Key Specifications
Power
88.8 hp / 66.2 kW @ 7400 rpm
Torque
110.0 Nm (11.2 kgf-m or 81.1 ft.lbs) @ 3950 Revolutions"
Weight
207 kg / 456.4 lbs
Fuel Capacity
16.00 litres
Advertisement
Full 2020 Triumph Scrambler 1200 XE Specifications
Year
2019 - 20
Colours
Cobalt Blue/Jet Black, Fusion White/Brooklands Green
Colours
Cobalt Blue/Jet Black
Make Model
Triumph Scrambler 1200 XE
Warranty
24 months unlimited milage
Warranty
24 months unlimited milage
Width (mm)
905 mm
Width (in.)
35.6 inches
Wheelbase (mm)
1570 mm
Wheelbase (in.)
61.8 inches
Seat Height (mm)
870 mm
Seat Height (in.)
34.3 inches
Height (mm)
1205 mm
Height (in.)
47.4 inches
Wheelbase (mm)
1530 mm
Wheelbase (in.)
60.2 inches
Seat Height (mm)
840 mm
Seat Height (in.)
33.1 inches
Height (mm)
1200 mm
Height (in.)
47.2 inches
Seat Height
870 mm / 34.3 in
Wheelbase
1570 mm / 61.8 in
Height
1250 mm / 49.2 in without mirrors
Length
1250 mm / 49.2 in without mirrors
Width
905 mm / 35.6 in with handlebars
Oil Capacity (Quarts)
4.76 US quarts
Oil Capacity (l)
4.50 litres
Fuel Capacity (l)
16.00 litres
Fuel Capacity (gal.)
4.23 US gallons
Dry Weight (lbs.)
456.4 pounds
Dry Weight (kg)
207
Oil Capacity (Quarts)
4.76 US quarts
Oil Capacity (l)
4.50 litres
Fuel Capacity (l)
16.00 litres
Fuel Capacity (gal.)
4.23 US gallons
Dry Weight (kg)
205
Dry Weight (lbs.)
452.0 pounds
Dry Weight
207 kg / 456.4 lbs
Fuel Capacity
15.8 Litres / 4.2 US gal / 3.7 Imp gal
Fuel Control
Single Overhead Cams (SOHC)
Engine Type
Twin, four-stroke
Displacement (ci)
73.22 cubic inches
Displacement (cc)
1200.0 cc
CO2
113.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
97.6 x 80.0 mm
Bore x Stroke (in,)
3.8 x 3.1 inches
Fuel Control
Single Overhead Cams (SOHC)
Engine Type
Twin, four-stroke
Displacement (ci)
73.22 cubic inches
Displacement (cc)
1200.0 cc
CO2
118.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
97.6 x 80.0 mm
Bore x Stroke (in,)
3.8 x 3.1 inches
Displacement
1200 cc / 73.2 cu-in
Engine Detail
Four stroke, 270° crank angle parallel twin, SOHC
Fuel System
Injection. Multipoint sequential electronic fuel injection with SAI
Fuel System
Injection. Multipoint sequential electronic fuel injection with SAI
Bore x Stroke
97.6 x 80.0 mm
Compression Ratio
11.0:1
Compression Ratio
11.1:1
Cooling System
Liquid cooled
Emissions
Euro 4
Exhaust
Brushed 2 into 2 exhaust system with brushed high level silencers
Exhaust
High level stainless steel headers with twin chromed silencers
Fuel Consumption
5.11 litres/100 km (19.6 km/l or 46.03 mpg)
Fuel Consumption
4.90 litres/100 km (20.4 km/l or 48.00 mpg)
Fuel Induction
Multipoint sequential electronic fuel injection
Ignition
Digital-inductive type via engine management system
Ignition
Digital - inductive type
Lubrication
Wet sump
Starter
Electric
Starter
Electric
Clutch
Wet, multi-plate
Clutch
Wet. multi-plate
Final Drive
X ring chain
Final Drive
Chain (final drive)
Gearbox
5-speed
Gearbox
5-speed
Primary Drive
X ring chain
Primary Drive
X ring chain
Transmission / Drive
6 Speed
Wheel Travel - Rear (mm)
200 mm
Wheel Travel - Rear (in.)
7.9 inches
Wheel Travel - Front (mm)
200 mm
Wheel Travel - Front (in.)
7.9 inches
Trail (mm)
121 mm
Trail (in.)
5.1 inches
Trail (mm)
129 mm
Wheel Travel - Front (in.)
7.9 inches
Wheel Travel - Front (mm)
200 mm
Wheel Travel - Rear (in.)
7.9 inches
Wheel Travel - Rear (mm)
200 mm
Trail (in.)
4.8 inches
Frame Type
Tubular steel cradle
Frame Type
Tubular steel with aluminum cradles, Twin-sided, aluminum, 579 mm / 22.8 in long swingarm
Suspension - Front
Showa 47mm fully adjustable upside down forksl
Suspension - Front
Showa 47mm fully adjustable USD forks
Suspension - Rear
Fully adjustable Ohlins twin shocks with piggy back reservoir
Suspension - Rear
Öhlins fully adjustable piggy-back RSUs with twin springs
Rake
26.9°
Rake
26.9°
Trail
129.5 mm / 5.1 in
Wheel Travel - Front
250 mm / 9.8 in
Wheel Travel - Rear
250 mm / 9.8 in
Instrumentation
Analogue speedometer with odometer and trip information
Instrumentation
Analogue speedometer with odometer and trip information
Brakes - Front
Double disc. Brembo 2-piston floating caliper
Brakes - Front
2x 320mm discs, Brembo M50 monoblock calipers, radial master cylinder, Switchable cornering ABS
Brakes - Rear
Single disc. Brembo 2-piston floating caliper ABS
Brakes - Rear
Single 255mm disc, Brembo 2-piston floating caliper, Switchable ABS
Rims
Spoked wheels
Rims
Spoked wheels
Tyres - Front
90/90-21
Tyres - Front
90/90-21
Tyres - Rear
150/70 R17
Wheels - Front
36-spoke 21 x 2.15 in, aluminum rims
Wheels - Rear
32-spoke 17 x 4.25 in, aluminum rims
