2014 KTM RC8R 1190 Specifications

Name: 2014 KTM RC8R 1190
Brand: KTM

Sport • Specs last verified 13 July 2026

No images available

Tap to enlarge

2014 KTM RC8R 1190 Overview

KTM RC8R 1190 is a sport motorcycle, displacing 1195 cc. Power comes from a Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder engine, a compression ratio of 13.5 :1. On the performance side, it delivers 129 kW @ 10250 rpm of peak power and 127 Nm @ 8000 rpm of torque. Top speed is factory-quoted at 271.4 km/h. On the road, the 2014 RC8R 1190 tips the scales at 186 kg, carries a 16.5-litre fuel tank, offers a seat height of 805 mm - 825 mm and spans a 1425 mm wheelbase. That's roughly 16.7 kg lighter than the average sport motorcycle in our database. The full 2014 KTM RC8R 1190 spec sheet below covers every technical detail, from suspension travel to tyre sizes.

2014 RC8R 1190 - Pros & Cons

Strengths

Strong power output: With 129 kW @ 10250 rpm and 127 Nm @ 8000 rpm of torque on tap, the RC8R 1190 is no slouch for its class.

Considerations

Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.

Wear Points & Servicing Notes

Cooling system servicing

RC8R 1190's Liquid cooling setup is low-maintenance provided the coolant interval is kept - old, acidic coolant is the main cause of long-term corrosion in the water passages.

Brake disc and pad wear

Braking up front comes from 2x 320mm discs 4 piston calipers - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.

Suspension condition on used examples

The RC8R 1190's suspension runs 43mm WP Upside down adjustable at the front. The rear uses WP shock, fully adjustable. Fork-seal condition and rear linkage play are the two things worth checking before buying used.

Final drive maintenance

The RC8R 1190 uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.

Frame & chassis check

Built around a Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar, the RC8R 1190's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.

RC8R 1190 - Buying & Maintenance Guide

What to check before buying

Before handing over money for a used 2014 KTM RC8R 1190, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy RC8R 1190 should catch quickly and settle into a smooth idle.

Oil and filter changes

Nothing protects a RC8R 1190's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). Match the viscosity grade to what the owner's manual specifies, not what's cheapest.

Carburetor upkeep

Deposits in the carbs are the usual culprit behind poor running on a stored RC8R 1190 - strip and clean the float bowls before the first start. Pilot jets clog first and get overlooked most, so make a point of checking them.

2014 KTM RC8R 1190 - Frequently Asked Questions

What engine does the 2014 KTM RC8R 1190 have?

The 2014 KTM RC8R 1190 uses a Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder engine with 1195 cc of displacement. It is liquid cooling.

What is the top speed of the 2014 KTM RC8R 1190?

The 2014 KTM RC8R 1190 has a factory-quoted top speed of 271.4 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.

How much does the 2014 KTM RC8R 1190 weigh?

The 2014 KTM RC8R 1190 weighs 186 kg. This is the manufacturer's dry figure.

How much power does the 2014 KTM RC8R 1190 make?

The 2014 KTM RC8R 1190 produces 129 kW @ 10250 rpm of power and 127 Nm @ 8000 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2014 KTM RC8R 1190?

The 2014 KTM RC8R 1190 has a 16.5-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 275-330 km between stops.

Is the 2014 KTM RC8R 1190 suitable for shorter riders?

The 2014 KTM RC8R 1190 has a seat height of 805 mm - 825 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2014 KTM RC8R 1190 have?

The 2014 KTM RC8R 1190 uses 2x 320mm discs 4 piston calipers at the front and Single 240mm disc at the rear.

What tyre sizes does the 2014 KTM RC8R 1190 use?

The 2014 KTM RC8R 1190 runs 120/70 ZR17 front and 190/55 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2014 KTM RC8R 1190 have?

The 2014 KTM RC8R 1190 is fitted with a 6 Speed claw shifted transmission.

KTM RC8R 1190 Spec Evolution

The KTM RC8R 1190 was produced across 8 model years (2008-2015). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2008	2009	2010	2011	2012	2013	2014	2015
Max Power	125 kW @ 10250 rpm	167.6 hp / 122.4 kW) @ 10250 rpm	167.6 hp / 122.4 kW) @ 10250 rpm	129 kW / 175 hp @ 10250 rpm	129 kW / 175 hp @ 10250 rpm	129 kW / 175 hp @ 10250 rpm	129 kW / 175 hp @ 10250 rpm	129 kW / 175 hp @ 10250 rpm
Dry Weight	-	182 kg / 405.23 lb (no fuel)	182 kg / 405.23 lb (no fuel)	186.0 kg / 410.1 lbs	186.0 kg / 410.1 lbs	186.0 kg / 410.1 lbs	186.0 kg / 410.1 lbs	186.0 kg / 410.1 lbs
Engine Detail	Liquid cooling, four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Seat Height	805 mm / 825 mm	805 mm / 825 mm	805 mm / 825 mm	805 mm - 825 mm / 31.69in - 32.48in	805 mm - 825 mm / 31.69in - 32.48in	805 mm - 825 mm / 31.69in - 32.48in	805 mm - 825 mm / 31.69in - 32.48in	805 mm - 825 mm / 31.69in - 32.48in
Fuel Capacity	16.5 Litres / 4.3 gal	16.5 Litres / 3.5 gal	16.5 Litres / 3.5 gal	16.5 Litres / 4.3 gal	16.5 Litres / 4.3 gal	16.5 Litres / 4.3 gal	16.5 Litres / 4.3 gal	16.5 Litres / 4.3 gal
Frame Type	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar
Displacement	1195	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in	1195 cc / 73.0 cu-in
Brakes - Front	2x 320mm discs Brembo 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers	2x 320mm discs 4 piston calipers

Key Specifications

Engine

Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder

Power

129 kW / 175 hp @ 10250 rpm

Torque

127 Nm / 93.6 lb-ft @ 8000 rpm

Top Speed

271.4 km/h

Weight

186.0 kg / 410.1 lbs

Fuel Capacity

16.5 Litres / 4.3 gal

Full 2014 KTM RC8R 1190 Specifications

Year 2014

Make Model KTM RC8R 1190

Seat Height 805 mm - 825 mm / 31.69in - 32.48in

Wheelbase 1425 mm / 56.1 in

Ground Clearance 110 mm / 4.3 in

Dry Weight 186.0 kg / 410.1 lbs

Fuel Capacity 16.5 Litres / 4.3 gal

Top Speed 271.4 km/h

Max Power 129 kW / 175 hp @ 10250 rpm

Max Torque 127 Nm / 93.6 lb-ft @ 8000 rpm

Standing Start ¼ Mile 10.8 sec

Displacement 1195 cc / 73.0 cu-in

Engine Detail Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder

Bore x Stroke 105 x 69 mm

Compression Ratio 13.5 :1

Cooling System Liquid cooling

Exhaust Stainless steel underfloor silencer with regulated catalytic converter

Fuel Induction Keihin EFI throttle body 52 mm

Ignition Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment

Lubrication Pressure lubrication with 3 Eaton pumps

Starter Electric

Clutch Wet, multiple discs, hydraulic operated

Final Drive Chain 5/8 x 5/16" X Ring

Primary Drive Ratios 40:76

Secondary Drive Ratio 17:37

Transmission / Drive 6 Speed claw shifted

Frame Type Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar

Suspension - Front 43mm WP Upside down adjustable

Suspension - Rear WP shock, fully adjustable

Steering Head Angle 66.7°

Trail 97 mm / 3.82 in

Wheel Travel - Front 120 mm / 4.7 in

Wheel Travel - Rear 125 mm / 4.9 in

Brakes - Front 2x 320mm discs 4 piston calipers

Brakes - Rear Single 240mm disc

Tyres - Front 120/70 ZR17

Tyres - Rear 190/55 ZR17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
