Key Specifications
Engine
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Fuel Capacity
9.0 L / 2.4 US gal / 2.0 Imp gal
Full 2011 KTM 530 EXC Specifications
Year
2010 - 11
Make Model
KTM 530 EXC
Seat Height
925 mm / 36.4 in
Wheelbase
1475 mm / 58.1 in
Ground Clearance
380 mm / 15.1 in
Dry Weight (kg)
114
Dry Weight
114 kg / 251 lbs
Fuel Capacity
9.0 L / 2.4 US gal / 2.0 Imp gal
Maximum Load / GVWR
335 kg / 739 lbs
Oil Capacity
0.60 L / 0.63 US qt / 0.50 Imp qt, full synthetic oil (Motorex Power Synt 4T 10W/50)
Displacement
510.4 cc / 31.1 in
Engine Detail
Four stroke, single cylinder, SOHC, 4 valves per cylinder
Bore x Stroke
95 x 72 mm
Compression Ratio
11.9:1
Cooling System
Liquid cooled
Fuel Induction
Keihin MX FCR 3900J
Fuel Reserve
2 L / 2.1 US qt / 1.8 Imp qt
Ignition
CDI Kokusan 4K-3
Lubrication
Pressure circulation lubrication with two rotor pumps
Spark Plug
NGK LKAR 8AI - 9
Starter
Electric & kick
Battery Capacity
YTX5L-BS 12V 4Ah, maintenance free
Clutch
Wet, multi-disc
Final Drive
Chain, 5/8 x 1/4"
Final Drive Ratio
15:45
Gear Ratios
1st 14:34 / 2nd 17:31 / 3rd 19:28 / 4th 22:26 / 5th 24:23 / 6th 26:21
Primary Drive Ratios
33:76
Transmission / Drive
6 Speed
Frame Type
Central tube chrome-moly-steel frame
Suspension - Front
WP 4860 MXMA PA usd fork
Suspension - Rear
WP Suspension PDS 5018 DCC, aluminium swing arm
Steering Head Angle
63.5°
Wheel Travel - Front
300 mm / 11.8 in
Wheel Travel - Rear
335 mm / 13.2 in
Brakes - Front
Single 260 mm disc, floating caliper
Brakes - Rear
Single 220 mm disc, floating caliper
Tyres - Front
90/90 - 21 M/C 54M M+S TT, Metzeler MCE 6 Days Extreme
Tyres - Rear
140/80 - 18 M/C 70M M+S TT, Metzeler MCE 6 Days Extreme
