2014 Suzuki GSX 1300R Hayabusa Specifications

Name: 2014 Suzuki GSX 1300R Hayabusa
Brand: Suzuki

Sport touring • Specs last verified 13 July 2026

No images available

Tap to enlarge

2014 Suzuki GSX 1300R Hayabusa Overview

Suzuki GSX 1300R Hayabusa is a sport touring motorcycle, displacing 1340 cc. Power comes from a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder engine, a compression ratio of 12.5:1. On the performance side, it delivers 146 kW @ 9800 rpm of peak power and 154 Nm @ 7200 rpm of torque. Top speed is factory-quoted at 296.9 km/h. On the road, the 2014 GSX 1300R Hayabusa tips the scales at 266 kg, carries a 21-litre fuel tank, offers a seat height of 805 mm and spans a 1480 mm wheelbase. That's roughly 18.1 kg heavier than the average sport touring motorcycle in our database. The full 2014 Suzuki GSX 1300R Hayabusa spec sheet below covers every technical detail, from suspension travel to tyre sizes.

2014 GSX 1300R Hayabusa - Pros & Cons

Strengths

Strong power output: With 146 kW @ 9800 rpm and 154 Nm @ 7200 rpm of torque on tap, the GSX 1300R Hayabusa is no slouch for its class.
Fuel injection: Fuel injection means consistent cold starts and clean throttle response without the fussiness of a carbureted setup.
Large fuel range: A 21-litre tank means fewer stops on longer rides - a genuine plus for touring or a lengthy daily commute.

Considerations

Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.

Wear Points & Servicing Notes

Cooling system servicing

GSX 1300R Hayabusa's Liquid cooled setup is low-maintenance provided the coolant interval is kept - old, acidic coolant is the main cause of long-term corrosion in the water passages.

Fuelling & injector care

The Suzuki Fuel Injection fuel injection on the GSX 1300R Hayabusa needs little beyond good fuel and periodic use of an injector-cleaner additive - no jetting or float-bowl maintenance to worry about.

Brake disc and pad wear

Braking up front comes from 2 x 310 mm Discs, 4 piston calipers - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.

Suspension condition on used examples

The GSX 1300R Hayabusa's suspension runs Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable at the front. The rear uses Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable. Fork-seal condition and rear linkage play are the two things worth checking before buying used.

Final drive maintenance

The GSX 1300R Hayabusa uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.

Frame & chassis check

Built around a Design (Material): Twin-spar (aluminum alloy), the GSX 1300R Hayabusa's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.

Handling the weight at a standstill

266 kg puts the GSX 1300R Hayabusa toward the heavier end of its class. It's most noticeable at walking pace; once underway the mass settles into the handling rather than fighting it.

GSX 1300R Hayabusa - Buying & Maintenance Guide

What to check before buying

Before handing over money for a used 2014 Suzuki GSX 1300R Hayabusa, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy GSX 1300R Hayabusa should catch quickly and settle into a smooth idle.

Oil and filter changes

Nothing protects a GSX 1300R Hayabusa's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). Match the viscosity grade to what the owner's manual specifies, not what's cheapest.

Fuel system care

Fuel injection on the GSX 1300R Hayabusa needs little attention beyond decent fuel and an occasional system-cleaner additive. Anything left standing for three months or more should have its fuel drained and replaced before it varnishes the injectors.

2014 Suzuki GSX 1300R Hayabusa - Frequently Asked Questions

What engine does the 2014 Suzuki GSX 1300R Hayabusa have?

The 2014 Suzuki GSX 1300R Hayabusa uses a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder engine with 1340 cc of displacement. It is liquid cooled.

What is the top speed of the 2014 Suzuki GSX 1300R Hayabusa?

The 2014 Suzuki GSX 1300R Hayabusa has a factory-quoted top speed of 296.9 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.

How much does the 2014 Suzuki GSX 1300R Hayabusa weigh?

The 2014 Suzuki GSX 1300R Hayabusa weighs 266 kg. This is the manufacturer's wet figure.

How much power does the 2014 Suzuki GSX 1300R Hayabusa make?

The 2014 Suzuki GSX 1300R Hayabusa produces 146 kW @ 9800 rpm of power and 154 Nm @ 7200 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2014 Suzuki GSX 1300R Hayabusa?

The 2014 Suzuki GSX 1300R Hayabusa has a 21-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 350-420 km between stops.

Is the 2014 Suzuki GSX 1300R Hayabusa suitable for shorter riders?

The 2014 Suzuki GSX 1300R Hayabusa has a seat height of 805 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2014 Suzuki GSX 1300R Hayabusa have?

The 2014 Suzuki GSX 1300R Hayabusa uses 2 x 310 mm Discs, 4 piston calipers at the front and Single 260 mm disc, 1 piston caliper at the rear.

What tyre sizes does the 2014 Suzuki GSX 1300R Hayabusa use?

The 2014 Suzuki GSX 1300R Hayabusa runs 120/70 ZR17 front and 190/50 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2014 Suzuki GSX 1300R Hayabusa have?

The 2014 Suzuki GSX 1300R Hayabusa is fitted with a 6 Speed transmission.

Suzuki GSX 1300R Hayabusa Spec Evolution

The Suzuki GSX 1300R Hayabusa was produced across 24 model years (1999-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	1999	2000	2001	2002	2003	2004	2005	2006	2007	2008	2009	2010	2011	2013	2014	2015	2016	2017	2018	2019	2020	2021	2022	2023
Max Power	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	127.6 kW / 175 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	146 kW / 195.7 hp @ 9800 rpm	187.7hp / 140kW @ 9700rpm	187.7hp / 140kW @ 9700rpm	187.7hp / 140kW @ 9700rpm
Wet Weight	248.0 kg / 546.7 lbs	-	249 kg / 549 lbs	249 kg / 549 lbs	249 kg / 549 lbs	249 kg / 549 lbs	249 kg / 549 lbs	249 kg / 549 lbs	249 kg / 549 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	266 kg / 586 lbs	264kg / 582 lbs	264kg / 582 lbs	264kg / 582 lbs
Dry Weight	217 kg / 480 lbs	217 kg / 480 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	221.5 kg / 488.3 lbs	220 kg / 485 lbs	220 kg / 485.0 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs
Engine Type	In-line four	-	In-line four	In-line four	In-line four	In-line four	In-line four	-	-	In-line four	Single cylinder	-	-	-	-	-	-	-	-	-	-	-	-	-
Top Speed	306 km/h / 190.1 mph	299.3 km/h / 186 mph	300.0 km/h / 186.4 mph	-	-	-	-	-	-	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	296.9 km/h / 184.49 mph	-	-	-
Seat Height	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	805 mm / 31.7 in	800 mm / 31.5 in	800 mm / 31.5 in	800 mm / 31.5 in
Fuel Capacity	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	21 Litres / 5.5 US gal / 4.6 Imp gal	20 Litres / 5.3 US gal	20 Litres / 5.3 US gal	20 Litres / 5.3 US gal
Frame Type	Twin-spar (Aluminum Alloy)	Twin-spar (Aluminum Alloy)	Twin-spar steel	Twin-spar steel	Twin-spar steel	Twin-spar steel	Twin-spar steel	Twin-spar steel	Twin-spar steel	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Design (Material): Twin-spar (aluminum alloy)	Twin-spar aluminium frame and swingarm	Twin-spar aluminium frame and swingarm	Twin-spar aluminium frame and swingarm

Key Specifications

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder

Power

146 kW / 195.7 hp @ 9800 rpm

Torque

154 Nm / 15.81 kg-m / 113.6 lb-ft @ 7200 rpm

Top Speed

296.9 km/h / 184.49 mph

Weight

266 kg / 586 lbs

Fuel Capacity

21 Litres / 5.5 US gal / 4.6 Imp gal

Full 2014 Suzuki GSX 1300R Hayabusa Specifications

Year 2014

Make Model Suzuki GSX 1300R Hayabusa

Seat Height 805 mm / 31.7 in

Wheelbase 1480 mm / 58.3in

Ground Clearance 120 mm / 4.7 in

Height 1165 mm / 45.9 in

Length 2190 mm / 86.2 in

Width 735 mm / 28.9 in

Dry Weight 220 kg / 485 lbs

Fuel Capacity 21 Litres / 5.5 US gal / 4.6 Imp gal

Wet Weight 266 kg / 586 lbs

Top Speed 296.9 km/h / 184.49 mph

Acceleration (100-140 km/h) 3.2 sec

Acceleration (140-180 km/h) 3.4 sec

Acceleration (60-140 km/h) 3.9 sec

Max Power 146 kW / 195.7 hp @ 9800 rpm

Max Torque 154 Nm / 15.81 kg-m / 113.6 lb-ft @ 7200 rpm

Standing Start 0-100 km 3.0 sec

Standing Start 0-140 km 4.4 sec

Standing Start 0-200 km 7.3 sec

Standing Start ¼ Mile 10.2 sec

Displacement 1340 cc / 81.8 cu-in

Engine Detail Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder

Bore x Stroke 81 x 65 mm

Compression Ratio 12.5:1

Cooling System Liquid cooled

Fuel Consumption 6.1 L/100 km / 16.3 km/l / 38.3 US mpg / 46.0 Imp mpg

Fuel Induction Suzuki Fuel Injection fuel injection

Ignition Electronic

Lubrication Wet sump

Starter Electric

Clutch Clutch Type: Wet multi-plate, manual Clutch Actuation System: Hydraulic Clutch Spring Type: Coil Number of Clutch Springs: 6 Number of Clutch Plates: 10 Drive; 9 Driven

Final Drive Chain

Final Drive Ratio 2.388 (43/18)

Gear Ratios 1st 1.596 / 2nd 2.615 / 3rd 1.937 / 4th 1.526 / 5th 1.136 / 5th 1.136

Primary Drive Ratios 1.596 (83/52)

Transmission / Drive 6 Speed

Frame Type Design (Material): Twin-spar (aluminum alloy)

Suspension - Front Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.

Suspension - Rear Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.

Rake 24.2°

Trail 98 mm / 3.8 in

Brakes - Front 2 x 310 mm Discs, 4 piston calipers

Brakes - Rear Single 260 mm disc, 1 piston caliper

Tyres - Front 120/70 ZR17

Tyres - Rear 190/50 ZR17

Wheels - Front 17 M/C x MT3.50, cast aluminum alloy

Wheels - Rear 17 M/C x MT6.00, cast aluminum alloy

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
