Key Specifications
Engine
In-line four, four-stroke
Power
150 hp / 111.8 kW @ 10000 rpm
Torque
108 Nm / 79.6 lb-ft @ 9500 rpm
Weight
207 kg / 456.4 lbs - ABS 209 kg / 460.8 lbs
Fuel Capacity
17.00 litres / 4.49 gallons
Advertisement
Full 2018 Suzuki GSX-S 1000 Specifications
Comments
Traction Control System.
Comments
Traction Control System.
Year
2017 - 18
Colours
Glass Sparkle Black/Candy Daring Red
Colours
Glass Sparkle Black/Candy Daring Red
Make Model
Suzuki GSX-S 1000
Warranty
12 month unlimited mileage limited warranty.
Warranty
12 month unlimited mileage limited warranty.
Ground Clearance (mm)
140 mm
Ground Clearance (in.)
5.5 inches
Ground Clearance (mm)
140 mm
Ground Clearance (in.)
5.5 inches
Seat Height
810 mm / 31.9 in.
Seat Height
810 mm / 31.9 in
Wheelbase
1,460 mm / 57.5 in.
Wheelbase
1460 mm / 57.5 in
Ground Clearance
140 mm / 5.5 in.
Height
1180 mm / 46.5 in
Length
2,115 mm / 83.3 in.
Length
2115 mm / 83. 2 in
Width
795 mm / 31.3 in.
Width
795 mm / 31.2 in
Dry Weight
207 kg / 456.4 lbs
Dry Weight
207 kg / 456.4 lbs
Fuel Capacity
17.00 litres / 4.49 gallons
Fuel Capacity
17 Litres / 4.4 US gal / 3.7 Imp gal
Wet Weight
207 kg / 456.4 lbs - ABS 209 kg / 460.8 lbs
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
Bore x Stroke (mm)
74.5 x 57.3 mm
Bore x Stroke (in,)
2.9 x 2.3 inches
Engine Type
In-line four, four-stroke
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Displacement
998.6 cc / 60.9 cub. in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Fuel System
Injection
Fuel System
Injection
Bore x Stroke
73.4 x 59.0 mm
Compression Ratio
12.2:1
Compression Ratio
12.2:1
Cooling System
Liquid cooled
Engine Lubrication
Wet sump
Engine Lubrication
Wet sump
Exhaust
4-2-1 exhaust system
Exhaust
4-2-1 exhaust system
Fuel Induction
Fuel Injection
Ignition
Electronic ignition (transistorised)
Ignition
Electronic ignition (Transistorized)
Lubrication
Wet sump
Starter
Electric
Starter
Electric
Valve System
4
Valve System
4
Clutch
Wet, multi-plate type , Rack and pinion clutch
Clutch
Wet, multi-plate type
Final Drive
Chain, DID50VAZ, 114 links
Final Drive
Chain
Final Drive Ratio
2.588 ( 44/17)
Gearbox
6-speed
Gearbox
6-speed
Primary Drive Ratios
1.553 (73/47)
Transmission / Drive
6 Speed, constant mesh
Frame Type
Aluminum
Frame Type
Aluminium, twin spar
Suspension - Front
Inverted telescopic, coil spring, oil damped
Suspension - Front
Inverted telescopic, coil spring, oil damped
Suspension - Rear
Link type, single shock, coil spring, oil damped
Suspension - Rear
Link type, coil spring, oil damped
Rake
25.0°
Rake
25.0°
Trail
100 mm / 3.9 in.
Trail
100 mm / 3.9 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
130 mm / 5.1 in
Brakes - Front Diameter (mm)
310 mm
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front Diameter (mm)
310 mm
Brakes - Front
Double disc. Brembo 4-piston
Brakes - Front
2 x 310mm Brembo discs, 4 piston Brembo calipers / ABS
Brakes - Rear
Single disc
Brakes - Rear
Single 220 mm disc / ABS
Rims
Black 6-spoke lightweight cast aluminum
Rims
Black 6-spoke lightweight cast aluminum
Tyres - Front
120/70-ZR17
Tyres - Front
120/70ZR17M/C (58W) tubeless
Tyres - Rear
190/50-ZR17
Tyres - Rear
190/50ZR17M/C (73W) tubeless
