Suzuki DL 1050 V-Strom Specs
2020 - 2023
• 2 variants
Suzuki has built the DL 1050 V-Strom, an enduro motorcycle, across 2 variants since 2020, most recently updated for 2023. Under the tank sits a four stroke, 90° V-twin, DOHC, 4 valves per cylinder. It makes 107.4 hp at peak. Torque tops out at 100 Nm.
About the Suzuki DL 1050 V-Strom
Documented here are the full technical specifications for the Suzuki DL 1050 V-Strom, a Enduro / Off-Road motorcycle with a production run from 2020 to 2023. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.
Suzuki DL 1050 V-Strom by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2020
|
2023
|
|
Seat Height
|
855 mm / 33.7 in | 855mm / 33.7 in |
|
Wheelbase
|
1554 mm / 61.2 in | 1555 mm / 61.2 in ↑ |
|
Engine Detail
|
Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder | Four stroke, 90° V-twin, DOHC, 4 valves per cylinder |
|
Ground Clearance
|
165 mm / 6.5 in | 165mm / 6.5 in |
|
Fuel Capacity
|
20 Litres / 5.3 US gal / 4.4 Imp gal | 20 Litres / 5.3 US gal |
|
Suspension - Front
|
43mm KYB fully adjustable inverted 43mm fork | 43mm KYB inverted telescopic front forks, full adjustable, coil spring, oil damped |
|
Suspension - Rear
|
Linkage-assisted, rebound-damping and spring-preload adjustable shock | Link-type KYB mono-shock, full adjustable, coil spring, oil damped |
|
ABS
|
Standard | ABS standard |
|
Bore x Stroke
|
100 x 66.0mm | 100 x 66 mm |
|
Height
|
1515 mm / 59.6 in | 1515mm / 59.6 in |
|
Length
|
2265 mm / 98.2 in | 2265 mm / 89.2 in |
|
Wet Weight
|
236 kg / 520 lbs | 242 kg / 534 lbs ↑ |
|
Tyres - Front
|
110/80 x 19 | 110/80R19M/C 59V tubeless |
|
Width
|
870 mm / 34.3 in | 940 mm / 37 in ↑ |
|
Tyres - Rear
|
150/70 x 17 | 150/70R17M/C 69V tubeless |
|
Wheels
|
Cast aluminum | 10-spoke cast aluminium wheels |
|
Rake
|
25.3° | 25° ↓ |
|
Fuel Induction
|
EFI w/ 49mm throttle body | EFI with 49mm throttle body |
|
Trail
|
109 mm / 4.3 in | 110 mm / 4.3 in ↑ |
