Key Specifications
Engine
In-line four, four-stroke
Torque
29.5 Nm (3.0 kgf-m or 21.8 ft.lbs) @ 9000 Revolutions"
Weight
169.0 kg / 372.6 lbs
Fuel Capacity
14.00 litres / 3.70 US gallons
Advertisement
Full 2023 Yamaha R3 Specifications
Comments
Balanced 50/50 weight distribution.
Colours
Icon Blue, Yamaha Black
Ground Clearance (mm)
160 mm
Ground Clearance (in.)
6.3 inches
Seat Height
780 mm / 30.7 in.
Wheelbase
1380 mm / 54.3 in.
Height
1140 mm / 44.9 in.
Length
2090 mm / 82.3 in.
Width
730 mm / 28.7 in.
Oil Capacity (Quarts)
2.64 US quarts
Oil Capacity (l)
2.50 litres
Fuel Capacity
14.00 litres / 3.70 US gallons
Wet Weight
169.0 kg / 372.6 lbs
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
Displacement (ci)
19.59 cubic inches
Displacement (cc)
321.0 cc
CO2
95.1 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
68.0 x 44.1 mm
Bore x Stroke (in,)
2.7 x 1.7 inches
Fuel System
Injection
Compression Ratio
11.2:1
Emissions
Euro 5
Engine Lubrication
Wet sump
Fuel Consumption
4.10 litres/100 km (24.4 km/l or 57.37 mpg)
Ignition
TCI
Starter
Electric
Valve System
2
Clutch
Wet multi-plate
Final Drive
Chain (final drive)
Gearbox
6-speed
Primary Drive
Constant mesh
Frame Type
Diamond
Suspension - Front
37mm KYB inverted front forks
Suspension - Rear
Swingarm
Rake
25.0°
Trail
95 mm / 3.7 in.
Wheel Travel - Front
130 mm / 5.1 in.
Wheel Travel - Rear
125 mm / 4.9 in.
Instrumentation
Digital multi-function instruments
Lighting system
Dual LED headlight
Brakes - Front
Single disc. Hydraulic. ABS.
Brakes - Rear
Single disc. Hydraulic. ABS.
Tyres - Front
110/70-R17
