.50 litres / 0.92 US gallons
Trail	105 mm / 4.1 in.	105 mm / 4.1 in.	105 mm / 4.1 in.	104.5 mm / 4.1 in ↓	105 mm / 4.1 in. ↑	105 mm / 4.1 in.
Wheel Travel - Front	151 mm / 5.1 in	151 mm / 5.1 in	151 mm / 5.1 in	170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in ↑	170 mm / 6.7 in.	170 mm / 6.7 in.
Wheel Travel - Rear	177 mm / 7.0 in	177 mm / 7.0 in	177 mm / 7.0 in	170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in ↓	170 mm / 6.7 in.	170 mm / 6.7 in.
Ignition	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors.	Knock control and oxygen sensors	-	-
Max Torque	83 Nm / 61.2 lb-ft @ 6000rpm	83 Nm / 61.2 lb-ft @ 6000rpm	83 Nm / 61.2 lb-ft @ 6000rpm	83 Nm / 61.2 lb-ft @ 6000rpm	83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 6000 Revolutions"	83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 6000 Revolutions"
